Connecting the Display (Figure 10.1)

To setup this display, please refer to the following figure and procedures.
1. Be sure all equipment is turned off.
2. Connect the DC adapter to the power connector on the monitor and the other end into
an electrical outlet.
3. Connect the D-SUB cable from the display's VGA input connector to the D-SUB
connector of your host computer and tighten the screws (10.1).
4. Connect the USB cable from the USB port of your display to USB port of your computer (10.1).
5. Configure the touch screen. Refer to the "Touch Screen Driver Installation" section on
page 17.
6. Once the touch screen is configured, the monitor is ready for use.
7. Connect the remote control cable to RJ11 port (10.1) (optional).
Notice!
!
To ensure the LCD display works well with your computer, please configure the display
mode of your graphics card to make it less than or equal to 1024 x 768 resolution and
make sure the timing of the display mode is compatible with the
LCD display.
We have listed the compatible "Video Modes" of your LCD display in the appendix
(on page 16) for your reference.
Don't connect telephone or internet cable to RJ-11 port.
Adapter rating:12Vdc 2.5A min., marked with LPS.
