TECOM AR1061 User Manual

1-port adsl2+ router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AR1061
1-port ADSL2+ Router
User's Manual
ISO-9001
ISO-9001
P a g e 1 o f 5 9
TECOM Copyright, 2007
© All Rights Reserved,
M/C: TDSL-1061AR-UM
DC: 960910B-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR1061 and is the answer not in the manual?

Questions and answers

Related Manuals for TECOM AR1061

Summary of Contents for TECOM AR1061

  • Page 1 AR1061 1-port ADSL2+ Router User’s Manual TECOM Copyright, 2007 © All Rights Reserved, ISO-9001 ISO-9001 M/C: TDSL-1061AR-UM DC: 960910B-2 P a g e 1 o f 5 9...
  • Page 2 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual FCC Statement This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions in this manual, may cause interference to radio communications. This equipment as been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against radio interference when operated in a commercial environment.

  • Page 3: Table Of Contents

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Contents Introduction ......................4 System Overview ....................4 General Description ......................4 Specifications ........................5 Hardware Installation ..................... 6 Package Content ......................... 6 Hardware Setup Procedure ....................6 The I/O Port Definition ......................7 The LED Indicator Definition ....................

  • Page 4: Introduction

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 1 Introduction The AR1061 is an ADSL2+ router that can be used to connect to a twisted copper pair ADSL2+ broadband network. The AR1061 is backwards compatible to all ADSL modulation technology including G.lite, G.dmt, T1.413, ADSL2 and ADSL2+. AR1061 also supports various internet service provider networks via common WAN protocol such as PPPOE, PPPOA, Bridge/MER 1483 modes.

  • Page 5: Specifications

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 2.2 Specifications ADSL Standard ITU-T G.992.1(G.dmt) ANSI T1.413 Issue 2 G.992.2 (G.lite) G.994.1 (G.hs) Auto-negotiating rate adaptation ADSL2 G.dmt.bis (G.992.3) ADSL2 G.lite.bis (G.992.4) ADSL2+ (G.992.5) Software Features RFC-1483/2684 LLC/VC-Mux bridged/routed mode RFC-1577 Classical IP over ATM...

  • Page 6: Hardware Installation

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 3 Hardware Installation 3.1 Package Content Upon opening the gift box of AR1061 Router, you will find the following items. 1 x AR1061 Router Main Unit 1 x 15VDC/500mA power adaptor 1 x CD-ROM...

  • Page 7: The I/O Port Definition

    PC systems, you have to prepare a low-density Ethernet switch or hub for expansion purpose. Connect the AC Power Adaptor (15V) and then the AR1061 Router will start to run and connect the Home local network to the Broadband world.

  • Page 8: The Led Indicator Definition

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 3.4 The LED Indicator Definition The following table is a description of the meaning of the different LEDs on the AR1061: Color Status Description Power Off Steady Power On Green POWER Blinking or...
  • Page 9 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Page 9 of 59...

  • Page 10: Software Configuration

    ADSL Line mode : Auto-detect. • 4.1 Set your PC’s Ethernet port AR1061 is an ADSL Router which support DHCP and default enable. You also can set your computer IP Address as 192.168.1.x within the same subnet as AR1061 (default IP address is 192.168.1.1) and netmask (default netmask is 255.255.255.0).

  • Page 11: Lan Configuration

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual This page displays the AR-1061 Router current status and settings. This information is read-only except for the PPPoE/PPPoA channel for which user can connect/disconnect the channel on demand. Click the “Refresh” button to update the status...

  • Page 12: Wan Configuration

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description IP Address The IP address your LAN hosts use to identify the device’s LAN port. Subnet Mask LAN subnet mask. Secondary IP The secondary IP address assignment for the device’s LAN port.
  • Page 13 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual the channel modes, the setting is quite different accordingly. Please refer to the section – Channel Mode Configuration for details. Function buttons in this page: Click Add to complete the channel setup and add this PVC channel into configuration.
  • Page 14 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Virtual Path Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table. Virtual Channel Identifier. This is read-only field and is selected on the Select column in the Current ATM VC Table.
  • Page 15 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Sustained Cell Rate, measured in cells/sec., is the average cell rate over the duration of the connection. Maximum Burst Size, a traffic parameter that specifies the maximum number of cells that can be transmitted at the peak cell rate.

