Summary of Contents for Vibe LiteAir LA4
- Page 1 INSTRUCTION MANUAL LiteAir 4, 5, 6 Component Speakers Models: LA4, LA5, LA6 To ensure maximum performance and safety, please follow this manual. Please retain the manual for future reference after www.vibeaudio.co.uk installation...
-
Page 2: Owners Manual
LiteAir Component Speakers OWNERS MANUAL Congratulations on purchasing your VIBE LITEAIR speakers, please read this manual in order to fully understand how to get the best results from your speakers and ensure that all advice on how to look after the speakers is followed. Thank you for buying VIBE, we hope you enjoy listening to your product as much as we enjoyed creating it. -
Page 3: Speaker Installation
LiteAir Component Speakers SPEAKER INSTALLATION Firstly, make sure that the speakers will fi t in your chosen location. This may involve the removal of the standard vehicle speakers. Please use the mounting depth and hole cut dimensions as detailed in this manual for guidance. •... -
Page 4: Tweeter Installation
LiteAir Component Speakers TWEETER INSTALLATION The tweeter can either be fi tted fl ush mount or surface mount. Try and take into account the following when locating a suitable position. For optimum staging try and locate a position that is higher than the woofer but within twelve inches (maximum) of it. -
Page 5: Wiring Diagram
LiteAir Component Speakers The second requires the use of the metal strip provided. (See Figure B) • After fi nding a suitable position for the tweeters place the cut out template for the tweeter in position and mark around it. •... -
Page 6: Limited Warranty
● Products returned without a returns authorisation number ● Damage to product due to the use of sealant INTERNATIONAL WARRANTY Contact your International VIBE audio dealer or distributor concerning specifi c procedures for your country’s warranty policies. WARNING VIBE equipment is capable of sound pressure levels that can cause permanent damage to your hearing and those around you. -
Page 7: Specifications
LiteAir Component Speakers SPECIFICATIONS LiteAir 4 101mm 70 watts 210 watts 35 watts RMS 89 dB 80Hz - 25kHz 60Hz - 25kHz 55Hz - 25kHz 1.3” (34mm) 3.7” (93mm) Material Weight Rating Space Stereo 2 Space Stereo 2 Space Stereo 2 Space Stereo 4 Space Stereo 4 Space Stereo 4...
