- Page 1 36” Vent Hood INSTRUCTIONS BOOKLET LIVRET D’INSTRUCTIONS MANUAL DE INSTRUCCIONES Ed. 2008...
- Page 2 Dear Sir/Madam, congratulations! You have purchased a prestigious range hood of guaranteed quality. For best results, we suggest that you carefully follow the operating and maintenance instructions provided in this booklet; in addition, to order spare charcoal filters, use the special coupon on the cover.
- Page 3 FFSYM48W5*FS Product code ARAFX30W5*SS FFSYM36W5*FS ARAFX36W5*SS FFALT24W5*FS ARART24W4*SG ARVUX24W5*SS ARARX30W5*SG ARVUX30W5*SS ARARX36W5*SG ARVUX36W5*SS FDCON48W5*SS FDDIA36W5*SS FDCON36W5*SS FDLGO30W5*SS FDCON30W5*SS FDADR36W5*SG FDFUT48W5*SS FDLUM36W5*SS FDFUT36W5*SS FDLUM48W5*SS FDINT48W5*SS FDASL36W5*SG FDINT36W5*SS FDIRD36W5*SS FFKRS48W5*FG ARART24W4*SG FFKRS36W5*FG ARTRA30W4*SS FDKRS36W5*SG ARTRA36W4*SS FDKRS48W5*SG FFPLN36W5*FS FDLGO36W5*SS FFPLN48W5*FS FDLNE48W5*SS FDLGO36W5*SS FDLNE36W5*SS FDCON30W5*SS FDMIZ30W5*SS FDASL36W5*SG...
- Page 4 Fig. O1 Fig. O2 Fig. C...
- Page 5 - not included in Aga models - six inch exhaust opening - unit includes 6”-5” adapter Fig. O3 Fig. O4...
- Page 6 ISTRUZIONI PER PANNELLO REMOVIBILE INSTRUCTION FOR REMOVABLE PANEL Fig. H3...
- Page 7 INSTRUCTIONS BOOKLET WARNINGS This instruction booklet must be kept together with the appliance for future reference. If the appliance is sold or consigned to other parties, check that the booklet is supplied with it, to ensure that the new user has the correct information on the operation of the range hood and is aware of the warnings.
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS The technical data pertaining to the electric appliance The technical specifica- tions of the appliance are shown on the rating plates located inside the range hood. INSTALLATION (Section reserved for qualified installers of the range hood) Minimum distance: distance between the main top of the cooking appliance and the bottom-most section of the hood. - Page 9 - the blue/white wire must be used for the neutral, - the brown/black wire must be used for the phase; the cable must not come into contact with hot parts (over 75°C). - fit a plug that is suitable for the load to the power cable, and connect it to a suitable power outlet.
-
Page 10: Operation
OPERATION 1. TWO BUTTON CONTROL PANEL LIGHT - Switch A Position 0: the light is off. Position 1: the light is on. SPEED - Switch B This is used to start and set the speed of the motor, from 1 to 3, or with continuous speed variator, depending on the version. - Page 11 Mode pushbutton Function: it turns hood motor on and off. The function “desired speed” enables to start the motor at the speed that was selected before the hood was last turned off. Optional: version with remote control (some versions only). WARNING: Install the hood away from sources of electromagnetic waves, as these could affect the correct operation of the electronic system.
- Page 12 2. CHARCOAL FILTERS To replace the charcoal filters, proceed as follows: remove the metal filters as described above. The two filters located at the ends of the motor can now be easily accessed. To install the new fi lters see picture. In case of hood with the motor box the fi...
- Page 13 WARNING! Light bulbs with different shapes and power ratings from the original may seriously damage the light compartment. 2. SPOTLIGHT To replace the lamp (“Round halogen light”): a) Make sure the appliance is disconnected from the mains power supply. b) Remove, by levering with a screwdriver, the support ring A for the cover glass. c) Remove the cover glass B to access the light compartment.
-
Page 14: Maintenance And Cleaning
3. FLUORESCENT TUBE (Section reserved for qualified installers) Replacing the fluorescent tube: a) Disconnect the device from the mains; b) Unscrew the fixing screws and remove the bottom panel; c) Remove the fluorescent tube, by rotating through 90°, and replace it with one of similar features (8W-13W-21W-28W according with the model);... -
Page 15: Safety Warnings
SAFETY WARNINGS The electrical system features an earth connection in compliance with in- ternational safety standards; furthermore, it is compliant with the European standard for electromagnetic compatibility. Do not connect the appliance to flues (from boilers, fireplaces, etc.). Make sure the mains voltage corresponds to the values on the rating plate located inside the range hood. - Page 16 - Adjust the alignment of the range hood using the screws on the brack-ets (Fig. O2). The top screw (B) adjust the distance from the wall, the bottom screw (C) adjust the height. Step 3 - To avoid hood unhooking due to underneath pressure, fix it to the wall with a screw anchor and related screw, by using the appropriate holes at the back of the hood or the cope flasks.
