Message Format and Delivery Mechanism

4.0 Message Format and Delivery Mechanism
There are two message queues (in-bound and out-bound) for the user application to send control
messages and to receive response and event messages, respectively. The message queues are created
from pre-allocated memory buffers in consideration of maximum message size and total number of
messages. The entire message header and content are copied to/from the buffers in the message
queue during message transmitting and receiving. The memory used for messaging is not shared be-
tween the message sender and the receiver.
4.1

Message Functions

Three functions are provided to send and receive messages.
XStatus_t xMsgSend (void *pMsgBuf);
Description
Input
Output
Return
Caution
Note
XStatus_t xMsgReceive (void *pMsgBuf, UINT16 channel, int timeout);
Description
Input
Output
Return
Caution
XStatus_t xMsgWrite (void *pMsgBuf); (Sheet 1 of 2)
Description
Input
Output
20
Sends a control message to the in-bound message queue
– Pointer to the message buffer.
pMsgBuf
None
• — If successful
XSUCC
• XERROR — If errors
Message buffer requires 4-byte alignment.
Message buffer can be used for any other purpose after sending.
Receives acknowledgement or event from the outbound message queue.
• pMsgBuf – Pointer to the message buffer
• – Channel number. (Reserved for future extension)
channel
• timeout – Waiting flag
— XWAIT_NONE — If return immediately
— XWAIT_FOREVER — If never time out (no other values are valid.)
None
• XSUCC — If successful
• XERROR — If errors
Message buffer requires 4-byte alignment. The receiving buffer must fit the maximum
message size. Cannot be called from ISR.
Posts a message (e.g. an user defined external event message) to the out-bound queue so
that it can be retrieved by
XMsgReceive()
pMsgBuf — Pointer to the message buffer.
None
.
