- Page 1 48 PORTS WEB SMART SWITCH SW-2248F Planex Communications Inc.
-
Page 2: Table Of Contents
TABLE OF CONTENT About This Guide................. 1 Purpose .................... 1 Terms/Usage ..................1 Introduction..................3 Gigabit Ethernet Technology ............3 Fast Ethernet Technology ..............4 Switching Technology ..............5 VLAN (Virtual Local Area Network)..........6 Features.................... 6 Unpacking and Installation ..............9 Unpacking.................. - Page 3 Configuration ..................18 Installing the Web Management Utility......... 18 Discovery List................19 Monitor List ................... 20 Device Setting................22 Toolbar................... 23 Configuring the Switch ..............24 Login....................25 Setup Menu ..................27 Configuring Setup Setting.............. 27 Port Settings................28 Port-based VLAN Settings (Virtual Local Area Network) ..30 IEEE 802.1Q VLAN Settings (Virtual Local Area Network)..
-
Page 4: About This Guide
ABOUT THIS GUIDE Congratulations on your purchase of the 48 Ports Web Smart Switch. This device integrates 1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Purpose This guide discusses how to install your 48 Ports Web Smart Switch. Terms/Usage In this guide, the term “Switch”... -
Page 5: Introduction
INTRODUCTION This chapter describes the features of the 48 Ports Web Smart Switch some background information about Ethernet/Fast Ethernet/Gigabit Ethernet switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol, full duplex, flow control, and management objects, but with a tenfold increase in theoretical throughput over 100-Mbps Fast Ethernet and a hundredfold increase over 10-Mbps Ethernet. -
Page 6: Fast Ethernet Technology
tomorrow’s rapidly improving switching and routing internetworking technologies. And with expected advances in the coming years in silicon technology and digital signal processing that will enable Gigabit Ethernet to eventually operate over unshielded twisted-pair (UTP) cabling, outfitting your network with a powerful 1000-Mbps- capable backbone/server connection creates a flexible foundation for the next generation of network technology products. -
Page 7: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. -
Page 8: Vlan (Virtual Local Area Network)
VLAN (Virtual Local Area Network) A VLAN is a group of end-stations that are not constrained by their physical location and can communicate as if a common broadcast domain, a LAN. The primary utility of using VLAN is to reduce latency and need for routers, using faster switching instead. - Page 9 Up to 4K unicast addresses entities per device, self-learning, and table aging 1536KBytes packet buffer Supports IEEE 802.3x flow control for full-duplex mode ports Supports Back-pressure flow control for half-duplex mode ports Supports port-base VLAN and IEEE 802.1Q VLAN Supports port-base QoS Supports Trunk Supports Port-setting for Speed/Disable, Flow control Easy configuration via WEB Browser...
-
Page 10: Unpacking And Installation
UNPACKING AND INSTALLATION This chapter provides unpacking and installation information for the Switch. Unpacking Open the shipping cartons of the Switch and carefully unpacks its contents. The carton should contain the following items: One 48 Ports Web Smart Switch One AC power cord, suitable for your area’s electrical power connections Four rubber feet to be used for shock cushioning Screws and two mounting brackets... -
Page 11: Rack Mounting
Leave at least 10cm of space at the front and rear of the hub for ventilation. Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack. For information on rack installation, see the next section, Rack Mounting. -
Page 12: Connecting Network Cable
Connecting Network Cable The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and it runs both in half and full duplex mode using two pair of Category 5 cable. The Switch also supports 2-Ports 1000Mbps Gigabit Ethernet that runs in Auto-negotiation mode and 10Mbps Ethernet or 100Mbps Fast Ethernet that runs both in half and full duplex mode and 1000Mbps Gigabit Ethernet runs in full duplex mode using four pair of Category 5 Cable. -
Page 13: Identifying External Components
IDENTIFYING EXTERNAL COMPONENTS This chapter describes the front panel, rear panel, and LED indicators of the Switch. Front Panel The figure below shows the front panels of the Switch. Figure 3. Front panel of the Switch LED Indicator: Comprehensive LED indicators display the status of the switch and the network (see the LED Indicators chapter below). -
Page 14: Rear Panel
