- Page 1 8-Port Web Smart PoE Switch SW-0008FP Planex Communications Inc.
-
Page 2: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Table Of Contents
TABLE OF CONTENT About This Guide................. 1 Purpose .................... 1 Terms/Usage ..................1 Introduction..................3 Fast Ethernet Technology ..............3 Switching Technology ..............4 VLAN (Virtual Local Area Network)..........5 Power over Ethernet (PoE) .............. 5 Features.................... 6 Unpacking and Installation ..............7 Unpacking.................. - Page 4 Monitor List ................... 17 Device Setting................19 Toolbar................... 20 Configuring the Switch ..............21 Login....................22 Setup Menu ..................24 Configuring Setup Setting.............. 24 Port Settings................25 VLAN Settings (Virtual Local Area Network) ......26 Trunk Setting ................28 Mirror Setting................28 QoS Setting ................
-
Page 5: About This Guide
Purpose This guide discusses how to install your SW-0008FP. Terms/Usage In this guide, the term “User’s Manual” refers to your SW-0008FP and “User’s Manual” refers to other Ethernet switches. -
Page 7: Introduction
INTRODUCTION This chapter describes the features of the SW-0008FP and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. -
Page 8: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. -
Page 9: Vlan (Virtual Local Area Network)
VLAN (Virtual Local Area Network) A VLAN is a group of end-stations that are not constrained by their physical location and can communicate as if a common broadcast domain, a LAN. The primary utility of using VLAN is to reduce latency and need for routers, using faster switching instead. -
Page 10: Features
Features 8×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports with PoE function Compliant with IEEE 802.3af specification Supports PoE power maximum 15.4W for each PoE ports Supports PoE Powered Device (PD) classification identify Each port supports auto MDI/MDIX, so there is no need to use cross-over cables or an up-link port Full/half duplex transfer mode for each port Wire speed reception and transmission... -
Page 11: Unpacking And Installation
Unpacking Open the shipping cartons of the Switch and carefully unpacks its contents. The carton should contain the following items: One SW-0008FP One AC power cord, suitable for your area’s electrical power connections Four rubber feet to be used for shock cushioning Screws and two mounting brackets CD-Rom with Web Management Utility and User’s Guide... -
Page 12: Connecting Network Cable
Leave at least 10cm of space at the front and rear of the hub for ventilation. Install the Switch on a sturdy, level surface that can support its weight, or in an EIA standard-size equipment rack. For information on rack installation, see the next section, Rack Mounting. - Page 13 power connector and the system fan. The switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.
-
Page 15: Identifying External Components
Switch. Front Panel The figure below shows the front panels of the Switch. Figure 3. Front panel of SW-0008FP Reset: The Reset button is to reset all the setting back to the factory default. Note: Be sure that you recorded the setting of your device, else all the setting will be erased when pressing the ì... -
Page 16: Rear Panel
These ports support network speeds of either 10Mbps or 100Mbps, and can operate in half- and full- duplex transfer modes. These ports also supports automatic MDI/MDIX crossover detection function gives true “plug and play” capability, just need to plug-in the network cable to the hub directly and don’t care if the end node is NIC (Network Interface Card) or switch and hub. -
Page 17: Understanding Led Indicators
UNDERSTANDING LED INDICATORS The front panel LEDs provides instant status feedback, and, helps monitor and troubleshoot when needed. Figure 5. LED indicators of the Switch Power and System LEDs POWER: Power Indicator : When the Power LED lights on, the Switch is receiving power. : When the Power turns off or the power cord has improper connection. - Page 18 When the Link/ACT LED is blinking, the port is transmitting or Blinking receiving data on the Ethernet network. : No link. 100M When the 100Mbps LED lights on, the respective port is connected to a 100Mbps Fast Ethernet network. : When the respective port is connected to a 10Mbps Ethernet network POWER GOOD When the PoE device was connected and the port supplies power Green...
-
Page 19: Configuration
CONFIGURATION Through the Web Browser you can configure the Switch such as VLAN, Trunking, and QoS… etc. With the attached Web Management Utility, you can easily discover all the Web Management Switch, assign the IP Address, changing the password and upgrading the new firmware. Installing the Web Management Utility The following gives instructions guiding you through the installations of the Web Management utility. -
Page 20: Discovery List
Figure 6. Web Management Utility The Web Management Utility was divided into four parts, Discovery List, Monitor List, Device Setting and Toolbar function, for details instruction, follow the below section. Discovery List This is the list where you can discover all the Web management devices in the entire network. -
Page 21: Monitor List
System word definitions in the Discovery List: MAC Address: Shows the device MAC Address. IP Address: Shows the current IP address of the device. Protocol version: Shows the version of the Utility protocol. Product Name: Shows the device product name. System Name: Shows the appointed device system name. - Page 22 View Trap: The Trap function can receive the events that happen from the Web Management Switch in the Monitor List. There is a light indicator behind the “View Trap” button, when the light indicates in green, it means that there is no trap transmitted, and else when it indicates in red, it means that there is new trap transmitted, this is to remind us to view the trap.
