Fuho TA-462S User Manual

4ch standalone dvr
Hide thumbs

Advertisement

Table of Contents

4CH STANDALONE DVR
4ch
USER MANUAL
2009 AUG. Ver 1.1
MOTION
MOTION
Remote
(Optional)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TA-462S and is the answer not in the manual?

Questions and answers

Related Manuals for Fuho TA-462S

Summary of Contents for Fuho TA-462S

  • Page 1 4CH STANDALONE DVR USER MANUAL 2009 AUG. Ver 1.1 Remote MOTION MOTION (Optional)
  • Page 3 H D D S U P O R T L I S T Warning: For maximum performance and compatibility, always use the recommended hard drivers listed below. SATA Maxtor Seagate HITACHI Brand Capacity 250GB 250GB 250GB 250GB /Model STM3250318AS ST3250824AS HDT725025VLA380 WD2500AVVS Number 320GB...
  • Page 4 U S B S U P O R T L I S T Warning: For maximum performance and compatibility, always use the recommended hard drivers listed below. B r a n d / C a p a c i t y T r a n s c e n d / 4 G T r a n s c e n d / 8 G S a n D i s k / 4 G...

  • Page 5: Table Of Contents

    CONTENTS ........1、FEATURES ....... 2、SPECIFICATIONS ......... 3、INSTALLATION ......4、FRONT CONTROL PANEL ......5、OPERATING MANUAL ......6、BACK UP PROCEDURE ......7、RECORDING PROCEDURE 8、4CH CONTINOUS RECORDING HOURS ON 400GB HDD DVR VIEWER USER GUIDE ...... 9、 ... 10、REMOTE CONTROL USER GUIDE(Optional)

  • Page 6: Features

    1.FEATURES : 1、Duplex(Recording, Playback) 2、Up to 60fps Recording Speed. 3、USB flash disk backup. 4、Adjust Up/Down/Left/Right screen position. 5、Video Input Signal: N T S C / P A L. 6、Video Compression: Modified MJPEG. 7、Manual, Motion & Programmed. 8、Motion Detection with Adjustable Time Duration. 9、Search Data by Date and Time.

  • Page 7: Specifications

    2.SPECIFICATIONS NTSC/PAL Video Format Embedded RTOS Operating System RCA x 4 Video Input RCA x 1 Audio Input RCA x 1 Video Output RCA x 1 Audio Output Multi-Language Display NTSC Display Frame 120 f (4x30 f 100 fps (4x25 fps) Recording Frame NTSC 60 fps...

  • Page 8: Installation

    3.INSTALLATION: Rear Panel VIDEO IN AUDIO VIDEO DC12V (1)Video Output : RCA x 1 (2)Video IN : RCA x 4 (3)Audio Input : RCA x 1 (4)Audio Out : RCA x 1 USB Port (6)Power Input : For safety reasons, always use the original factory power adaptor attached DC-12V / 3A.

  • Page 9: Front Control Panel

    4.FRONT CONTROL PANEL： (12) ( 1 ) ( 8 ) ( 3 ) ( 4 ) ( 6 ) ( 7 ) ( 5 ) ( 2 ) (10) (11) (1) Power indicator. (2) HDD indicator. (3) Up Arrow/CH1: Camera 1 full screen display. (4) Left Arrow/CH2: Navigate left through menu options/ Camera 2 full screen display.