mini-GBIC Ports (Port 51~52): The Switch is equipped with two mini-GBIC ports, supported optional 1000BASE-SX/LX mini-GBIC module. Note: When the port was set to “Forced Mode”, the Auto MDI/MDIX will be disabled. Reset: The Reset button is to reset all the setting back to the factory default. Note: Be sure that you recorded the setting of your device, else all the setting will be erased when pressing the “Reset”... -
Page 15: Understanding Led Indicators
UNDERSTANDING LED INDICATORS The front panel LEDs provides instant status feedback, and, helps monitor and troubleshoot when needed. Figure 5. LED indicators of the Switch Power and System LEDs POWER: Power Indicator : When the Power LED lights on, the Switch is receiving power. : When the Power turns off or the power cord has improper connection. -
Page 16: Ports 1~48 10/100M Status Leds
Ports 1~48 10/100M Status LEDs LINK/ACT: Link/Activity : When the Link/ACT LED lights on, the respective port is successfully connected to an Ethernet network. Blinking : When the Link/ACT LED is blinking, the port is transmitting or receiving data on the Ethernet network. : No link. -
Page 17: Ports 51~ 52 Mini-Gbic Status Leds
Ports 51~ 52 mini-GBIC Status LEDs LINK/ACT: Link/Activity : When the mini-GBIC module is installed and connected to a network, the Link/ACT LED lights on. Blinking : When the LED is blinking, the mini-GBIC module is receiving data on a network. -
Page 18: Configuration
CONFIGURATION Through the Web Browser you can configure the Switch such as VLAN, Trunking, QoS… etc. With the attached Web Management Utility, you can easily discover all the Web Management Switch, assign the IP Address, changing the password and upgrading the new firmware. Installing the Web Management Utility The following gives instructions guiding you through the installations of the Web Management utility. -
Page 19: Discovery List
Figure 6. Web Management Utility The Web Management Utility was divided into four parts, Discovery List, Monitor List, Device Setting and Toolbar function, for details instruction, follow the below section. Discovery List This is the list where you can discover all the Web management devices in the entire network. -
Page 20: Monitor List
System word definitions in the Discovery List: MAC Address: Shows the device MAC Address. IP Address: Shows the current IP address of the device. Protocol version: Shows the version of the Utility protocol. Product Name: Shows the device product name. System Name: Shows the appointed device system name. - Page 21 View Trap: The Trap function can receive the events that happen from the Web Management Switch in the Monitor List. There is a light indicator behind the “View Trap” button, when the light indicates in green, it means that there is no trap transmitted, and else when it indicates in red, it means that there is new trap transmitted, this is to remind us to view the trap.
-
Page 22: Device Setting
Device Setting You can set the device by using the function key in the Device Setting Dialog box. Configuration Setting: In this Configuration Setting, you can set the IP Address, Subnet Mask, Gateway, Set Trap to (Trap IP Address), System name and Location. Select the device in the Discovery list or Monitor List and press this button, then the Configuration Setting window will pop out as Figure 9, after filling up the data that you want to change, you must fill up the... -
Page 23: Toolbar
Figure 10. Password Change Firmware Upgrade: When the device has a new function, there will be a new firmware to update the device, use this function to update. Figure 11. Web Access: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access”... -
Page 24: Configuring The Switch
Monitor Save As: To record the setting of the Monitor List in appointed filename and file path. Monitor Load: To manually load the setting file of the Monitor List. Exit: To exit the Web Management Utility. In the “View TAB”, there are view log and clear log function, this function will help you to show trap setting. -
Page 25: Login
System Setting Device status and Statistic Login Before you configure this device, note that when the Web Smart Switch is configured through an Ethernet connection, make sure the manager PC must be set on same the IP network. For example, when the default network address of the default IP address of the Web Smart Switch is 192.168.0.1, then the manager PC should be set at 192.168.0.x (where x is a number between 2 and 254), and the default... - Page 26 When the following dialog page appears, remain enter the default password "admin" and press Login to enter the main configuration window. Figure 13. After entering the password, the main page comes up, the screen will display the device status. Figure 14. Device Status...
