- Page 1 EL640.480-AG1 Series ICEBrite™ VGA Flat Panel Displays USER’S MANUAL www.planar.com...
- Page 2 Revision Control Date Description July 1999 Document number OM501-01 June 2004 Document number 020-0350-00 Rev A March 2005 Rev B (ECO 2201) updated J1 connector information...
-
Page 3: Table Of Contents
Contents EL640.480-AG1 Series VGA Display ........................3 Features and Benefits ............................3 Options ..................................3 Installation and Handling............................4 Mounting EL Displays ............................4 Cable Length................................5 Cleaning ...................................5 Avoiding Burn-In ..............................5 Specifications ................................6 Control Basics .................................6 Power..................................6 Data and Power Connector ..........................7 Locking Power and Data Connector ...................... - Page 4 Figures Figure 1. Data/Power Connector........................7 Figure 2. Video Input Timing Diagram......................9 Figure 3. Setup and Hold Timing Diagram....................10 Figure 4. Data Format............................11 Figure 5. EL640.480 AG1 Dimensions......................15 Tables Table 1. DC Input Voltage Requirements.....................6 Table 2. Video Input Requirements........................6 Table 3.
-
Page 5: El640.480-Ag1 Series Vga Display
EL640.480-AG1 Series VGA Display The EL640.480-AG1 series displays are 8.1" diagonal VGA products which offer designers an affordable solution in demanding applications where superior visual performance and environmental ruggedness are critical. Utilizing Planar’s proprietary ICEBrite (Integrated Contrast and Brightness Enhancement) technology, these displays excel in ambient light environments ranging from dark to nearly sunlight-bright. -
Page 6: Installation And Handling
Installation and Handling The mechanical package consists of the display panel and electronic circuit board adhesively bonded together and mounted in a plastic bezel. The bezel supplies the mounting ears and protects otherwise exposed leads. The display is made of glass material and must be handled with care. -
Page 7: Cable Length
Excessive cable lengths can pick up unwanted EMI. There are third party products which allow this maximum cable length to be exceeded. Contact Planar Application Engineering for more information. Avoiding Burn-In As with other light-emitting displays, use a screen saver or image inversion technique to avoid causing burn-in on the display. -
Page 8: Specifications
There is no overcurrent protection on either the V H or V L inputs to protect against catastrophic faults. Planar recommends the use of a series fuse on the 12 volt supply. A general guideline is to rate the fuse at 1.8 to 2 times the display maximum current rating. -
Page 9: Data And Power Connector
Data and Power Connector The EL640.480-AG1 display uses the Samtec STMM-110-01-T-D and the EL640.480-AG1 ET display uses the Samtec EHT-110-01-S-D or equivalent locking connectors. Although these connectors differ slightly, their pinouts are identical and are shown in the table below. The mating connector for both displays is in the Samtec TCSD family of cable strips. -
Page 10: Locking Power And Data Connector
Locking Power and Data Connector The display may be ordered with an optional 20 Pin 2 pin, 2 mm through-hole locking male header, Samtec EHT-110-01-S-D or equivalent. This locking connector is standard on the EL640.480-AG1 ET display. The mating Pin 1 connector is in the Samtec TCSD family of cable strips. -
Page 11: Interface Information
PC104, ISA, and many other interfaces. Planar Application Note 116 summarizes some of the interfacing options that have been used in the past with EL VGA displays. -
Page 12: Table 5. Video Input Timing
Table 5. Video Input Timing. AG1 ET Symbol Name Units Frame time Frame frequency CP1 High time CP1 Period 34.5 31.5 µs tHOLD S (FRAME) CP1 (LINE) tCLK tS12 tS21 CP2 (SHIFT) tHOLD UD0 to UD3 LD0 to LD3 Figure 2. Setup and Hold Timing Diagram. Table 6. -
Page 13: Self-Test Mode
CP1 (LINE) CP2 (SHIFT) Row 1 Row 2 634 638 Row 2 4 2 Row 2 4 1 634 638 Pixel no. Figure 4. Data Format. Self-Test Mode The EL640.480-AG1 display incorporates a self-test mode composed of a 1x2 checkerboard pattern that inverts every few seconds. The self-test mode is entered by applying power to the display with the S signal static. -
Page 14: Optical Performance
250 µA (for maximum dimming) from pin 1 to pin 2 of the dimming port. For more information on frame rate dimming please see Planar Application Note 120. EL640.480 AG1 Series User’s Manual (020-0350-00B) -
Page 15: Generating Grayscales
Careful testing is necessary to select appropriate grayscales for an application, especially when the ICEBrite displays are driven at less than their maximum frame rate. For additional information, refer to Planar Application Note 119 or contact Planar's Application Engineers. Environmental Table 8. -
Page 16: Safety And Emi
Height .197 (0.007) Component Envelope Figures 5 illustrates the distance components extend behind the display. Tall components do not necessarily fill this area. Planar reserves the right to relocate components within the constraints of the component envelope without prior customer notification. For this reason, Planar advises users to design enclosure components to be outside the component envelope. -
Page 17: Figure 5. El640.480 Ag1 Dimensions
Tolerances, unless otherwise stated, ± 0.2 mm. Connector is shown from the back side. Figure 5. EL640.480 AG1 Dimensions. Note: This is not a controlled version of the mechanical drawing. Prior to beginning your design, please contact Planar Applications Engineering for the current detailed drawing. EL640.480 AG1 Series User’s Manual (020-0350-00B) -
Page 18: Description Of Warranty
EL640.480-AG1 ET with conformal coating Design and specifications are subject to change without notice. Planar Systems continues to provide optional, and in many cases custom, features to address the specific customer requirements. Consult Planar Sales for pricing, lead time and minimum quantity requirements. -
Page 19: Support And Service
Support and Service Planar is a U.S. company based in Beaverton, Oregon and Espoo, Finland, with a world-wide sales distribution network. Full application engineering support and service are available to make the integration of Planar displays as simple and quick as possible for our customers. - Page 20 Tel: +358-9-420-01 Hours: M-F, 7:00am - 4pm CET © 2004 Planar Systems, Inc. 06/04 Planar is a registered trademark of Planar Systems, Inc. ICE, ICEBrite, and ICEPlus are trademarks of Planar Systems, Inc. Other brands and names are the property of their respective owners.