  • Page 10: Operating Manual

    5.OPERATING MANUAL (MAIN MENU) Setup Camera Record Motion Detection Screen Audio System Search Language English Exit 2008/12/09 13:35:27 Press to select items to enter Press MENU to exit. Camera Setup Camera Channel Channel Name Display Brightness Contrast Saturation 2008/12/09 13:36:56 Press to select items to enter...
  • Page 11 Record Setup Record Record Speed Normal u Record Quality Event Rec Duration Record Schedule 2008/12/09 13:37:42 Press to select items to enter Press MENU to exit. (1) Record Speed： Set the number of frame per second (fps). NTSC：default: 15 fps，maximum total frame: 60 fps. PAL ：default: 12 fps，maximum total frame:50 fps.
  • Page 12 Motion Detection Setup Motion Detection Channel Sensitivity Alarm Duration Motion Area Smart Record 2008/12/09 13:39:05 Press to select items to enter Press MENU to exit. (1) Channel： The diagram above shows Channel 1. (2) Sensitivity： To set Off, or 1 to 4， default: Off. (3) Alarm Duration：...
  • Page 13 Audio Setup Audio Record Mute Input Volume Ouput Volume 2008/12/09 13:40:14 Press to select items to enter Press MENU to exit. (1) Record：On/Off (2) Mute：On/Off (3) Input Volume：Adjust input volume (4) Output Volume：Adjust output volume. System Setup System Hard Disk Setup Password change Time Set Event List...
  • Page 14 (1)Hard Drive Disk Hard Disk Setup Overwite Enable Format HDD Size: 238463MB UsekO: 304MB Used: 238463MB Hitachi HDP7250 2008/12/09 13:41:27 (1.1) Overwrite Enable: Enable overwrite when HDD capacity is full: Yes: When HDD overwrite is taking place, the data is stored in duration of 4 hours per event and being recorded continuously.
  • Page 15 (2).Password Change：Password Setup Password Change Current Password 1 2 3 4 5 6 7 8 9 0 - = + q w e r t y u I o p [ ] a s d f g h j k l ; S h i f t z x c v b n m , .
  • Page 16 (4). Event List: Event List 019 08/12/09 13:44:11 MOT oxxx  018 08/12/09 13:35:17 REC START 017 08/07/09 13:35:16 POWER ON 016 08/07/09 11:17:24 POWER OFF 015 00/07/01 08:16:37 REC START 014 00/01/01 08:16:37 REC STOP 013 00/01/01 08:15:42 REC START 012 00/01/01 08:15:42 REC STOP ‚...
  • Page 17 Time Search Time Search Start 2000/01/01 08:00:29 2008/12/09 13:45:19 2000/01/01 08:00:29 (UP,Down)SET (Left,Right)SELECT (MENU)EXIT (PLAY)PLAY 2008/12/09 13:45:44 (1) Set Search of time, then press “play” button to start playback. (2) Playback: ＊Press button for fast forward. Press one more time for faster speed.

  • Page 18: Back Up Procedure

    6.BACK UP PROCEDURE Start 2008/12/09 13:45:18 2008/12/09 13:45:18 Size USB BACKUP MODE (CH1)Start Time, (CH2)End Time (CH4)Start Backup, (STOP)Exit 2008/12/09 13:45:18 (1) Stick USB flash Drive into USB port ”button to enter event list and play back you choose. Press“ ”button to enter backup menu.

  • Page 19: Ch Continous Recording Hours On 400Gb Hdd

    8. 4CH CONTINOUS RECORDING HOURS ON 400GB HDD ＊ The chart of estimated record time listed below is for reference only. The length of time recorded can be varied due to variation in image size may be somewhat different. Recording Results in NTSC Format 60 fps 30 fps...

  • Page 20: Dvr Viewer User Guide

    9.DVR VIEWER USER GUIDE 1.Playback Recorded File (1.1) Start VVF SLPlayer (1.2) Point the cursor in the screen and right-click “Open File”. Pick and choose the file you want to view in ( . v vf format) and play. 2、Capture an image (2.1) During the playback of the specific file, click “Pause”, located on the bottom of the screen.
  • Page 21 3.Convert File to AVI Format (3.1) Point the mouse cursor to the screen, and press the right button on the mouse, pick and choose「Export」/「AVI」 (3.2) Set Input/Output File 、Compression、Export Channel and Audio. (3.3) Click “OK” to start converting file to AVI format. 4、Option (1) Always on top：The sub window always stays on top.

  • Page 22: Remote Control User Guide(Optional)

    10.REMOTE CONTROL USER GUIDE (OPTIONAL) CH1 Display CH2 Display Record CH3 Display CH4 Display Quad Display/ Auto Switching Mute Menu Left Right Fast Reverse Down Fast Forward Play Pause Stop Record/ Stop Playback...
  • Page 23 4CH STANDALONE DVR USER MANUAL H12C462S01...
