- Page 1 PZMIII/PZMTIII Precision Zoom Stereo Microscope INSTRUCTION MANUAL Serial No._____________________ 101212 World Precision Instruments...
-
Page 3: Table Of Contents
Adusting a Microscope ........................ 4 System Diagram ..........................5 OPERATING INSTRUCTIONS ......................6 MAINTENANCE ............................ 7 ACCESSORIES ............................8 SPECIFICATIONS ..........................9 PZMIII Eyepieces and Objectives .................... 9 APPENDIX: BOOM STAND ASSEMBLY ..................10 Focus Mount ..........................10 WARRANTY ............................11 Claims and Returns ........................11 Repairs ............................11 Copyright ©... - Page 4 World Precision Instruments...
-
Page 5: About This Manual
This symbol indicates a WARNING. Warnings alert you to actions that can cause personal injury or pose a physical threat. Please read these carefully. NOTES and TIPS contain helpful information. Fig. 1—The PZMIII binocular microscope is shown on its standard post stand. World Precision Instruments... -
Page 6: Introduction
Zooming is smooth and effortless, controlled by a spring-loaded knob. The PZMIII’s compact size and light weight make it more stable and easily manipulated on a boom stand. The binocular PZMIII can be eaily upgraded to a trinocular microscope at any time by attaching the optional Photo/Video Module. -
Page 7: Instrument Description
Light Path Base Selector Bar* Fig. 2—This image identifies the parts of the binocular PZMIII. The trinocular version (PZMTIII) has the video/photo port and the light path selector bar, and it can accept the camera with a C-Mount coupler. *NOTE: “True trinocular” microscopes do not have the Light Path Selector Bar. -
Page 8: Setup
Setup Remove the microscope from the case and check that the following parts are all present and undamaged: • Microscope and Base • WFH 10x Wide-Field Eyepieces (two) • Paired Eyeguards (two) • Stage Plate • Instruction Manual Unscrew the protective cap on the bottom of the microscope head. Refer to the “Instrument Description”... -
Page 9: System Diagram
Fan Stand 502004 502005 503102 501353 Ring Light Articulated Arm 504134 Fiber Optic Light with Table Clamp: 502007 Boom/Clamp Stand NOVA Optional Wall Mount: 502163 502006 Fig. 3—This diagram shows many of the options available for the PZMIII. World Precision Instruments... -
Page 10: Operating Instructions
Move the microscope to the desired height (working distance) according to lens (auxiliary objective lens) attached (see “PZMIII Eyepieces and Objectives” on page 9 for working distance). Then, re-tighten the knobs. Interpupilary Distance Adjustment–Looking through the eyepieces with both eyes, adjust the interpupillary distance by sliding the two eyepiece tubes with both hands until a single image is observed. -
Page 11: Maintenance
PZMIII/PZMTIII MAINTENANCE This instrument should be kept in a cool, dry place free from direct sun, dust, alkali and acid fumes, as well as moisture. Do not disassemble any of the lenses since they have all been properly aligned at the factory. -
Page 12: Accessories
Articulated Arm and Table Clamp w/o Focus Mount (requires 502009 Focus Mount for PZMIII) 501355 Universal Focus Mount for 76 mm PZMIII (Required for BS, AAC, BBS, and BCS) (5/8” pin) 502160 Lighted Fan Base, Fluorescent base, Tungsten Halogen beam 501369 10×... -
Page 13: Specifications
Diopter Adjustment ................±5 Diopter (both eye tubes) Microscope Body......................Rotatable 360° Auxiliary Lenses Total Magnification ......................2X–225X Biggest Field Of View .......................∅110mm Working Distance ......................26–287mm PZMIII Eyepieces and Objectives 10x Eyepiece 15x Eyepiece 20x Eyepiece 25x Eyepiece Field (mm) Field (mm) -
Page 14: Appendix: Boom Stand Assembly
APPENDIX: BOOM STAND ASSEMBLY Remove all the parts from the box. Unscrew the hex screw from Vertical Post. The Vertical Post should have a cross block attached to it. Screw Vertical Post and Base together using the hex screw. (Insert the screw from bottom of the base into the threaded section of Vertical Post.) Insert the Horizontal Bar into the... -
Page 15: Warranty
WPI shall not be liable for any damage to data or property that may be caused directly or indirectly by use of this product. - Page 16 International Trade Center, 175 Sarasota Center Blvd., Sarasota FL 34240-9258 Tel: 941-371-1003 • Fax: 941-377-5428 • E-mail: sales@wpiinc.com 1 Hunting Gate, Hitchin, Hertfordshire SG4 0TJ Tel: 44 (0)1462 424700 • Fax: 44 (0)1462 424701 • E-mail: wpiuk@wpi-europe.com Germany Zossener Str. 55, 10961 Berlin Tel: 030-6188845 •...
