Fuho 16CH H.264 User Manual

Embedded digital video recording systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

16CH H.264
Embedded Digital Video Recording systems
USER MANUAL
2012 NOV V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 16CH H.264 and is the answer not in the manual?

Questions and answers

Related Manuals for Fuho 16CH H.264

Summary of Contents for Fuho 16CH H.264

  • Page 1 16CH H.264 Embedded Digital Video Recording systems USER MANUAL 2012 NOV V1.0...
  • Page 2   WARNING  Do not expose the DVR under the sunlight, heat or wet environment while installation. As it could decrease the performance of DVR and damage the machine.  Do not touch the power plug or case with wet hands as this could result electric shock.

  • Page 3: Table Of Contents

      CONTENTS Specification ............................1 Structure of Product .......................... 2 HDD Installation ..........................4 System installation ..........................5 Quick Set up Guide ........................... 6 System Operation ..........................8 Display mode ..........................11 Live Viewing Mod ......................11 Live Monitor ........................12 PTZ ..........................

  • Page 4: Specification

      1. Specification Video Format NTSC Video Input 16 CH Input / BNC Audio Input 4 CH Input / RCA Video Output 1 CH Output / BNC Audio Output 1 CH Output / RCA XGA Output 800x600、1024x768、1280x1024 Alarm Input 4CH Alarm In Alarm Output Buzzer，1 x Relay Out (N.O、N.C) Display Mode...

  • Page 5: Structure Of Product

      2. Structure of Product  Front Panel Under the live viewing mode, press MENU to enter the main menu. Menu MENU Under the menu mode, press MENU to go to the upper menu. To stop the operation or go to the upper menu under the playback Stop mode.
  • Page 6    Installation USB Mouse Port 2.0 USB Mouse VIDEO IN 1~16 CH Video Input (BNC) VIDEO OUT Video Output (BNC) AUDIO OUT Audio Output (RCA) AUDIO IN 1~4 CH Audio Input ALARM Includes 4 DI AND 1 DO (Default N.O.) DC12V Power Input LCD Monitor Output...

  • Page 7: Hdd Installation

      3. HDD Installation Please install the 3.5 inch SATA HDD in the device and connect the power  wire and transmission wire. If no install HDD, the system can’t recording. When install 1pc HDD, the hard disk can be installed in any SATA HDD ...

  • Page 8: System Installation

      4. System installation Connect the camera video output to the DVR video input port with BNC  connectors. BNC connectors recommend to use RG-59 or above. DVR Network installation  Please connect DVR to HUB or router by using RJ-45 network cable and make sure the DVR network indicator LED in on(Please refer to Network Setup for further network setting information of using static IP, PPPoE or DHCP )

  • Page 9: Quick Set Up Guide

      5. Quick Set up Guide System power on, the system will automatically jump to quickly set up guided wizard and allows the user can simply and quickly set up the DVR, the operation as shown below: Note: set Guidance after each reboot; go to the main menu ->Configuration Management->Basic->System setting Setup 1: Set the date and time / If next reboot to open Guide (as below), setup finish and then click「Next」for next step setting.
  • Page 10   Setup3: Setup recording quality / resolution / frame (as below), finish setup and then click「Next」for next step setting. Setup4: HDD management & format(as below) , finish setup and then click 「Next」for next step setting. Setup5: Display the last HDD information.  ...

  • Page 11: System Operation

      System Operation There are 3 kinds of DVR control method: Front panel, remote control and USB mouse, The front panel operation, please refer to the [Front panel]. USB Mouse Operation  Quick Menu: Right click the mouse button under the live viewing mode to go for enter into Quick Menu.
  • Page 12   Note：There are many DVR equipments in the same place, the remote control first need to select a device, according to the DVR ID. So, should give each DVR device to define a unique device number (DVR ID). Otherwise, the remote control operation may be playing a role for multiple devices with the same DVR ID number at the same time.
  • Page 13   Quick Menu    The function described as below  Enter the main menu For Single channel display For Quad Display (1-4),Click again and then display 5-8, 9-12, 13-16, 1-4 cycle. For 9 division display (1-9), click again and then display 9-16, 1-9 cycle.

  • Page 14: Display Mode

      7. Display mode There are 4 kinds of screen display mode: Live, Auto Switch, PTZ , Digital zoom, quick playback. 7.1 Live Viewing Mod The DVR will go to the live display mode after boot up.      In Live Display mode, there are 5 different status icon: ...

