Planar IX2851 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IX2851
LED LCD Monitor

Advertisement

Table of Contents
loading

Related Manuals for Planar IX2851

Summary of Contents for Planar IX2851

  • Page 1 IX2851 LED LCD Monitor...
  • Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced, translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.

  • Page 3: Table Of Contents

    TECHNICAL SUPPORT (FAQ) ..................18 TECHNICAL SUPPORT (FAQ) .................. 19 ERROR MESSAGE & POSSIBLE SOLUTION ............19 APPENDIX ..........................20 SPECIFICATIONS ......................20 FACTORY PRESET TIMING TABLE ................. 21 CONNECTOR PIN ASSIGNMENT ................22 WALL MOUNTING (OPTIONAL) ................25 PLANAR SUPPORT ......................26...

  • Page 4: For Your Safety

    | FOR YOUR SAFETY Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: For Your Safety (French)

    | POUR VOTRE SÉCURITÉ Avant d'utiliser le moniteur, veuillez lire attentivement le présent manuel. Ce manuel doit être conservé pour référence future. Déclaration FCC d'interférence de radiofréquence classe B AVERTISSEMENT : (POUR LES MODÈLES CERTIFIÉS FCC) REMARQUE : Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de classe B, conformément à...

  • Page 6: Precautions

    PRECAUTIONS • Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. • Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.
  • Page 7 PRÉCAUTIONS • Ne pas utiliser le moniteur près de l'eau, par exemple près d'une baignoire, d'un lavabo, d'un évier, d'un bac à linge, d'une piscine ou dans un sous-sol humide. • Ne pas placer le moniteur sur un chariot, un support ou une table. Si le moniteur tombe, il peut blesser quelqu'un et causer de graves dommages à...

  • Page 8: Weee Declaration

    WEEE DECLARATION Disposal of Waste Equipment by Users in Private Household in the European Union. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.The separate collection and recycling of your waste...

  • Page 9: Before You Operate The Monitor

    • Recommended Resolutions: 3840*2160@60Hz • LED Backlight, energy efficient • Ergonomic Design • Space Saving, Compact Case Design PACKAGE LIST The product package should include the following items: IX2851 LED LCD Monitor User's Guide Stand Monitor Power Cable DP Cable...

  • Page 10: Installation Instructions

    INSTALLATION INSTRUCTIONS STAND BASE INSTALLATION The monitor is supplied complete with a stand.If you prefer to wall mount the monitor, please follow the instructions on page 21 to remove the stand. Be sure to include the stand with the monitor if it is necessary to return the unit. CAUTION •...

  • Page 11: Adjusting The Viewing Angle

    ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle. •...

  • Page 12: Controls And Connectors

    CONTROLS AND CONNECTORS POWER CORD Power Source: 1. Make sure that the power cord is the correct type required in your area. 2. This LCD monitor has an internal universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area (No user adjustment is required.) 3.

  • Page 13: Operating Instructions

    | OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. •...

  • Page 14: Front Panel Control

    FRONT PANEL CONTROL • Power Button: Press this button to switch ON/OFF monitor’s power. • Power Indicator: Blue — Power On mode. Orange —Off mode. • MENU / ENTER : Activates OSD menu or function adjust confirm. • ECO/(-) Activates the ECO control when the OSD is OFF or navigate through adjustment icons when OSD is ON or adjust a function when function is activated.

  • Page 15: How To Adjust A Setting

    HOW TO ADJUST A SETTING 1. Press the MENU-button to activate the OSD window. 2. Press + or - to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. If the function selected has a sub-menu, press + or - again to navigate through the sub-menu functions.

  • Page 16: Adjusting The Picture

    ADJUSTING THE PICTURE Main Menu Main Menu Description Item Icon Menu Item Luminance Contrast Adjusts Image brightness in relation to the background. Brightness Adjusts backlight levels. Eco Mode Picture Adjustment, Standard: Brightness = 90, Contrast = 50. Brightness, Contrast (Adjustable) Text: Brightness = 20, Contrast = 50.
  • Page 17 Main Menu Main Menu Description Item Icon Menu Item Color Normal Normal Color Temperature. Temp. (RGB value is nonadjustable) Warm Warm Color Temperature. (RGB value is nonadjustable) Cool Cool Color Temperature. (RGB value is nonadjustable) sRGB RGB Color Temperature. (RGB value is nonadjustable) User Adjust R.G.B levels as desired.

  • Page 18: Plug And Play

    PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol.

  • Page 19: Technical Support (Faq)

    | TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution Power LED is not on * Check if the Power Switch is in the ON position. * Power Cord should be connected. No Plug & Play * Check if the PC system is Plug & Play compatible.

  • Page 20: Technical Support (Faq)

    TECHNICAL SUPPORT (FAQ) CLOCK (pixel frequency) controls the number of pixels scanned by one horizontal sweep. If the frequency is not correct, the screen shows vertical stripes and the picture has not correct width. FOCUS adjusts the phase of the pixel clock signal. With a wrong phase adjustment the picture has horizontal disturbances in light picture.

  • Page 21: Appendix

    | APPENDIX SPECIFICATIONS LCD Panel Panel Type TFT Color LCD Panel Size 70.9cm(28") Pixel pitch(mm) 0.16(H ) × 0.16(V ) Max. Resolution 3840X2160 Display Colors 1.073G Frequency H-Frequency 30KHz – 99KHz (D-SUB/Dual-link DVI-D/HDMI) (H/V) 30KHz – 160KHz (DisplayPort) V-Frequency 56Hz – 80Hz (D-SUB) 23Hz –...

  • Page 22: Factory Preset Timing Table

    FACTORY PRESET TIMING TABLE Preset Display Modes HORIZONTAL VERTICAL STAND RESOLUTION FREQUENCY(kHZ) FREQUENCY(Hz) 640×480 @60Hz 31.469 59.940 640×480 @67Hz 35.000 66.667 640×480 @72Hz 37.861 72.809 640×480 @75Hz 37.500 75.000 Dos-mode 720×400 @70Hz 31.469 70.087 800×600 @56Hz 35.156 56.250 800×600 @60Hz 37.879 60.317 SVGA...

  • Page 23: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Detect Cable Blue Ground Ground DDC-Serial Data Ground H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground...
  • Page 24 20-Pin Display Port Signal Cable Pin No. Mnemonic Signal ML Lane 3 (n) Lane 3 - Ground ML Lane 3 (p) Lane 3 + ML Lane 2 (n) Lane 2 - Ground ML Lane 2 (p) Lane 2 + ML Lane 1 (n) Lane 1 - Ground ML Lane 1 (p)
  • Page 25 19 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS Data 2+ TMDS Clock Shield TMDS Data 2 Shield TMDS Clock- TMDS Data 2- TMDS Data 1+ N.C. TMDS Data 1 Shield DDC SCL TMDS Data 1- DDC CLK TMDS Data 0+ DDC/CEC Ground...

  • Page 26: Wall Mounting (Optional)

    WALL MOUNTING (OPTIONAL) Refer to the instructions that come with the base mounting kit. To convert your LCD display from a desk-mounted to a wall-mounted display, do the following: 1. Verify that the Power button is turned Off, then disconnect the power cord. 2.

  • Page 27: Planar Support

    Visit Planar at http://www.planar.com/support for product registration, operations manuals, touch screen drivers, warranty information and access to Planar's Technical Library for online troubleshooting. To speak with Planar Customer Support please have you model and serial number available and dial: Planar Support Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the US.
  • Page 28 04/16 Q41G28M193501A...
