Remove this HARDWARE IDENTIFICATION CHART,
EXPLODED DRAWING and PART LIST from the user's
manual. Save this page for future reference.
HARDWARE IDENTIFICATION CHART
The chart below is provided to help you identify the small parts used in assembly. The number in parenthesis
below each part refers to the key number of the part. The second number refers to the quantity used in assembly.
Note: Some small parts may have been pre-assembled for shipping purposes. If a part is not found in the
part bag, check to see if it has been pre-assembled.
3/8" Washer (67)–2
Star Washer (103)–8
Bracket Washer (70)–4
Upright Screw (63)–4
Handrail Bolt (93)–2
Resistance Bracket Bolt (107)–4
Handrail Nut (4)–2
Screw (75)–8
