ProForm Performance 400 C User Manual page 9

4. Identify the Left and Right Base Covers (73, 74).
Slide the Left and Right Base Covers onto the
Left and Right Uprights (75, 76) as shown.
5. Set a Handrail (71) onto the Left Upright (75).
Make sure that the Upright Wire (70) is not
pinched.
Attach the Handrail (71) with two 5/16" x 2 1/4"
Screws (7) and two 5/16" Star Washers (8).
Start both Screws before tightening them.
Attach the other Handrail (not shown) in the
same way. Note: There is no wire on the left
side.
Remove and discard the two indicated screws
(A) from both Handrails (71) (only one is shown).
4
75
73
5
75
9
76
74
7
8
A
71
70
