INSTALLER AND OWNER GUIDE
Model 828
Electric Heater
Fitted with one of the following fascia
Brooklyn
(G.C. No. EF-032-21)
This guide is intended to help you
install and care for your Valor Fires
electric heater. Please read carefully
before installing and using your
heater. However, if further information
is required, our
Valor Fires Technical Helpline
will be pleased to help.
Telephone 0844 8711 565
(National call rates apply in the
United Kingdom)
In the Republic of Ireland
Telephone 0044 844 8711 565
Important: Please keep your guide in a safe place for future reference
©
Baxi Heating U.K. Limited 2008.
Moonlight.
or
5129556/03
Advertisement
Related Manuals for Valor Fires 828
Summary of Contents for Valor Fires 828
- Page 1 Fitted with one of the following fascia Brooklyn Moonlight. (G.C. No. EF-032-21) This guide is intended to help you install and care for your Valor Fires electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Valor Fires Technical Helpline will be pleased to help.
- Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Valor Fires, Erdington, Birmingham B24 9QP www.firesandstoves.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication ©...
- Page 3 INSTALLER AND OWNER GUIDE Safety First. Valor Fires heaters are CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence. All Valor Fires heaters are manufactured to the highest standards of quality and excellence and are manufactured to ISO 9001...
- Page 4 Always make sure the heater is firmly secured to prevent it from being tipped over. Always use a fireguard when young children and infirm persons can come into contact with the heater. Always use genuine Valor Fires spare parts. © Baxi Heating U.K. Limited 2008. Page 4...
- Page 5 INSTALLER AND OWNER GUIDE Never Never leave children unsupervised in a room where the heater is ON and unguarded. Never obstruct or cover the fan outlet or force items into heater openings. Never install or use the heater anywhere where water is in use, i.e. Bathrooms, Kitchens, Shower Rooms, Swimming Pools etc.
- Page 6 INSTALLER AND OWNER GUIDE 3. FITTING THE HEATER The installation of this heater requires a reasonable level of DIY skills. Please read this guide thoroughly before commencing installation and if in doubt, seek help from a competent person. Do I need any tools? 1.
-
Page 7: Table Of Contents
INSTALLER AND OWNER GUIDE (Illustrations are not (Illustrations are not Contents Contents to scale) to scale) Heater Cover plate Wall Rear Spacer mounting frame bracket Bag of pebbles Front Spacer frame Lower securing bracket Woodscrew Wall plug M5 x 8 screw (Silver) No.8 x 3/8 screw... - Page 8 INSTALLER AND OWNER GUIDE Heater dimensions. Model Dimension A Dimension B Dimension C Brooklyn Moonlight Figure 2. Heater dimensions (Fascia may differ from that shown) Moving the cable guide. At the base of the heater you will find an electric cable which runs through a rectangular plastic cable guide.
-
Page 9: Heater
INSTALLER AND OWNER GUIDE Item 1 Item 3 Item 4 Item 2 Figure 3. Removing and positioning the cable guide. If the electric cable is damaged, to avoid a hazard it must be replaced by a Valor Fires authorised service agent, or similarly qualified person. All external wiring between the heater and the electrical supply shall comply with current IEE regulations. - Page 10 INSTALLER AND OWNER GUIDE Heater fixing. All fixings necessary to install the heater the heater have been identified in figure 1. The heater must be fixed into position. Fitting a wall mounting bracket to the wall. Supplied with the heater are two wall mounting brackets (See figure 1). Fix one of these brackets to the wall as follows.
-
Page 11: Frame
INSTALLER AND OWNER GUIDE Fitting the spacer frames. (See figure 5). The heater is supplied with two spacer frames. One for the rear and one for the front of the heater flanges. Fit the rear spacer before the front spacer. Fitting the rear spacer frame. - Page 12 INSTALLER AND OWNER GUIDE Fitting the brackets to the heater. 1. Locate the second wall mounting bracket to the rear of the heater using two silver M5 x 8mm screws supplied. Ensure that the bracket is correctly orientated before securing (See figure 7). Figure 7 2.
-
Page 13: Diffuser
INSTALLER AND OWNER GUIDE Fitting the cover plate. The heater is supplied with a cover plate for the base of the heater (See figure 1). 1. Secure the cover plate to the base of the heater using four No.8 x 3/8 screws supplied (See figure 9). - Page 14 INSTALLER AND OWNER GUIDE Fitting the Fascia Before fitting the fascia complete the last page of this guide. 1. Remove the fascia from its packaging. 2. Locate the fascia onto the heater. To do this locate the bracket at the top of the fascia into the bracket at the top of the front spacer (See figure 12).
- Page 15 INSTALLER AND OWNER GUIDE 5. CLEANING AND MAINTAINING THE HEATER How do I clean my heater? The heater fascia and glass parts need only to be wiped clean with a dry soft cloth, do not use polishes or abrasive materials. I have a problem with my heater! Important Safety Before undertaking maintenance or replacing the lamp(s) always disconnect the...
- Page 16 INSTALLER AND OWNER GUIDE 2. My heater is on but there is no light or heat. The first thing to do is check the wall socket. To do this plug in a known working appliance. If the appliance you have plugged in works then there is a good chance that the problem lies with the 13Amp fuse in the heater plug.
- Page 17 INSTALLER AND OWNER GUIDE 7. WARRANTY AND SERVICE Information for the customer Standard Warranty Terms & Conditions The warranty is for 12 months subject to contract. In the United Kingdom servicing can be carried out either by a heateam service engineer or a suitably qualified person.
- Page 18 INSTALLER AND OWNER GUIDE What this warranty does not cover Repairs to heaters which haven’t been installed properly and as set out in this guide. Faults caused by inadequate supply of electricity. Reimbursement of any third party repair or replacement costs that we haven’t been told about or agreed with you in advance.
- Page 19 INSTALLER AND OWNER GUIDE To be completed by the customer: Model Serial number (Can be found on the information label - See figure 15) A LABEL CONTAINING THE SERIAL NUMBER MAY HAVE BEEN PLACED INSIDE THIS BOX. Fascia name (Block Capitals) Fascia code - Can be found close to the information label (Block Capitals) A LABEL CONTAINING THE FASCIA CODE MAY HAVE BEEN PLACED...
- Page 20 © Baxi Heating U.K. Limited 2008.
