- Page 1 Instruction Manual To ensure maximum performance and safety, please follow this manual. Please retain the manual for future reference after installation Model: BDQB69 -V1...
-
Page 2: Owners Manual
KEEP THE VOLUME AT A LEVEL SO YOU CAN STILL HEAR OUTSIDE NOISE - failure to do this may result in an accident. VIBE equipment is capable of producing sound levels that can permanently damage your hearing. VIBE recommends caution when listening at high volume. - Page 3 Wiring conections Before you begin please read all instructions that come with your power tools and wear all recommended safety equipment. Also remember the rule - “measure twice cut once” please ensure that the QB69 will actually fit in its intended location as replacing metalwork is a costly business.
- Page 4 Secure the 2 side screws first and then fasten the 4 corner screws through the grill and the speaker to secure the speaker in place. Congratulations. You have completed the installation of the VIBE QB69 Speakers can be enclosed or mounted free air. For best results ensure a rigid mounting surface.
- Page 5 Parameters RMS Power = 200 watts Peak Power = 600 watts Miminum recommended amplifier input = 100 Watts RMS Sensitivity = 91dB Frequency response = 30Hz – 25KHz Mounting cutout = 170mm x 220mm Mounting depth = 100mm Recv = 3.600 ohms Fo = 45.272 Hz Sd = 28.400 mm Vas = 31.137 ltr...
-
Page 6: Limited Warranty
For the avoidance of doubt, VIBE does not limit its liability for death or personal injury to the extent...
