Detergent dispenser
1. Press the release lever in the prewash compartment downward
and remove the drawer.
2. Remove the insert (model "A" and "B1") or siphon (model
"B2") from the softener compartment.
Remove the insert for liquid detergents.
For model "A" only remove also the siphon from the chlorine
bleach compartment.
3. Wash all the parts under running water.
4. Replace the parts and refit the detergent dispenser. Insert the
detergent dispenser in the washing machine.
Mesh Filter in the Water Connection
Check and clean regularly.
For washing machines with a straight inlet hose
1. Turn off the tap and unscrew the water inlet hose from the tap.
2. Clean the internal mesh filter and screw the water inlet hose
back onto the tap.
3. Now unscrew the inlet hose on the rear of the washing machine.
4. Pull off the mesh filter from the washing machine connection
with universal pliers and clean it.
5. Refit the mesh filter and screw the inlet hose on again.
6. Turn on the tap and ensure that the connections are completely
water-tight.
For washing machines with Water Stop hose
1. Turn off the tap and unscrew the Water Stop hose from the tap.
2. Clean the internal mesh filter and screw the water inlet hose
back onto the tap.
3. Turn on the tap and ensure that the connection is completely
water-tight.
A
A
B1
B2
