High Tech Pet Power Pet Installation Instructions Manual page 8

3. Drill the hole first using a 1/8 inch drill
bit and then finishing with a 1/4 inch
drill bit. (Figure 6) Be careful to not
penetrate the drill bit beyond the frame
material (aluminum or PVC). Drilling too
deep may damage the glass or the glass
seal. Drill just deep enough to create a
1/4 inch hole for the pin to engage.
4. Insert the lock pin in the drilled hole
and hold the lock in position while
you mark the two mounting slots
on the edge of the sliding door.
(Figure 7)
When doing this, position the lock
so that it will not interfere with
anything while opening and closing
the door.
5. Remove the lock and using a 1/8 inch
drill bit, drill pilot holes for two screws
to hold the lock to the sliding door.
(Figure 8)
Drill only deep enough to produce a
hole in the sliding door frame. Drilling
too deep may damage the glass or
glass seal.
___________________________________________________________________________________________
8 www.hightechpet.com
FIGURE 6
FIGURE 7
FIGURE 8