-
Page 27: Setup Menu
Setup Menu When the main page appears, find the Setup menu in the left side of the screen (Figure 15). Click on the setup item that you want to configure. There are eleven options: Port Settings, VLAN Settings, Trunk Setting, Device Status, Statistic, System Settings, Trap Setting, Password Setting, Backup Setting and Reset Setting as shown in the Main Menu screen. -
Page 28: Port Settings
Port Settings In Port Settings menu (Figure 16), this page will show each port’s status, press the ID parameter to set each port’s Speed, Flow Control, and QoS priority. When you need to renew the posted information, press the “Refresh” button. The Link Status in the screen will show the connection speed and duplex mode;... -
Page 29: Flow Control
To change the port setting, click on the ID parameter to enter to the selected port to configure its Speed/Disable, Flow control and QoS setting. Figure 17. Speed/Disable: This setting has six modes—100M Full, 100M Half, 10M Full, 10M Half, Auto and Disable—for speed or port disable selections. Note: If speed set to be exist 100M full mode or 10M full mode, flow control have fixed setting to disable Flow Control:... -
Page 30: Port-Based Vlan Settings (Virtual Local Area Network)
In some ports that need to have a high priority to manage the data transfer, QoS should be change. Set the port’s QoS to high to determine the port will always transfer their data first. Note: QoS function can be working in any port either from port 1 to port 24 or from port 25 to port 52.However, QoS setting can not be working in different port group. - Page 31 Figure 20. VLAN Settings Once you want to modify the VLAN Group, check on the ID parameter, the ID VLAN configuration window will pop out.
-
Page 32: Ieee 802.1Q Vlan Settings (Virtual Local Area Network)
Figure 21. VLAN Group Change Note 1: group 1 and Group 2 can not be managed at the same time Note 2:When add a new Vlan, the members of default Vlan 1 are removed automatically. Therefore, packets can only transmit among the member ports of new Vlan. Packets can not fordward among the ports which are not included in the new vlan. - Page 33 VID: select the VID group that you set. When you select VID Table Setting, press “Add new VID” to create new VID group, from port 01 ~ port 52, select Untag Port, Tag Port or Not Member for each port. To save the VID group, press “Apply” button.
-
Page 34: Trunk Setting
Figure 23. Trunk Setting The Trunk function enables to cascade two devices with a double times bandwidth (up to 4000Mbps in full duplex mode). There are seven groups for trunk setting, each group has fixed setting to choose, Group 1~Group 6 for 10/100Mbps setting, Group 7 for 10/100/1000Mbps setting (only port 49 and port 50) -
Page 35: Device Status
Figure 24. Trunk Settings Be sure that the selected trunk setting port must connect to the device with a same VLAN group. Device Status Click on the “Status” to present the device status on this screen, it will show the System Status, Port Status, VLAN Status and Trunk Status . Press “Refresh”... - Page 36 Figure 25. Statistic For Detail packet information, click on the ID parameter as Figure 26.
-
Page 37: System Setting
Figure 26. System Setting The System Setting includes the System name, Location name, Login Timeout, IP Address, Subnet Mask and Gateway. Through the Web Management Utility, you can easily recognize the device by using the System Name and the Location Name. The Login Timeout is to set the idle time-out for security issue, when there is no action when running the Web Smart Utility and the time is up, you must re-login to Web Smart Utility before you set the Utility. -
Page 38: Trap Setting
Figure 27. Trap Setting The Trap Setting enables the device to monitor the Trap through the Web Management Utility, set the Trap IP Address of the manager where the trap to be sent. - Page 39 Figure 28. Trap Setting System Events: Monitoring the system’s trap. Device Bootup: a trap when booting up the system. Illegal Login: a trap when there is using a wrong password login, and it will record from where the IP to be login. Fiber Port Events: Monitoring the Fiber port status.
-
Page 40: Set Password
Abnormal* Transmit Error: a trap when there are transmit data error in fiber port. Copper Port Events: Monitoring the copper port status. Abnormal* Receive Error: a trap when there are receive data error in copper port. Abnormal* Transmit Error: a trap when there are transmit data error in copper port. -
Page 41: Backup Setting
Backup Setting The backup tools help you to backup the current setting of the Switch. Once you need to backup the setting, press the “Backup” button to save the setting. To restore a current setting file to the device, you must specify the backup file and press “Restore”... -
Page 42: Logout
Logout When press this function, the web configuration will go back to first Login page. Figure 32. Logout... -
Page 43: Technical Specifications
TECHNICAL SPECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z 1000BASE-SX/LX Gigabit Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3x Full Duplex Flow Control Protocol CSMA/CD Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex) Gigabit Ethernet: 2000Mbps (full-duplex) Topology... - Page 44 Performance Transmits Method: Store-and-forward Filtering Address Table: 4K entries per device Packet 10Mbps Ethernet: 14,880/pps Filtering/Forwarding Rate: 100Mbps Fast Ethernet: 148,800/pps 1000Mbps Gigabit Ethernet: 1,488,000/pps MAC Address Learning: Automatic update Transmits Method: Store-and-forward RAM Buffer: 1536K Bytes per device...
-
Page 45: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
