CHANGING THE LIGHT

Before removing the light bulb, turn off the refrigerator first and then unplug the unit from the wall outlet.
Failure to do so could result in electrical shock or personal injury.
As shown in Figure step 1, remove the lamp cover;
As shown in Figure step 2, use left hand to press the LED light panel to inside along the direction of
arrow B and pull out the circuit boards along the direction of "arrow C" with flat head screwdriver.
As shown in Figure step 3, hold down of wire terminal with left hand and remove the LED lamp
circuit with right hand seizing the other wire terminal .
Replace with LED light that is the same shape and size.
Reinstall the LED light panel and lamp cover.
Step 1

CHANGING THE REVERSIBLE DOOR

Step 2
7
Step 3
