Table of Contents Usage Notice Precautions..........................1 Introduction About K15A Series ........................2 Touch Screen for K15A-0101 ..................2 Package Overview .......................3 Installation Product Overview ......................4 Front View ........................4 Bottom View ......................4 Attaching the L-Brackets ....................5 Side Mount for your monitor ..................6 Connecting the Display (Figure 10.1) ................8 (Figure 10.1) ......................9...
Usage Notice Warning - To prevent the risk of fire or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.
Introduction About K15A Series The K15A Series is a 15" flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Active matrix TFT LCD technology • 1024 x 768 XGA resolution •...
Package Overview LCD Display VGA Signal Cable Power Cord USB Cable ( A to B) Quick Start Guide DC Power Supply Remote Key Screws Bracket (sold separately)
Attaching the L-Brackets Depending on your mounting scheme, alternately, you may use the L-brackets to mount your displays onto your wall or device. Find a suitable location for attaching L-brackets. A. The left and right sides B. The Top and bottom sides Bracket Bracket Bracket...
Side Mount for your monitor This monitor can be mounted with 4 screws and a pair brackets on the opposites. 156 mm 132 mm...
Page 10
Customer panel material: RECOMMENDED CUSTOMER PANEL CUT-OUT 365.93 mm 72 mm 72 mm 4-R4.29 344.81 mm A: The distance between the shielding surface and the bottom of the screw hole is 6.5 mm. IMPORTANT! Warning! Please select proper screws! Please use four M4 screws of adequate length for mounting your monitor. Please note: The mounting stand must be able to support at least 11 lbs (5kg)
Connecting the Display (Figure 10.1) To setup this display, please refer to the following figure and procedures. 1. Be sure all equipment is turned off. 2. Connect the DC adapter to the power connector on the monitor and the other end into an electrical outlet.
User Controls Back Panel Controls Power Enter Down Menu Menu off status Menu on status Menu appear Menu disappear/return to main item Brightness Main item select up/Adjust up Contrast Main item select down/Adjust down Enter/Select sub-item function Power On/Off...
How to Use the OSD Menus Icon key Name Menu Down Enter Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the five functions in the main menus. 2.
On-Screen Display Menus Main OSD Menu: ITEM CONTENT Contrast The monitor luminance level control. Brightness The monitor backlight level control. Auto Adjust Fine-tune the image to full screen automatically. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down.
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your sales representative or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected described in the "Installation"...
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. There may be three sources for this problem. Please check the cable connections or contact your sales representative or our service center for more information.
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 720X400 31.47 IBM VGA 640X480 31.47 Apple MacII 640X480 35.00 VESA VGA 640X480 37.86 VESA VGA 640X480 37.50 VESA VGA 800X600 35.16 VESA VGA 800X600 37.88 VESA VGA 800X600 48.08 VESA VGA 800X600 46.88 Apple Mac...
Touch Screen Driver Installation The K15A-0101 is available with USB connection. The Linux kernel 2.6.x (32 bit & 64 bit) touch ® driver can be downloaded at www.touchrev.com. HID for Windows 7, VISTA , XP, 2000, ME, 98. Please Note: ®...
