Dresser (8299) - Assembly and Operation Manual
Congratulations on purchasing an MDB Family product. This product will provide many years of service
if you adhere to the following guidelines for assembly, maintenance, and operation. This product is
for residential use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assembling
the product in addition to the Allen wrench included in the hardware box. Do not use power screwdriv-
ers. All of our products are made from natural woods. Please understand that natural woods have color vari-
ations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARD-
WARE. YOUR MODEL MAY LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC VARI-
ATIONS.
revised 11DEC2013
Page 1
Advertisement
Related Manuals for Million Dollar Baby Dresser
Summary of Contents for Million Dollar Baby Dresser
- Page 1 Dresser (8299) - Assembly and Operation Manual Congratulations on purchasing an MDB Family product. This product will provide many years of service if you adhere to the following guidelines for assembly, maintenance, and operation. This product is for residential use only. Any institutional use is strictly prohibited.
- Page 2 PARTS G. Back Top Bar H. Back Bottom Bar J. Back Center Bar K. Front Top Bar B. Right Side Panel A. Left Side Panel L. Front Bottom Bar M. Top Panel D. Right Bottom Panel C. Center Panel N. Back Board (2) R.
- Page 3 U. Drawer Front Panel (3) V. Drawer Back Panel (3) HARDWARE H5. Cam H2. 5/8” Small H4. Metal H3. 1/2” Small Wood H1. 1-1/2” Wood Lock (18) Wood Screws (8) Pin (4) Screw (56) Screw (16) H10. Knob H6. Cam Bolt (18) H7.
- Page 4 STEP 2. Set up side panels (A and B). A. Left Side Panel B. Right Side Panel H17. Left Panel Glide STEP 3. Set up all bars (G, H, J, K and L). G. Back Top Bar P. Support Block L.
- Page 5 STEP 4. Attach center panel (C) to right bottom panel (D). D. Right Bottom Panel C. Center Panel Rotate H5 to secure. STEP 5. Attach front bars (K and L) and center panel assemble to right side panel (B). B. Right Side Panel K.
- Page 6 STEP 6. Insert wood dowels H12 to top support bar (Q). Q. Top Support Bar Attach back bars (G, H and J) and top support bar (Q) to right side panel (B). STEP 7. Then, slide in the top panel (M). * Make sure the wood dowel (H11) on the support block (P) inserts into the...
- Page 7 5/8” wood screws with washer head (H18). N. Back Board N. Back Board Attach the door (E) to the STEP 10. dresser. And, place the shelf (F) inside the dresser. E. Door F. Shelf H9. Knob E. Door H7. Door Hinges Page 7...
- Page 8 STEP 11. R. Left Drawer Panel S. Right Drawer Panel U. Drawer Front Panel T. Drawer Bottom Board Rotate H5 to secure. V. Drawer Back Panel H9. Knob H16. Left Drawer Glide H15. Right Drawer Glide Page 8...
- Page 9 STEP 12. Slide the drawers into the dresser. STEP 13. FURNITURE ANTI-TIPPING KIT INSTALLATION Serious or fatal crushing can occur when furniture tips over on children. To help prevent tip-over, follow the steps below to install this anti-tipping strap. WARNING Serious or fatal crushing injuries can occur from furniture tip-over.
- Page 10 13b. Install the strap on the wall with long screw and washer. 13c. Install the other end of strap on the back of dresser with short screw and washer into the wood framing of the dresser. Page 10...
-
Page 11: One-Year Limited Warranty
KEEP THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. Finish ONE YEAR LIMITED WARRANTY: We will replace any missing parts at the time of purchase or any defective item within a one year period from the date of original purchase. Please keep your receipt so that we may process your warranty READ ALL INSTRUCTIONS BEFORE ASSEMBLING THIS request.
