- Page 1 Polar LOOK Kéo Power User Manual...
-
Page 2: Table Of Contents
ENGLISH Contents 1. PRODUCT ELEMENTS......9. IMPORTANT INFORMATION ....17 Changing Batteries....... 17 Changing Transmitter Sealing 2. INTRODUCTION ......Rings ........17 Maintenance......17 3. INSTALL BATTERIES......Technical Specifications ....18 Limited International Polar 4. SET CRANK LENGTH......Guarantee......... 19 LOOK Limited Warranty .... -
Page 3: Product Elements
ENGLISH 1. PRODUCT ELEMENTS Product Elements... -
Page 4: Introduction
ENGLISH 2. INTRODUCTION Together with a Polar cycling computer (CS600X, For video tutorials of the Polar LOOK Kéo Power, CS600 and CS500), Polar LOOK Kéo Power go to www.polar.fi/en/support/video_tutorials or system provides the following training information: www.lookcycle.com. • Actual, average and maximum power values The power output measurement of the Polar LOOK Kéo Power system is based on strain gauges. - Page 5 ENGLISH The power output measurement is performed Kéo Power pedals are not intended for beginning simultaneously from both pedals with identical cyclists, and they are not designed to release measurement systems. This enables accurate automatically in a fall or crash. Proper use by comparison of left and right leg power output.
- Page 6 ENGLISH • The material of the Kéo cleats is especially designed to be compatible with the body of your LIFESPAN - WEAR - INSPECTION REQUIREMENT Kéo. Using other than LOOK Kéo cleats can The Iifespan of LOOK components depends on seriously damage your pedals, and creates a real many factors, such as rider size and riding risk of malfunction.
-
Page 7: Install Batteries
ENGLISH 3. INSTALL BATTERIES Before training, install batteries to both transmitters. Open the cover by turning it counterclockwise. Place the battery (CR2354) inside the cover with the positive (+) side facing the cover. Put the cover with the battery inside it in place, and close it by turning clockwise. - Page 8 ENGLISH Pair Transmitters Manually The transmitters can also be paired manually. Press and hold the left transmitter button for 10 seconds (green light blinks 10 times). A blinking red light indicates the pairing is in process. A blinking green light indicates the pairing is complete.
-
Page 9: Set Crank Length
ENGLISH 4. SET CRANK LENGTH Before starting training for the first time, set your crank length on the left transmitter. Press and hold the button on the left transmitter for 5 seconds to access the crank length selection mode (green battery light blinks 5 times). -
Page 10: Install Pedals
ENGLISH 5. INSTALL PEDALS Screw the pedal onto the crank. Make sure to Carefully read all these instructions before use to screw it as far as it goes but do not tighten it. get the best out of the product. The specifications may be changed without notice when Unscrew the pedal so that the mark on the improvements are made in this product. - Page 11 ENGLISH Check the pedal positioning to allow correct transmitter attachment to pedal. The use of any device joining the cycling shoes to the pedals such as toe clips or clipless pedals may increase or decrease the risk of injury resulting from a fall or a collision.
-
Page 12: Install Transmitters
ENGLISH 6. INSTALL TRANSMITTERS Pass the cable tie through the hole in the After installing the pedals, install the transmitters transmitter. Press and hold the transmitter in to the bike. The transmitters are marked R (right), place, and tighten the cable tie around the and L (left). -
Page 13: Teach Transmitters To Cycling Computer
ENGLISH 7. TEACH TRANSMITTERS TO CYCLING COMPUTER The Polar LOOK Kéo Power system is compatible CS500 with Polar CS600X, CS600 and CS500 cycling Select Settings > Bike SET > Bike 1/ 2 / 3 > computers. Before training for the first time, the Power SET >... - Page 14 ENGLISH Default Power Settings For the Polar LOOK Kéo Power system to work properly, the cycling computer must use the default power settings. Even if you know the correct settings for your bike, do not use them. Set them as: : 304 g Chain weight : 1473 mm...
-
Page 15: Training
ENGLISH 8. TRAINING Calibration Important Calibration Information • Switch the transmitters on outside, to ensure The Polar LOOK Kéo Power system is calibration is done in training conditions. automatically calibrated each time the transmitters are switched on. During calibration • If the temperature changes 10°C or more during the transmitters are measuring zero power values. - Page 16 ENGLISH Start Training Transmitter LED Light Color Information • Blinking red light: automatic pairing and Activate your cycling computer. The cycling calibration. Do not touch the pedals. computer detects the transmitters automatically. • Blinking green light: ready to start training. Press START to start the recording.
-
Page 17: Important Information
ENGLISH 9. IMPORTANT INFORMATION Changing Batteries When changing the sealing rings, use caution to avoid damaging It is recommended that you change both transmitter them or the transmitters. batteries at the same time. When the battery is low, a red light will blink once every two seconds when the automatic calibration has been completed. -
Page 18: Technical Specifications
ENGLISH Technical Specifications Pedal Tension Adjustment Polar P5 power transmitter LOOK pedals are ALWAYS delivered pre-set to a minimum tension. Adjustment is carried out at the rear of the pedal, -10 °C to +50 °C Operating temperature: on the lever, using a 3 mm Allen key. By turning the key Storage temperature: -20 °C to +60 °C in the + direction (clockwise), you increase the amount of... -
Page 19: Limited International Polar Guarantee
USA or Canada. This limited Polar repaired or replaced at any of the authorized Polar international guarantee is issued by Polar Electro Oy for Service Centers regardless of the country of purchase. consumers who have purchased this product in other countries. -
Page 20: Look Limited Warranty
All rights reserved. No part of this manual may be used or reproduced in any form or by any means without prior written permission of Polar Electro Oy. The names and This crossed out wheeled bin marking shows that Polar logos marked with a ™... -
Page 21: Disclaimer
• Polar Electro Inc. / Polar Electro Oy shall not be liable product, whether the claim is based upon contract, for any damages, losses, costs or expenses, direct,...
