Customer panel material:
RECOMMENDED CUSTOMER PANEL CUT-OUT
365.93 mm
72 mm
72 mm
A
A
A
A
4-R4.29
344.81 mm
*
A: The distance between the shielding surface and the bottom of the screw hole is 6.5 mm.
IMPORTANT!
Warning!
!
Please select proper screws!
Please use four M4 screws of adequate length for mounting your monitor.
Please note: The mounting stand must be able to support at least 11 lbs (5kg)
7