  • Page 15: Live Monitor

      Start/Stop the Manual [Record] to enter manual Move cursor to UI Quick Menu record menu to select [Left click] to select Start/Stop the Auto [Auto Switch key] To UI Quick Menu select Switching Start/Stop PTZ Auto Click “PTZ” enter control To UI Quick Menu select Cruise...
  • Page 16   The following table is simple operation for Mouse and panel , remote  control: Front Panel & Remote Setup Operation USB Mouse Control Select Item [Up/Down/Right/Left] Moving Cursor Enter Select Item [Enter] [Left Click] [Up/Down/Right/Left]Move to Moving Cursor to channel [Left Select PTZ Channel channel position and then click] to confirm...

  • Page 17: Digital Zoom

      7.4 Digital Zoom This system provides digital zoom in or zoom out the video image on the  live monitoring and playback interfaces. Please operate by mouse, directly click Quick Menu by mouse or  panel remote control arrow keys to click confirm.

  • Page 18: Quick Playback

        4. Moving mouse cursor to the bottom right corner of the selection area, press and hold the left mouse button drag to display the zoom position. 5. When pop-up the digital zoom display, can click right mouse button to exit, re-pull the selected area.
  • Page 19   The playback operation control bar(as below), the function operation as  follows: Front Panel & Remote Menu Operation USB Mouse Control Fast Rewind [Fast Rewind] [Left Click] Fast Forward [Fast Forward] [Left Click]] Step /Pause [Step/Pause] [Left Click]] Step Forward [Step Forward] [Left Click]] Play 1x...

  • Page 20: Menu Operation

      8. Menu Operation 8.1 User Login After system turn on, the system will auto appear the following dialog  box that you need to key in correct user name and password before into the main menu. The default user name: admin / Password: blank. The user name can be ...

  • Page 21: The Main Menu Instructions

      8.2 The Main Menu Instructions   8.2.1 Configuration Management Path: Main Menu->Set up Management   The setup management page is divided into the Basic setup / Live /  Recording / Schedule recording / Alarm / Network / User Management / PTZ / Advanced setup.

  • Page 22: 1 ) Basic Setup

      ( 1 ) Basic Setup Path: Main Menu->Config management->Basic setup   The setup page is divided into the System and Date & Time  setup pages.    (1.1) System a. Setup DVR Name, You can key in 4 characters for Chinese words or 12 characters Arabic numerals (words).
  • Page 23   Note: If the setup is different the actual display, and then unable enter the menu to change the output screen. The system boot and plug to continuous press mouse wheel until show the screen, you can successfully change the screen output. g.

  • Page 24: ( 2 ) Live (Live Image)

      ( 2 ) Live (Live image) Path: Select Main menu->Configuration Management->Live.   The setting page is divided into Live image and Mast     (2.1) Live image setting   a. Channel Name: Setup to modify channel name. You can key in 5 characters for Chinese words or 15 characters Arabic numerals (words).

  • Page 25: 3 ) Recording

        The mask setting steps are as follows, need to use the mouse set a. Select channel for privacy mask , click「Setup」, enter the live monitor screen. b. In the mask area, move the mouse cursor and press left button to select area, and then release the mouse button to finish the cover area setup.
  • Page 26   record with image record. (The factory default for channel image record is enable; Audio record is closed) (3.2)Video record Bitrate The related setup for video record data , as follows: a. Resolution: Setup each channel image record resolution b. Frame rate: Setup each channel the record frame rate c.
  • Page 27   sampling rate. When the video is complex, the captured bit and retrieved bit are more, that will make the video data files increase. On the contrary, if the video is simply, that will collect less bit to storage. In other words, the whole audio and video sampling rate aren’t same.

  • Page 28: 4 ) Schedule Recording

      (3.5)Loop Record Set up Loop record when the HDD is recording full to cover and Loop record.   ( 4 ) Schedule Recording Path: Main menu->Configuration Management->Schedule  Recording This DVR, except manual recording don’t need to schedule the ...
  • Page 29   ※ This DVR can setup image individually for each channel, the users setup need to pay attention(Avoid to only set up CH1 and forget to set up other channel), the setup values for CH1 can copy to other channel or all channel, The follow-up camera setup are all same with this, as below shown: (4.2) Motion recording...

