- Page 1 RAROS-G RANDOM ORBITAL SANDER OPERATOR'S MANUAL ORIGINAL INSTRUCTIONS...
- Page 2 Important! It is essential that you read the instructions in this manual before operating this machine. Subject to technical modifications.
- Page 3 DESCRIPTION 1. Trigger lock pin 4. Sanding pad 7. Nitto style coupler 10. Axle adjuster 2. Trigger 5. Handle grip 8. Drive spindle 11. Air regulator adj. 3. Protection cover 6. Air inlet 9. Wrench knob Fig.1 Fig.2 Fig.3 Fig.4 Fig.5 Fig.6 Quick...
-
Page 4: General Safety Rules
recommended. GENERAL SAFETY RULES ■ Inspect the backing pad before each use. Do not use if ■ For multiple hazards, read and understand the safety cracked or broken or if it has been dropped. instructions before installing, operating, repairing, ■ Avoid direct contact with the moving sanding pad in maintaining, changing accessories on, or working near order to prevent pinching or cutting of hands or other the sander or polisher. -
Page 5: Dust And Fume Hazards
VIBRATION HAZARDS ■ The sander or polisher is not intended for use in potentially explosive atmospheres and is not insulated The information for use shall draw attention to vibration against contact with electric power. hazards that have not been eliminated by design and ■... -
Page 6: Specifications
SYMBOLS APPLICATION The product provides a patternless finish. The tool is ideal for sanding jobs such as feather edging, metal preparation Safety alert and blending body. Any other use is forbidden. Other features include: swirl-free finishes from its dual action pad motion, built-in regulator for positive speed control, side exhaust, and airflow adjustment. -
Page 7: Loading And Operation
unusually long air hoses (over 8 metres). The minimum LUBRICATION hose diameter should be 6.35 mm (1/4”) I.D. and the fittings must have the same inside dimensions. automatic in-line filter-regulator-lubricator recommended (Fig. 7) as it increases product life and ■ Keep hose away from heat, oil and sharp edges. Check keeps the product in sustained operation. -
Page 8: Troubleshooting
REMEDIES TROUBLESHOOTING ■ Pour air tool lubricating oil into air inlet. ■ Operate tool in short bursts of forward and/or reverse WARNING rotation where applicable. If any of the following symptoms appears during ■ Tap motor housing gently with a plastic mallet. operation, stop using the tool immediately, or serious ■... -
Page 9: Parts List
PARTS LIST Description Description Description Description Sanding pad Washer 6 Housing grip O-ring 3.5 x 1.5 Drive spindle Copper cushion Bolt 3 x 7 O-ring 8 x 1.5 Retainer ring 32 Wave washer O-ring 7.5 x 1.8 Valve seat Wave washer Washer Handing cover Bracket... - Page 10 Techtronic Industries (Australia) Pty. Ltd. Level 1, 660 Doncaster Road Doncaster, VIC 3108, Australia Techtronic Industries New Zealand Ltd. 18-26 Amelia Earhart Avenue Mangere, Auckland 2022, New Zealand...