  • Page 16: Services Configuration

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description ADSL modulation Choose preferred xDSL standard protocols. G.lite : G.992.2 Annex A G.dmt : G.992.1 Annex A T1.413 : T1.413 issue #2 ADSL2 : G.992.3 Annex A ADSL2+ : G.992.5 Annex A...
  • Page 17 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual DHCP Server Configuration By default, the device is configured as a DHCP server, with a predefined IP address pool of 192.168.1.33 through 192.168.1.254 (subnet mask 255.255.255.0). Page 17 of 59...
  • Page 18 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Function buttons in this page: Field Description IP Pool Range Specify the lowest and highest addresses in the pool. Max Lease Time The Lease Time is the amount of time that a network user is allowed to maintain a network connection to the device using the current dynamic IP address.
  • Page 19 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual DHCP Relay Configuration Some ISPs perform the DHCP server function for their customers’ home/small office network. In this case, you can configure this device to act as a DHCP relay agent. When a host on your network requests Internet access, the device contacts your ISP to obtain the IP configuration, and then forward that information to the host.
  • Page 20 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Field Description Select this item if you want to use the DNS servers obtained by the Attain DNS Automatically WAN interface via the auto-configuration mechanism. Set DNS Manually Select this item to configure up to three DNS IP addresses.
  • Page 21 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual On the Dynamic DNS page, configure the following fields: Field Description Enable Check this item to enable this registration account for the DNS server. DDNS provider There are two DDNS providers to be selected in order to register your device with: DynDNS and TZO.
  • Page 22 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual column of the Dynamic DNS Table. Click Remove button to remove the selected registration from the configuration. Firewall Configuration Firewall contains several features that are used to deny or allow traffic from passing through the device.
  • Page 23 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields on the second setting block: Field Description Deny or allow traffic when matching this rule. Rule Action Direction Traffic forwarding direction. Protocol There are 3 options available: TCP, UDP and ICMP. Src IP Address The source IP address assigned to the traffic on which filtering is applied.
  • Page 24 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.5.1.4 MAC Filtering The MAC filtering feature allows you to define rules to allow or deny frames through the device based on source MAC address, destination MAC address, and traffic direction. Fields on the first setting block:...
  • Page 25 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual The source MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in Src MAC Address the MAC address space and are considered as don’t care. Dst MAC Address The destination MAC address. It must be xxxxxxxxxxxx format. Blanks can be used in the MAC address space and are considered as don’t care.
  • Page 26 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Enable Port Check this item to enable the port-forwarding feature. Forwarding Protocol There are 3 options available: TCP, UDP and Both. Enable Check this item to enable this entry.
  • Page 27 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Enable DMZ Check this item to enable the DMZ feature. DMZ Host IP Address IP address of the local host. This feature sets a local host to be exposed to the Internet.
  • Page 28 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual making requests to join and leave multicast groups, or a multicast router sending multicast packets to multicast group on the WAN side. When a host wishes to join a multicast group, it sends IGMP REPORT message to the device’s IGMP downstream interface.
  • Page 29 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Function buttons in this page: Apply Changes Click to save the setting to the configuration. Undo Discard your settings. RIP Configuration RIP is an Internet protocol you can set up to share routing table information with other routing devices on your LAN, at your ISP’s location, or on remote networks connected to...
  • Page 30 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields on the first setting block: Field Description Enable/disable RIP feature. Function buttons for the second setting block in this page: Apply Changes Click to save the setting of this setting block to the system configuration...

  • Page 31: Advance Configuration

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.6 Advance Configuration ARP table You can see the show list of learned MAC addresses through ARP in this page. Bridging You can enable/disable Spanning Tree Protocol and set MAC address aging time in this page.
  • Page 32 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Set the Ethernet address ageing time, in seconds. After [Ageing Time] seconds Ageing Time of not having seen a frame coming from a certain address, the bridge will time out (delete) that address from Forwarding Database (fdb).
  • Page 33 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Check to enable the selected route or route to be added. Enable Destination The network IP address of the subnet. The destination can be specified as the IP address of a subnet or a specific host in the subnet.
  • Page 34 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Delete a selected destination route on the Static Route Table. Show Routes Click this button to view the DSL device’s routing table. The IP Route Table displays, as shown in Figure. SNMP Configuration...
  • Page 35 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description System Description System description of the DSL device. System Contact Contact person and/or contact information for the DSL device. System Name An administratively assigned name for the DSL device.

  • Page 36: Diagnostic

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Remote Access The Remote Access function can secure remote host access to your DSL device from LAN and WLAN interfaces for some services provided by the DSL device. Fields in this page: Field...
  • Page 37 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual the network. A ping command sends a message to the host you specify. If the host receives the message, it sends messages in reply. To use it, you must know the IP address of the host you are trying to communicate with and enter the IP address in the Host Address field.
  • Page 38 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Select PVC Select the PVC channel you want to do the loop-back diagnostic. The ATM OAM flow type. The selection can be F5 Segment or F5 End-to-End.
  • Page 39 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Diagnostic Test The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. Page 39 of 59...