  • Page 30: 5 ) Alarm

      ( 5 ) Alarm Path: Select Main menu->Configuration management->Alarm  All Alarm setup for this DVR are all concentrated on this page,  the sub-individual set up for each channel or sensor are divided into Sensor alarm(Alarm input) / Motion detect / Video Loss / Alarm out.
  • Page 31   This setup can produce relevant action for the alarm is triggered, first set up the delay time. Alarm: Please press “Setting” for relative setup as the following (5.1.2.1) Basic setup of Alarm Please refer to the specific setup of alarm Buzzer: On/Off Full Screen: To have any specific camera image shown in full screen display after triggering the...
  • Page 32   (5.1.2.2) Alarm Handling Select which camera to start recording after triggering the alarm (You can choose numerous or all) (5.1.2.3) To PTZ To select the relative actions after triggering PTZ cameras, like present point, tour, and tracking. (5.1.3) Schedule (Sensor Input) The sensor input schedule recording is provided by this product, this means the sensor will not to be triggered when the setting is off (Because the setting of sensor input and...
  • Page 33   (5.2) Motion Detection (5.2.1) Movement Detection a. Turn on the motion detection of designated camera b. The setting of continuous duration time after triggering the motion detection c. The setting handling after triggering the alarm (Main Menu-> Setting Management-> Basic Alarm Setting-> Sensor Alarm->...
  • Page 34   The display of remote control: Sensitivity Setting of Motion Detection, Using mouse to drag the area (Option 1 to 5, 5 is the highest) Select Whole Area Delete Whole Area Area Saving Setting Leave the area setting (5.3) Image Loss Image Loss Setting is for the video clips loss from each channel of DVR, the alarm handling of motion detection, Video loss;...

  • Page 35: 6 ) Network

      (5.4) Alarm Output Main setting of alarm output (As figure 1.), Schedule (Please refer to Main Menu->Setting Management->Schedule Recording Setting), Buzzer Synchronizer (As figure 2.) Network ( 6 ) Main Menu-> Setting Management->Network  (6.1) Network (Setting)) Main Setting: a.
  • Page 36   Static IP Setting a. IP Address b. Subnet Mask c. Gateway d. DNS Server 1 e. DNS Server 2 PPPOE (As the following figure) Move Bar a. PPPOE Setting b. User Name c. Press “Dial” after setting up passwords, the connection status will be displayed on the bottom left corner (As the following figure) d.
  • Page 37   (6.3) E-mail Setting of Triggering Alarm Message Sending a. SMTP Server/Port: Input SMTP Server Name and Port b. Sender Address/Password: Setting of Receiver Address/Password c. Receiver Address: Input three different accounts of receiver address d. Press “Test”, to verify if the account is possible to send or to be received (6.4) DDNS Setting  ...

  • Page 38: 7 ) User Management

      DDNS Setting: only for applier DDNS: On/Off DDNS Server DDNS User Name and Password Host Domain Name Update Interval (Minutes) User Management ( 7 ) Main Menu-> Setting Management-> User Management   To add or delete user’s name or passwords, or press “setup” to modify user’s authority, authority options including system setup, manual record, playback, PTZ control, hard disk, file management, log search, two way audio, remote login, system...

  • Page 39: 8 ) Ptz

      The higher safety function is provided by this DVR by locking up with MAC address, and this means the only MAC address setup user is authorized. (As the following figure)     ( 8 ) PTZ Main Menu-> Setting Management-> PTZ Setup  ...

  • Page 40: 9 ) Advance

      (8.2) Advanced Setup PTZ Preset setup, cruise setup (default setup as cruise), and record track setup   Advance ( 9 ) Main Menu-> Setup Management-> Advance   (9.1) System Reset To restore the default value, it will be requested to restart (Warning message will pop up) (9.2) Import/ Export This function is to export all of the multiple settings to become...

  • Page 41: Data Search

        Data Search 8.2.2 Main Menu-> Data Search   Beside pressing quick menu button to playback daily 1~4  channel video files, you can also go to Main Menu->Data Search, or press in remote control for playback.  Data search can be selected “By Time” or “By Type”  ...

  • Page 42: ( 2 ) By Type (Data Search Playback)

      ( 2 ) By Type (Data Search Playback)   4. Start Time 1. End Time 2. Select Channel 3. Recording Type As per multiple triggering recording is provided, user can search video recording type by the following steps: a. Select Start time and End time b.

  • Page 43: Information Search

      1. Select start and end time 2. Select channel 3. Press “Search” to list out all the search data 4. Select the data for backup “Available for multiple channels”. 5. Press “Backup”, it will go to setup of backup time display automatically, after finishing calculating the size of data.

  • Page 44: 1 ) System

      System ( 1 ) Main Menu-> Information Search->System (or Press “Info” in  the remote control) Display system hard drive and software information  System Information ( 2 ) Main Menu->Information Search->System Information (Press  “INFO” on the remote control) Log Search is for operation, setup, playback, backup, data ...

