  • Page 1 5-port 10/100Base-TX Industrial Switch (IS-0005F) User’s Guide...
  • Page 2: Fcc Warning

    COPYRIGHT All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, whether electronic, mechanical, photo copying, recording or otherwise, without the prior written permission of the publisher. FCC WARNING This equipment has been tested and found to comply with the limits for a class A device, pursuant to part 15 of FCC rules.
  • Page 3: Table Of Contents

    INTRODUCTION ..............4 ......... 4 NDUSTRIAL THERNET ECHNOLOGY ........... 5 WITCHING ECHNOLOGY ................6 EATURES IS-0005F INDUSTRIAL SWITCH - UNPACKING AND SET-UP .................7 ................ 7 NPACKING IS-0005F ..........8 AYOUT OF THE DIN- IS-0005F......10 RAIL MOUNTING OF THE ..........11...
  • Page 4: About This Guide

    Ethernet environment. With its dry contact smart alarm, the IS- 0005F can initiate a physical alarm (audible and/or visible) in the event of a malfunction. The IS-0005F operates in a wide temperature range, from -10 to 70°C, and is designed to handle higher than normal degrees of vibration and shock, making it suitable for harsh industrial environments.
  • Page 5: Switching Technology

    These devices also operate well in temperatures as high as 70°C. Not an ordinary office switch by any means, the IS-0005F is engineered and designed specifically for the harsh, industrial- type environments commonly encountered in heavy industry.
  • Page 6: Features

    Features The Switch was designed for easy installation and high performance in an industrial environment where vibration, shock, heat, and RF interference may be commonplace. The Switch was specifically designed to be small and compact for easy DIN-rail mounting and it can be installed where space is limited.
  • Page 7: Is-0005F Industrial Switch - Unpacking And Set-Up

    DIP-switch to enable or disable alarm functions Power input polarity protection function Under-power and over-power detection function Wide operating temp.: -40°C ~ 70°C for the IS-0005F Store-and-forwarding Auto-negotiation at all copper ports IS-0005F I NDUSTRI AL WIT CH NPACKING AN D...
  • Page 8: Layout Of The Is-0005F

    Layout of the IS-0005F Front View of Switch 1. Alarm LED 2. Redundant Power LED 3. Primary Power LED 4. TX ports (5) 5. TX port 100Mbps LED 6. TX port LNK/ACT LED...
  • Page 9 TOP View of Switch Grounding Screw Terminal block for power input (PWR/RPS), and alarm dry contact DIP-switches Back View of Switch Din Rail Bracket Screws...
  • Page 10: Din-Rail Mounting Of The Is-0005F

    DIN-rail mounting of the IS-0005F The aluminum DIN-rail attachment plate should already be affixed to the back panel of the Switch. If you need to attach the DIN-rail plate, assure that the stiff metal spring is situated towards the top. Attaching the Switch to the...
  • Page 11: Redundant Power Inputs

    Switch. Do not place heavy objects on the Switch. Grounding the IS-0005F Industrial Switch will help minimize noise due to electromagnetic interference (EMI). Always run the ground connection from the ground screw to the grounding surface prior to connecting DC power.
  • Page 12 DC Powered Switch: Power is supplied through an external DC power source. Check the technical specification section for information about the DC power input voltage. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on. plastic green contact...
  • Page 13: Ethernet Connections

    D. Assure your DC power supply is stable and clean before applying DC power to the Switch. Ethernet Connections The IS-0005F Industrial Fast Ethernet Switch has five 10/100Base-TX Ethernet ports. The 10/100Base-TX ports are located on the Switch’s front panel and are...
  • Page 14: Led Indicators

    LED will illuminate green if the link speed is 100Mbps, and the lower LED will illuminate green if there is link activity. Otherwise, the LED’s will be off. External Alarm Contact The IS-0005F Industrial Switch has one Alarm Contact...
  • Page 15: Dip-Switch Settings

    connection point located on the green Power Contact Block on the top panel. For detailed instructions on how to connect the Alarm Contact power wires to the two ALM contacts of the 6-contact terminal block connector, see the Procedure for Connecting DC Power in the section above (it is the same procedure).
  • Page 16: Auto-Negotiation

    The following is the Recommended Procedure for configuring and setting DIP-switches during initial installation: 1. Turn all DIP-switches OFF. 2. Install the IS-0005F into your network. 3. Decide which port(s) need to be monitored or should trigger the alarm. 4. Turn the corresponding port DIP-switch ON.
  • Page 17: Switching, Filtering, And Forwarding

    Switching, Filtering, and Forwarding Packets entering the IS-0005F Switch with source and destination addresses belonging to the same port segment will be filtered, limiting those packets to one port, and relieving the rest of the network from the need to process them.
  • Page 18: Technical Specifications

    Physical and Environmental DC inputs 9-48V DC Temperature Operating: -10 ~ 70 C, Storage: -20 ~ 80 C IS-0005F Operating: -40 ~ 70 C, Storage: -40 ~ 85 C Humidity Operating: 10% ~ 80% Dimensions 100 x 50 x 120 mm (D x W x H)
  • Page 19: Appendix

    Transmission Method: Store-and-forward, with IEEE802.3x full duplex, non-blocking flow control. Packet Filtering / 10Mbps Ethernet: 14,880/pps Forwarding Rate: 100Mbps Fast Ethernet: 148,800/pps MAC Address Learning: Update automatically PPENDIX RJ-45 Pin Specifications The RJ-45 ports in the Switch support auto-negotiation and auto MDI/MDI-X. This feature eliminates worries about using a specific cable type.
