- Page 1 Libretto Istruzioni Instruction Manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Bruksanvisning...
- Page 2 Dear Customer, If you follow the recommendations con- tained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDaTIONS aND SUGGESTIONS INSTaLLaTION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. -
Page 4: Characteristics
CHaRaCTERISTICS Dimensions Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Reducer Flange ø 150-120 mm Ref. Q.ty Installation Components Screws 2,9 x 6,5 Q.ty Documentation Instruction Manual Electric Diagram... -
Page 5: Installation
INSTaLLaTION Drilling the Support surface and Fitting the Hood The Hood can be fitted directly to the underside of the Wall units (min. 650 mm above the cooker top) with snap-on side supports, which are set up for a support panel thickness of between 15 mm and 30 mm. - Page 6 • Replace the filter support • Screw the filter support using the 2 screws 12c (2,9 x 6 ,5) pro- vided. • Replace the grease filters make sure that the handle is visible on the outside. Connections DUCTED VERSION aIR EXHaUST SYSTEM When installing the ducted version, connect the hood to the chimney using either a flexible or rigid pipe ø...
-
Page 7: Control Panel
Control Panel The hood can be switched on pushing directly onto the requested speed without firstly having to select 0/1 button. FUNcTIONS 0/1 Light Turns lighting on and off. 0/1 Motor on First speed. When pressed for about 2 seconds the motor is switched off. Speed on Second speed. -
Page 8: Maintenance
REMOTE CONTROL (OPTIONaL) The appliance can be controlled using a remote control powered by a 1.5 V carbon-zinc alkaline batteries of the standard LR03-AAA type. • Do not place the remote control near to heat sources. • Used batteries must be disposed of in the proper manner. - Page 9 Activated charcoal filter (Recirculation version) REPLaCING THE aCTIVaTED CHaRCOaL FILTER • The filter is not washable and cannot be regene- rated. It must be replaced when led S1 flashes or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on.
- Page 10 Il simbolo sul prodotto o sulla confezione indica che il prodotto non deve essere considerato come un normale rifiuto domestico, ma deve essere portato nel punto di raccolta appropriato per il riciclaggio di apparecchiature elettriche ed elettroniche. Provvedendo a smaltire questo prodotto in modo appropriato, si contribuisce a evitare potenziali conseguenze negative per l’ambiente e per la salute, che potrebbero derivare da uno smaltimento inadeguato del prodotto.
