Summary of Contents for Planar IX2850
- Page 1 IX2850 LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product ............................7 Rear View of the Product ..............................8 Quick Installation ................................9 Basic Operation and Calibration/Reset Instructions..................10 Advanced Operation—OSD Menu......................... 12 Supporting Timing Modes ............................20 Technical Information ..............................21 Wall-Mount Installation Instructions........................22 Troubleshooting................................23 Planar Support ................................24... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the IX2850 LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 5: Unpacking Instructions
Unpacking Instructions Remove the LED LCD Monitor out of the package and take off the plastic bag and Polystyrene Foam. Remove base from plastic bag and attach to base. Adjust the display between -5° and 20°. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. - Page 6 Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à...
-
Page 7: Package Overview
Package Overview LED LCD Monitor Base Power Cord DisplayPort Cable HDMI Cable USB 3.0 Cable (A to B) User’s Guide... -
Page 8: First Setup
First Setup Install the stand base 1. Lay the LED LCD Monitor flat on a table with the LED screen face down. To prevent the monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. 2. -
Page 9: Front View Of The Product
Front View of the Product ①②③④ ⑤⑥ ① OSD Turn On/ Off ② Scroll Down/ Adjust Decrease/ Audio/ Preset * ③ Scroll UP/ Adjust Increase/ PIP (PBP)/Swap * ④ Input select/ Confirm Selection/ Auto * ⑤ Power On/ Off ⑥ LED Indicator * Hot keys Instructions please see “Using the OSD Menu”... -
Page 10: Rear View Of The Product
Rear View of the Product ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① Power Input ② DVI Input (DVI 24 pin) ③ HDMI-2 input (HDMI 19 pin) ④ HDMI-1 input (HDMI 19 pin) ⑤ DisplayPort-2 Input (DisplayPort 20 pin) ⑥... -
Page 11: Quick Installation
Quick Installation Connect either VGA, DVI, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note. The monitor ships with DisplayPort and HDMI cables only. DVI-dual link, or VGA cable may be sourced separately from a cable supplier. -
Page 12: Basic Operation And Calibration/Reset Instructions
Basic Operation and Calibration/Reset Instructions Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press button on the front. The power LED indicator light will be blue when the LED LCD Monitor is on. - Page 13 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Power Button Locked” message for 3 seconds and the message will disappear automatically.
-
Page 14: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲ or ▼ to select the desired OSD menu. Press 2 to confirm or reach the next sub-menu. To exit press 1. Short Cuts Function from the button(s) Input: When Input Select is pressed, change Input signal to DisplayPort1, DisplayPort 2, HDMI1,... - Page 15 Picture: To manually adjust the Picture Format, Contrast, Brightness, Sharpness, Over Drive and ECO Mode of screen image. • Picture Format: To select the video mode from 16:9, 4:3 or 1:1. • Contrast: To adjust the foreground white level of screen image. ▲: increase contrast, ▼: decrease contrast.
- Page 16 PiP/PbP: PiP/PbP button allows you to watch two screens from different sources at the same time. (PiP is picture in picture; PbP is picture by picture) • PiP/PbP Mode: Toggle to enable/disable PiP/PbP function. Main Input. Identifies main source (greyed out) •...
- Page 17 In PbP Mode 2PbP. Splits the screen left and right equally. In order to achieve full screen on each side, recommended resolution is 1920 x 2160; however, this is a custom resolution. Check your video card to see if custom resolution is supported. If not supported, black bars on top and bottom will result.
- Page 18 Audio Adjust: To adjust the audio functions. • Volume: To adjust the volume of speaker output. • Mute: To turn the Mute ON/OFF. • Audio Source: Default is main source, but can be manually switched in PiP and PbP mode.
- Page 19 Color: To select the color for improving brightness and color saturation between Warm, Normal, Cool, User Define, Preset Mode, and Blue Light Reducer. • Warm: Adds green to screen image for a darker color. • Normal: Adds red to screen image for warmer white and richer red. •...
- Page 20 Language: Allows user to choose from available languages. OSD Setting: To manually adjust the Horizontal and Vertical OSD position, Transparency and OSD Time Out. • Horizontal: To horizontally adjust the OSD position. • Vertical: To vertically adjust the OSD position. •...
- Page 21 Setup Menu: To set up Auto, H./ V. Position, Phase, Clock, DisplayPort, Reset and Information. • Auto: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. Size) of the screen. • H. Position: To adjust the horizontal position of the screen. •...
-
Page 22: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION STANDARD RESOLUTION 720 x 400 @ 70Hz VESA 1280 x 1024 @ 75Hz 640 x 480 @ 60Hz VESA 1440 x 900 @ 60Hz 640 x 480 @ 67Hz VESA 1440 x 900 @ 75Hz VESA 640 x 480 @ 72Hz VESA... -
Page 23: Technical Information
Technical Information Panel 28” TFT (with LED backlight) Power Management On: 45 Watts (typical), 75 Watts (maximum) Standby Mode: < 1.2 Watt (USB 3.0) Off: < 0.5 Watt Displayable Resolution UHD 3840 x 2160 max. Vertical Frequency 60Hz max. Compatibility VGA Support up to 2048 x 1152 HDMI/ DVI-D Support up to 3840 X 2160 @ 30Hz DP support up to 3840 x 2160 @ 60Hz (non-interlaced) -
Page 24: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Preparing to Install the Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm purchased separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1. -
Page 25: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power adapter and the power supply is firmly connected to the LED LCD Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. -
Page 26: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 27 2014 2001132452T 020-1265-00A...
