YOUR OVEN AND ACCESSORIES

9
8 7
13
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it
is not damaged.
• After cooking fatty foods without a cover, always clean the cavity and especially the grill heating
elements thoroughly, these must be dry and free from grease. Built-up grease may overheat and
begin to smoke or catch fire.
• Always operate the oven with the turntable fitted correctly. This promotes thorough, even cooking.
A badly fitted turntable may rattle, may not rotate properly and could cause damage to the oven.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you
start the oven. This does not affect cooking performance.
• When you order accessories, please quote both the PART NAME and MODEL NUMBER to
your dealer or SHARP approved service facility. The model number is located at the bottom of the
control panel.
WARNING:
The door, outer cabinet, oven cavity, turntable, dishes, accessories and especially the grills
will become very hot during operation. To prevent burns, always use thick oven gloves.
26/08/2004 15:23
10
1
2
6 5 4 3
11
12
14
15
Page 2
OVEN:
1. Control panel
2. Oven lamp
3. Waveguide cover (DO NOT REMOVE)
4. Bottom grill heating element
5. Turntable motor shaft
6. Oven cavity
7. Door seals and sealing surfaces
8. Door latches
9. Door opening handle
10. Top grill heating element
11. Ventilation openings
12. Outer cabinet
13. Power cord
ACCESSORIES:
Check to make sure the following accessories are
provided:
14. Turntable
15. Rack
• Place the turntable on to the turntable motor
shaft, ensuring it is located firmly.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
• For use of the rack, refer to the grilling and
dual cooking sections on pages 12 to 15.
Never touch the grills when they are hot.
