USER's GUIDE
TDS-32F Series
Touch Screen LCD Monitors
Rev.D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDS-32F Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Touch Revolution TDS-32F Series

  • Page 1 USER’s GUIDE TDS-32F Series Touch Screen LCD Monitors Rev.D...
  • Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
  • Page 3: Table Of Contents

    Table of Contents Usage Notice Precautions..........................1 Introduction About TDS-32FP Series ......................2 Touch Screen for TDS-32FP (Bezel Less) ................3 Package Overview ...................... 4 Installation Product Overview ......................5 Front View ......................5 Bottom View ......................5 VESA Mount for Your Monitor ..................6 Start Your Installation ....................
  • Page 4: Usage Notice

    Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.
  • Page 5: Introduction

    Introduction About TDS-32FP Series The TDS-32FP Series is a 31.5" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Direct Digital signal input • Active matrix TFT LCD technology •...
  • Page 6: Touch Screen For Tds-32Fp (Bezel Less)

    Touch Screen for TDS-32FP (Bezel Less) • Project Capacitive touch screen for fi nger input only • Surface: Glare treatment • Interface: USB controller • Transmittance: 90%±5% • HID: Windows® 7 • Driver: VISTA, XP, 2000, CE, XP Embedded, Linux kernel 2.6.x (32 bit & 64 bit), Apple ® Mac OS...
  • Page 7: Package Overview

    Package Overview LCD Display Power Cord VGA Signal Cable USB Cable (A to B) Audio-in Cable DVI-D Cable Quick Start Guide Touch Driver CD Cable Cover Screw Remote Key (sold separately)
  • Page 8: Installation

    Installation Product Overview • Front View • Bottom View AC IN COM OUT DVI IN COM IN VGA IN REMOTE KEY AUDIO IN AUDIO OUT...
  • Page 9: Vesa Mount For Your Monitor

    VESA Mount for Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface standard which defi nes a physical mounting interface for fl at panel monitors, and corresponding with the standards of fl at panel monitor mounting devices, such as wall and table arms.
  • Page 10: Start Your Installation

    Start Your Installation Please follow these instructions so that you can hook up the cables to associated connectors. 1. Lay the LCD fl at on an even surface and take off cable cover as seen in the step 1 diagram. 2.
  • Page 11: Connecting The Display (Figure 9.1)

    Connecting the Display (Figure 9.1) To setup this display, please refer to the following fi gure and procedures. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (9.1).
  • Page 12: (Figure 9.1)

    (Figure 9.1)
  • Page 13: User Controls

    User Controls Rear Panel Controls Icon Key Name Menu Down Select Power Menu off status Menu on status Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Mute Main item select down / Adjust down Auto Adjust Select sub-item function Power On / Off...
  • Page 14: How To Use The Osd Menus

    How to Use the OSD Menus Icon Key Name Menu Down Select Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the six functions in the main menu. 2.
  • Page 15: On-Screen Display Menus

    On-Screen Display Menus Main OSD Menu: ITEM CONTENT The monitor luminance level control. Contrast The monitor backlight level control. Brightness Fine-tune the image to full screen automatically. Auto Adjust Moving screen image horizontal position to left or right. Left/Right Moving screen image vertical position to up or down. Up/Down The screen image horizontal dot clock adjustment.
  • Page 16: Appendix Troubleshooting

    Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”...
  • Page 17: Warning Signal

    Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your local dealer or our service center for more information.
  • Page 18: Product Dimensions

    Product Dimensions +1.0 69.7 44.7 393.3±0.5 280.2 92.1 698.7±0.5 Front View Side View +1.0 781.54 476.14 +1.0 352.93 Back View...
  • Page 19: Compatibility Modes

    Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 640X480 31.47 VESA SVGA 800X600 35.16 VESA SVGA 800X600 37.88 VESA XGA 1024X768 48.36 VESA SXGA 1280X1024 64.00 VESA SXGA 1280X960 60.00 WXGA+ 1440X900 56.00 WSXGA+ 1680X1050 65.20 VESA WXGA 1280X768 47.776 VESA WXGA 1280X720 44.77...
  • Page 20: Touch Screen Driver Installation

    Touch Screen Driver Installation The TDS-32FP Series is available with USB connection. The Linux kernel 2.6.x (32 bit & 64 bit) touch driver is located on the enclosed CD-ROM. HID for Windows® 7, VISTA, XP, 2000, ME, 98, CE, XP Embedded, Linux, Apple® Mac OS. HID for Windows® 7. Please Note: 1.
  • Page 21 If you are using a PC running Windows® CE, follow the instructions below: 1. Power on the computer. 2. Make sure that the USB cable is connected to the computer. 3. Using Platform Builder, build an image fi le by following the step-by-step instructions found in the folder fi...