-
Page 23: Device Setting
Device Setting You can set the device by using the function key in the Device Setting Dialog box. Configuration Setting: In this Configuration Setting, you can set the IP Address, Subnet Mask, Gateway, Set Trap to (Trap IP Address), System name and Location. Select the device in the Discovery list or Monitor List and press this button, then the Configuration Setting window will pop out as Figure 9, after filling up the data that you want to change, you must fill up the... -
Page 24: Toolbar
Firmware Upgrade: When the device has a new function, there will be a new firmware to update the device, use this function to update. Figure 11. Web Access: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access” button to access the device in Web browser. -
Page 25: Configuring The Switch
In the “Help TAB”, there is About function, it will show out the version of the Web Management Utility. Configuring the Switch The SW-0008FP has a Web GUI interface for smart switch configuration. The Switch can be configured through the Web Browser. A network administrator can manage, control and monitor the switch from the local LAN. -
Page 26: Login
Device status and Statistic Login Before you configure this device, note that when the SW-0008FP is configured through an Ethernet connection, make sure the manager PC must be set on same the IP network. For example, when the default network address of the default IP address of the Web Smart Switch is 192.168.1.254, then the manager PC should be set at... - Page 27 Figure 13. After entering the password, the main page comes up, the screen will display the device status. Figure 14. Device Status...
-
Page 28: Setup Menu
Setup Menu When the main page appears, find the Setup menu in the left side of the screen (Figure 15). Click on the setup item that you want to configure. There are eleven options: Port Settings, VLAN Settings, Trunk Settings, Mirror Settings, QoS Settings, PoE Settings, Device Status, Statistic, System Settings, Trap Setting, Password Settings, Backup Settings and Reset Settings as shown in the Main Menu screen. -
Page 29: Port Settings
Port Settings In Port Settings menu (Figure 16), this page will show each port’s status, press the ID parameter to set each port’s Speed, Flow Control, Rate Control Ingress and Egress. When you need to renew the posted information, press the “Refresh” button. The Link Status in the screen will show the connection speed and duplex mode;... -
Page 30: Vlan Settings (Virtual Local Area Network)
Flow Control: This setting determines whether or not the Switch will be handling flow control. Set FlowCtrl to Enable for avoiding data transfer overflow. Or it sets to Disable; there is either no flow control or other hardware/software management. When the 10/100M port is set to full duplex mode, then the flow control will automatically set to disable;... - Page 31 select the VID group and change the setting, and press “Apply” button to save the settings. Figure 18. When you select Port VID setting, fill in each port’s PVID value between 1 and 511, Priority value between 0 and 7. Figure 19.
-
Page 32: Trunk Setting
Trunk Setting The Trunk function enables to cascade two devices with a double times bandwidth (up to 800Mbps in full duplex mode). There are 3 selection for the trunk setting, port “01, 02”, port “01,02,03,04” or select “disable” for closing this function. Figure 20. -
Page 33: Qos Setting
RX (receive) mode: this mode will duplicate the data that send to the source and forward to the sniffer port. Both (transmit and receive) mode: this mode will duplicate both the data transmit from and data that send to the source port, then it will forward to the sniffer port. - Page 34 STRICT: The high priority packets sent before low priority packets. Disable QoS: to disable the QoS function of the Switch. Figure 23. Port Based: to set the Switch QoS by port based, select the ports which is High or Normal. Figure 24.
- Page 35 Figure 26. DSCP Based: to set the Switch QoS base on DSCP, select the priority chosing from Lowest, Low, Normal, and High.
-
Page 36: Poe Setting
Figure 27. PoE Setting When click on the PoE Setting, the status of the PoE will present on the screen, it will show the PoE Enable, Priority, Power (W), Voltage (V), Current (mA), classification and Status. -
Page 37: Device Status
Figure 28. Press “Refresh” button to refresh the status of the PoE. Press click on the ID parameter to enter to the selected port to configure the PoE settings, select enable to activate the PoE function from port 1 to port 8, and disable to deactivate the PoE function. Click “Apply”... -
Page 38: Statistic
Statistic The Statistic Menu screen will show the status of each port packet count. Figure 30. Statistic For Detail packet information, click on the ID parameter as Figure 31. Figure 31. -
Page 39: System Setting
System Setting The System Setting includes the Web Server Port, System name, Location name, Login Timeout, IP Address, Subnet Mask and Gateway. Through the Web Management Utility, you can easily recognize the device by using the System Name and the Location Name. -
Page 40: Trap Setting
Trap Setting The Trap Setting enables the device to monitor the Trap through the Web Management Utility, set the Trap IP Address of the manager where the trap to be sent. Figure 33. Trap Setting System Events: Monitoring the system’s trap. Device Bootup: a trap when booting up the system. -
Page 41: Set Password
Abnormal*: 50 error packet count within 10 seconds. PoE Events: Monitoring the PoE ports status. PoE Power fail: a trap when the port’s power source is fail or the SW-0008FP is fail. Power on/Power down: a trap when the PoE port’s power is on and down. -
Page 42: Backup Setting
Backup Setting The backup tools help you to backup the current setting of the Switch. Once you need to backup the setting, press the “Backup” button to save the setting. To restore a current setting file to the device, you must specify the backup file and press “Restore”... -
Page 43: Logout
Logout When press this function, the web configuration will go back to first Login page. Figure 37. Logout... -
Page 45: Technical Specifications
TECHNICAL SPECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3x Full Duplex Flow Control IEEE 802.3af compliant Protocol CSMA/CD Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex) Topology Star Network Cables... -
Page 46: Physical And Environmental
Physical and Environmental AC inputs 100-240V AC, 50-60 Hz internal universal power supply Power 9Watts (max. no PD Device connected) Consumption 108Watts (max. with 7 x 15.4 w PoE Device connected) Temperature Operating: 0° ~ 40° C, Storage: -10° ~ 70° C Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90% Dimensions...
