Compact Disc Player
with Ultimate Skip Protection
and MP3 Playback
IS-PA040718
INSTRUCTION MANUAL
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE OPERATING THIS UNIT.
WARNING
To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
IMPORTANT
Since the CD circuitry may cause interference to other radio tuners nearby, switch this unit off when not
in use or move it away from the affected radio tuner.
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesirable operation.
NOTE: This equipment has been tested and found to comply within the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
.
interference by one or more of the following measures:
.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
.
.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio / TV technician for help.
SAFETY CERTIFICATION
This Compact Disc Player is made and tested to meet safety standards of the FCC, requirements and
compliance with safety performance of the U.S. Department of Health and Human Services, and also with
FDA Radiation Performance Standards 21 CFR Subchapter J.
LASER SAFETY
This unit employs an optical laser beam system in the CD mechanism,
designed with built-in safeguards. Do not attempt to disassemble;
refer to qualified service personnel. Exposure to this invisible laser
light beam may be harmful to the human eye.
THIS IS A CLASS-1 LASER PRODUCT. USE OF CONTROLS, OR
INVISIBLE LASER RADIATION WHEN
ADJUSTMENTS OR PROCEDURES OTHER THAN THOSE SPECI-
OPEN AND INTERLOCK FAILED OR
FIED HEREIN, MAY RESULT IN HAZARDOUS LASER LIGHT BEAM
DEFEATED. AVOID DIRECT EXPO-
EXPOSURE.
SURE TO LASER BEAM.
SAFETY PRECAUTIONS
1. Do not open the cabinet. Refer servicing to qualified personnel only.
2. Do not expose to excessive heat, direct sunlight, dust, moisture, vibration or shock.
3. Use ONLY the AC adaptor required; others may damage your unit. Disconnect from the wall outlet
when the set is not to be used for an extended period of time.
4. When cleaning your unit, use a soft dry cloth, do not use solvents or commercially available cleaners
as they may damage or discolor the finish.
5. Do not wear headphones while operating a motor vehicle, this could create a traffic hazard and is
illegal in many areas.
6. The headphones supplied with your unit provide superior stereo listening while allowing you to hear
outside sounds when listening at normally low volume levels. Listening at extremely high volume levels
minimizes the intrusion of outside noise/sounds.
7. If you notice that the sound has become weak or distorted, this is an indication that your batteries are
low. Replace with new or recharged batteries. (see "BATTERY OPERATION " )
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS-PA040718 and is the answer not in the manual?

Questions and answers

Summary of Contents for Insignia IS-PA040718

  • Page 1 Compact Disc Player with Ultimate Skip Protection and MP3 Playback IS-PA040718 INSTRUCTION MANUAL PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE OPERATING THIS UNIT. WARNING To prevent fire or shock hazard, do not expose this appliance to rain or moisture. IMPORTANT Since the CD circuitry may cause interference to other radio tuners nearby, switch this unit off when not in use or move it away from the affected radio tuner.
  • Page 2: Location Of Control

    When the battery indicator starts flashing in the LCD panel, this means that the batteries are losing their charge. In this case the CD player will not function properly and the batteries must be replaced. If you are using Ni-CD rechargeable batteries, follow the intructions on how to recharge the batteries detailed in the owners manual.
  • Page 3: Charging And Use Of Rechargeable Batteries

    CHARGING AND USE OF RECHARGEABLE BATTERIES Rechargeable Battery Operation This unit can fully recharge the specified rechargeable battery in approximately 15 hours. The rechargeable batteries (NOT supplied) should be recharged before they are used for the first time, if they are low in power or they have not been used for a long period (over 60 days).
  • Page 4: Listening With Earphones

    CHANGING THE CORD ORIENTATION (Optional Type 1 or 2) (Type 1) 1. Remove the two large flathead slot- ted screws with a coin. 2. Gently remove plastic plate to ex- pose the cord. 3. Gently lift the cord and reroute to rear edge.
  • Page 5: Cleaning Discs

    CLEANING DISCS Fingerprints should be carefully wiped from the surface of disc with a soft cloth. Unlike conventional records, compact discs have no grooves to collect dust and microscopic debris, so gently wiping them with a soft cloth should remove most particles. Wipe in a straight motion from the center to the edge.
  • Page 6: Lcd Display Information

    Press >> lightly and repeatedly. Keep << depressed Keep >> depressed 1 is displayed. CD ALL is displayed. 1 is displayed. CD player plays current track is displayed. CD player plays all tracks ALL is displayed. CD player plays all...
  • Page 7: Program Play

    PROGRAM PLAY This allows selected tracks on the disc to be played in any desired order. To set the program play a. In the stop mode, press the PROGRAM button and 0P-01 is displayed. PGM and 0 start flashing. b. Press F.SKIP or B.SKIP button to select the track number.
  • Page 8: Maintenance

    LOW BATTERY DETECTION starts flashing when battery voltage level is too low. The player will auto stop and power off when the voltage level is too low. MAINTENANCE Cleaning the Cabinet Wipe with a soft cloth. If the cabinet is very dirty, dampen the cloth with a weak solution of neutral detergent and water, and then wipe clean.
  • Page 9: Product Specifications

    PRODUCT SPECIFICATIONS PICK UP System Compact disc digital audio system Properties Wavelength: =780nm Supported Disc Type CD Audio, CD-R, CD-RW, MP3 AUDIO D/A conversion DAC four times oversampling Frequency response 20-20,000Hz Wow and filter Below measurable limits No. of channels 2 Channel (stereo) Output level Earphones: 15mW (32 )
