- Page 1 IX2790 LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product ............................6 Rear View of the Product .............................. 7 Quick Installation ................................8 Basic Operation................................. 9 Advanced Operation—OSD Menu ......................... 11 Supporting Timing Modes ............................18 Technical Information ..............................19 Wall-Mount Installation Instructions ........................20 Troubleshooting................................21 Planar Support ................................22... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the IX2790 LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 5: Safety Precautions
Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. Turn off the product before cleaning. LED Display screen surface may be cleaned using a soft clean cloth moistened with mild window glass commercial cleaners or 50/50 mixture of water and isopropyl alcohol. -
Page 6: Consignes De Sécurité
Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à... -
Page 7: Package Overview
Package Overview Congratulations on your purchase of this high performance LED edge lit, LCD monitor. This LED LCD Monitor comes with the following accessories: LED LCD Monitor Power Cord HDMI Cable Display Port Cable Mini DP to DP cable User’s Guide... -
Page 8: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤ ⑥ ① OSD Turn On/ Off ② Scroll Down/ Adjust Decrease/ Preset Mode Menu* ③ Scroll UP/ Adjust Increase/ Audio Menu* ④ Input select/ Confirm Selection/ Blue Light Reducer* ⑤ Power On/Off ⑥... -
Page 9: Rear View Of The Product
Rear View of the Product ① ② ③ ④ ⑤ ⑥ ⑦ ① Power Input ② HDMI 1 input (HDMI 19 pin) ③ HDMI 2 input (HDMI 19 pin) ④ HDMI 3 input (HDMI 19 pin) ⑤ Display Port 1 Input (Display Port 20 pin) ⑥... -
Page 10: Quick Installation
Quick Installation Connect either HDMI or Display Port Video source from the monitor to the computer, using the included HDMI cable or Display Port cable. Make sure both monitor and computer are powered OFF. Connect the earphone to the earphone output terminal of the monitor. (Earphone may be sourced separately from an earphone supplier) Connect power cord to a properly grounded AC outlet, and then to the monitor. -
Page 11: Basic Operation
Basic Operation Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press Power button on the front of LED LCD Monitor. The power LED indicator light will be blue when the LED LCD Monitor is on. - Page 12 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Power Button Locked” message for 3 seconds and the message will disappear automatically.
-
Page 13: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use▼ or ▲ to select the desired OSD menu. Press 2 to confirm or reach the next sub-menu. To exit press 1. Short Cuts Function from the button(s) Input: When Input Select is pressed, change Input signal to HDMI1, HDMI2, HDMI3, DisplayPort1,... - Page 14 Picture: To manually adjust the Picture Format, Brightness, Contrast, Sharpness, Overdrive, ECO Mode and Super Resolution of screen image. • Picture Format: To select the video mode from Full Screen, Aspect Ratio or Dot By Dot. • Brightness: To adjust the luminance of the video. ▲: increase brightness, ▼: decrease brightness.
- Page 15 PiP/PbP: PiP/PbP button allows you to watch two screens from different sources at the same time. (PiP is picture in picture; PbP is picture by picture) • PiP/PbP Mode: Toggle to enable/disable PiP/PbP function. Main Input. Identifies main source (greyed out) •...
- Page 16 In PbP Mode Splits the screen left and right equally. In order to achieve full screen on each side, recommended resolution is 2560 x 2880; however, this is a custom resolution. Check your video card to see if custom resolution is supported. If not supported, black bars on top and bottom will result.
- Page 17 Color: To select the color for improving brightness and color saturation between Warm, Normal, Cool, User Color, Preset Mode, and Blue Light Reducer. • Warm: Adds green to screen image for a darker color. • Normal: Adds red to screen image for warmer white and richer red. •...
- Page 18 Language: Allows user to choose from available languages. OSD Setting: To manually adjust the Horizontal and Vertical OSD position, OSD Background and OSD Time Out. • OSD H. Position: To horizontally adjust the OSD position. • OSD V. Position: To vertically adjust the OSD position. •...
- Page 19 Setup Menu: To set up DP Format, LED, Information and Reset. • DP Format: To adjust the DisplayPort bandwidth setting. -Full : Set DP version to 1.4. The maximum resolution is 5120x2880 60Hz. -Limit : Set DP version to 1.2. The maximum resolution is 3840x2160 30Hz. •...
-
Page 20: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION STANDARD RESOLUTION 720 x 400 @ 70Hz 1280 x 800 @ 60Hz 640 x 480 @ 60Hz VESA 1280 x 1024 @ 60Hz 640 x 480 @ 67Hz VESA 1280 x 1024 @ 75Hz VESA 640 x 480 @ 72Hz VESA 1600 x 900 @ 60RB... -
Page 21: Technical Information
Technical Information Panel 27” TFT (with LED backlight) Power Management On: 50 Watts (typical), 75 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution 5K UHD 5120 x 2880 max. Vertical Frequency 60Hz max. HDMI Support up to 3840 x 2160 Compatibility DP support up to 5120 x 2880 (non-interlaced) HDMI Support up to 3840 x 2160... -
Page 22: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. -
Page 23: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power supply is firmly connected to the LED LCD Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. Make sure all signal cables are installed. -
Page 24: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 25 Planar, a Leyard company 11/2017 Planar, a Leyard company. © Planar is a registered trademark of Planar, a Leyard company. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