  • Page 45: 3 ) Network

      1. Select Time 2. Select Type 3. Press Search 4. Press Export Steps: a. Select Time b. Type: Operation, Setup, Playback, Backup, Search, Information, Error; multiple selection is available. c. Press “Search” for the all type of lists d. Press “Export” to save the designated log list into USB flash drive (as the following figure) e.

  • Page 46: Hard Disk

        Hard Disk 8.2.5 Main Menu-> HDD Management  Displaying of HDD Status, users can format HDD in this function  Format Steps as following:  1. Select HDD 2. Press Format button Select Hard Disk Press “Format” button Remark: Please backup all the necessary data before running format procedure;...

  • Page 47: User Log-Out

      1. Select Type 2. Select Data 3. Press “Upgrade” button Steps of Update Procedure: Select Type: Mainboard, Panel (for specific model), Boot logo, Show logo Select the update data; the update data will be automatically recognized by the product its own Press “Upgrade”...

  • Page 48: Dvr Player

    B. During backup procedure, it will automatically be saved along with back-up files C. Download form DVR through IE connection D. Download form FUHO official website  DVR player must be uncompressed then install on pc, steps as the following figures: Step 2: Select the folder which the Step 1: Click ”NEXT”...
  • Page 49   Functional instruction is as follows: a. “ ”: Open file. b. “ ”: play / pause file. c. “ ”: stop file. d. “ ”: slow play at 1/2, 1/4 and 1/8 speed. e. “ ”: Quick play at X2, X4 and X8 speed. f.
  • Page 50   Picture 3 Picture 4  ...

  • Page 51: Ie Operation Instruction

      10. IE Operation Instruction 10.1 IE Security setting: If it is the first time to connect DVR through IE, please refer to the following different kinds of setting up Internet option Method 1:  1. For IE 7.0~9.0, click “Tools”-> “Internet Options” 2.
  • Page 52   3. Input the website or IP address which are designated to be connected, like http://122.117.84.239 as below, please let the box to remain unchecked as the red in the figure, Click “Apply” after setting up; this will be always applied by Window 7 user  ...

  • Page 53: Ie Connection

      10.2 IE Connection  Open IE and by entering IP address of the DVR to connect to the login screen as shown below. Select language you wish to view in and enter the correct user name and password after successfully downloading the control interface.

  • Page 54: The Main Screen Interface

      10.2.1 The Main Screen Interface The main screen interface is shown as the following: video monitoring window, PTZ control, monitor split mode (single-screen, 9, and 16 split window), select the stream (main stream, sub-stream), the channel on/off (single, multiple or all), setting, playback, and the user log off.  ...

  • Page 55: Remote Setting

      10.2.2 Remote Setting Configure (#8), modify DVR feature setting remotely as shown below: (a). system parameter settings: set or modify name of the DVR, hard drive overwrite, channel switch, VGA resolution, menu transparency, status display, set the network IP address, DDNS, mobile phone control port-related...
  • Page 56   (c). Alarm setting: set or modify the alarm input, output, etc... (d). User setting: set or modify users’ permissions and password.  ...
  • Page 57   (e). Other: manual recording, system time, alarm cancelling, event log, system reboot, remote updating, the factory default setting, remote video and photo storage location.  ...

  • Page 58: Remote Playback

        10.2.3 Remote Playback Playback (#9), time, motion, alarm, manual recording data playback or download. a. Channel selection b. Set the start, end date and time, then press "Search" (or click on the playback time) c. Double-clicking on the selected file for playback (16 video files playback allowed).
  • Page 59   Click on monitoring window (red square will appear) and select a video file from the event log list on left you wish to playback. 4. Playback screen (4,8,9,16 split) click on the desired channel for the single-screen playback, or click the "full screen" playback d.

  • Page 60: Remote Monitoring Features

      10.2.4 Remote Monitoring Features On the main screen of remote monitoring, click on the channel (red box), right-click on the video monitoring window as shown below:   a. Audio On: All 16 channels can record sound and image or remote transmission simultaneously.

  • Page 61: Mobile Phone Software Installation

      11. Mobile Phone Software Installation Connect to DVR from mobile phone for remote live monitoring. Software applications which support Symbian, Windows Mobile, APPLE i-PHONE, Google Android, and Blackberry must be installed first. ※For detailed instruction, please refer to “ mobile phone operational instructions”. ...
