INSTALLER AND OWNER GUIDE
Model 820 Longlite
Electric Heater
Fitted with the
Brooklyn
(G.C. No. EF-032-33)
This guide is intended to help you
install and care for your Valor Fires
electric heater. Please read carefully
before installing and using your
heater. However, if further information
is required, our
Valor Fires Technical Helpline
will be pleased to help.
Telephone 0844 8711 565
(National call rates apply in the
United Kingdom)
In the Republic of Ireland
Telephone 0044 844 8711 565
Important: Please keep your guide in a safe place for future reference.
©
Baxi Heating U.K. Limited 2009.
fascia.
5134807/02

Advertisement

loading
Need help?

Need help?

Do you have a question about the 820 Longlite and is the answer not in the manual?

Questions and answers

Related Manuals for Valor Fires 820 Longlite

Summary of Contents for Valor Fires 820 Longlite

  • Page 1 Fitted with the Brooklyn fascia. (G.C. No. EF-032-33) This guide is intended to help you install and care for your Valor Fires electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Valor Fires Technical Helpline will be pleased to help.