  • Page 40: Admin

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Select the Internet The available WAN side interfaces are listed. You have to select one for the WAN Connection side diagnostic. 4.8 Admin Commit / Reboot Whenever you use the Web configuration to change system settings, the changes are initially placed in temporary storage.
  • Page 41 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Backup/Restore This page allows you to backup and restore your configuration into and from file in your host. Password The first time you log into the system, you use the default password. There are two-level logins: 1234 and user.
  • Page 42 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description User Name Selection of user levels are: admin and user. Old Password Enter the old password for this selected login. New Password Enter the new password here.
  • Page 43 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description ACL Capability Enable/disable the ACL function Enable Check to enable this ACL entry Interface Select the interface domain: LAN or WAN IP Address Enter the IP address that allow access to this device.
  • Page 44 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: Field Description Current Time The current time of the specified time zone. You can set the current time by yourself or configured by SNTP. Time Zone Select The time zone in which the DSL device resides.
  • Page 45 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Fields in this page: ACS Field Description ACS URL. For example, http://10.0.0.1:80 https://10.0.0.1:443 User Name The username the DSL device should use when connecting to the ACS. Password The password the DSL device should use when connecting to the ACS.

  • Page 46: Statistics

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Port as follows: http://Device_IP:Port/Path Port The port of the device ConnectionRequestURL. Note: Please enable the Auto-Execution to enable the TR-069 process Statistics The DSL device shows the different layer of network statistics information.
  • Page 47 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Page 47 of 59...

  • Page 48: Bridge Mode

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual Channel Mode Configuration ADSL router supports multiple channel operation modes. This section will show procedures to configure the router. 4.10 Bridge Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “1483 Bridged”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM setting.

  • Page 49: Mer(Mac Encapsulating Routing) Mode

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.11 MER(Mac Encapsulating Routing) Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “1483 MER”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM setting.

  • Page 50: Pppoe Mode

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.12 PPPoE Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “PPPoE”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM setting. 3. Enter user/password from your ISP.

  • Page 51: Pppoa Mode

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.13 PPPoA Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “PPPoA”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM setting. 3. Enter user/password from your ISP.

  • Page 52: 1483 Routed Mode

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 4.14 1483 Routed Mode 1. Open the WEB page at “WAN interface/Channel Configuration”. 2. Select the Channel Mode to “1483 Routed”. Set the parameters VPI/VCI and Encapsulation mode according to the CO DSLAM setting.

  • Page 53: Appendix

    AR1061 1-port Ethernet ADSL2+ Router User‘s Manual 5 Appendix Appendix A: Protocol Stacks A.1 1483 Bridged Model Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 Bridged Channel Mode Scenario...
  • Page 54 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual A.2 1483 MER Model Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 MER Channel Mode Scenario Page 54 of 59...
  • Page 55 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual A.3 PPPoE Model PPPoE PPPoE Ethernet Ethernet Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-B) (1483-B) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS PPPoE Channel Mode Scenario Page 55 of 59...
  • Page 56 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual A.4 PPPoA Model Ethernet Ethernet AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS PPPoA Channel Mode Scenario Page 56 of 59...
  • Page 57 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual A.5 1483 Routed Model Ethernet Ethernet LLC/SNAP LLC/SNAP (1483-R) (1483-R) AAL5 AAL5 100BaseT 100BaseT xDSL xDSL SONET/SDH SONET/SDH ATU-R DSLAM BRAS 1483 Routed Channel Mode Scenerio Page 57 of 59...

  • Page 58: Appendix B: Mapping Pvcs To Vlans

    PVC to be configured as a bridging interface and used in conjunction with a VLAN. Figure B.1 illustrates the how the AR1061 Router adds a VLAN ID and tag to packets subject to PVC-VLAN mapping. In this example, vc3 is mapped to VLAN 20. The AR1061 Router adds VLAN ID 20 and tag 8100 to packets from vc3.
  • Page 59 AR1061 1-port Ethernet ADSL2+ Router User‘s Manual ATM Network Ethern DATA Header Header Vc3 mapped to VLAN 20 AR1061 Ethern VLAN ID Tag Type DATA Header Header 0x8100 Ether Switch Ethern DATA Header Header VLAN 20 VLAN 10 Figure B.1 Adding a VLAN ID and tag to packets from a PVC...
