- Page 1 8-Port Gigabit Web Smart Switch SWP-0208G SWP Series L2 Managed Switch User Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENT 1.0 I ......................2 NTRODUCTION 1.1 M ......................2 EATURES 1.2 S ................... 3 TART TO ANAGE WITCH 2.0 W ......................4 EB MANAGEMENT 2.1 C ......................5 ONFIGURATIONS 2.1.1.1 S ..................5 YSTEM INFORMATION 2.1.1.2 DHCP ........................ 5 2.1.1.3 R HTTP ................ -
Page 3: Introduction
1.0 Introduction This web smart switch is a high speed switch that provides up to 8 10/100/1000Mbps copper Ethernet ports, besides, it provides many advanced function for nowadays variety of network application but at lower cost. User doesn’t have to learn many sophisticated management function which are usually shown in SNMP switch but just to learn some simple or common control or setting function through either out-of-band RS232 port or Ethernet port, however, some new, advanced and important function such as Tag-VLAN, Trunking, RSTP and IGMP are also supported same as SNMP... -
Page 4: Start To Manage This Switch
Reset to default Field-code-upgrade through web browser 1.2 Start to Manage This Switch Either way user may start to manage this switch, web mode through Ethernet port or terminal mode through RS232 port. 1.2.1 Web mode default setting are: Default IP Address: 192.168.1.254 Default IP mask: 255.255.255.0 Default gateway:... -
Page 5: Web Management
2.0 Web management After login is successfully validated, the switch’s home page will show up. The left part on the page provides the function menus, while the right part provides the individual configuration value or system parameters value. Function manuals are divided into three categories, they are Configuration, Monitoring and Maintenance, and all functions are shown briefly below... -
Page 6: Configurations
2.1 Configurations 2.1.1.1 System information The system diagram shows general common system information, they are H/W, F/W version, MAC address, IP address, subnet mask, IP gateway, default VLAN value of management port, name, password, timeout value, and SNMP communities…etc. Once user finish the setting, he must press the “ Apply “ button to execute all his setting, and whenever he needs, he may press the “... -
Page 7: Relocate Http Port Number
The default DHCP is off, so Default IP or user defined IP is used when this machine is turning-ON, but if this switch needs an IP assigned from DHCP server, user may click the square field and then press “ Apply “ to get an IP which will be assigned by DCHP server “. - Page 8 Port status page always shows current port status of all 8 ports. User can set link mode, enable or disable flow control and jumbo frame, however, be noticed that the jumbo frame is global setting, it can’t be set on individual port but on all ports at a time.
-
Page 9: Tag-Based Vlan
Port-based VLAN is a kind of VLAN which is a group of ports marked as a kind by group ID, different VLAN ( different ID ) can’t communicate to each other. Before the setting, user must be aware of that there is a default Port-based VLAN, his group ID is 1, so, if user wants to set another new port-based VLAN, better set another group ID rather than 1. - Page 10 Tag-based VLAN is another kind of VLAN which is a group of ports marked as same kind by assigning a tag-value on each port, same as port-based VLAN, different VLAN ( different ID ) can’t communicate to each other, and before the setting, there is a default tag-based VLAN, which ID is 1 ( VLAN ID=1 ), so, if user wants to create another new tag-based VLAN, better set another VLAN ID rather than 1 ( tag-based VALN ID ranged from 1 ~ 4094 ).
- Page 11 Be aware that CPU port is still remain on VID=1 group now, user can only perform web management through one of 4 ports, that is port 1,2,3,4, but if user want to perform web management from other port existing in different VLAN group, for example port 8 in VID =10, then after creating new VLAN groups, he must go to System Configuration page, and select Tag VLAN Management Group to 10 by pressing “...
- Page 12 3. Accept Packet Type: ALL - Accept all ingress frames Tagged only - Only accept ingress frames with VLAN tag 4. Port VID: Set Port VID = value ( 1 ~ 4096 ), then an untagged ingress frames will bear this value a its VID, usually this port is connected to un-tag device ( legacy device ), then this frame become a tagged frame, hence, it can be handled inside the switch as a member of same VID group.
-
Page 13: Port Trunking
2.1.5 Port Trunking A default diagram is shown below, and up to 4 groups are provided Choose and click the trunk ports you want to group, for example, choose port 1, port 2 into group 1, then press “Apply”, after execution, diagram will shown below... -
Page 14: Port Mirroring
2.1.6 Port Mirroring A default diagram is shown below, Choose and click the ports you want to monitor, for example, choose port 2 is mirror port And the mirror source is port 5. then press “Apply”, after execution, diagram will shown below... -
Page 15: Quality Of Service
2.1.7 Quality of Service There are 4 class priority can be set for each port: Low, Normal, Medium and High, because there are 8 priority levels ( 0 ~ 7 ) for each port, so 8 priorities map into 4 class must be done in this QoS control. There are 3 QoS Mode can be chosen: Port-based, 802.1P and DSCP. - Page 16 Choose the port-based priority level for each port you want to set, then ports will get priority service as setting, for example, Under Strict Mode, Port 5,6,7,8 are set “ low ”, port 1,2,3,4 are set as high, medium, normal and low. Then, after “...
-
Page 17: Storm Control
2.1.8 Storm Control A default diagram is shown below, Choose and click type of storm you want to control, for example, choose Broadcast storm with 3,964 frames per second as upper limit, once the Broadcast frame rate higher than 3,964 frames per second, this port will be disabled. Press “Apply”, after execution, diagram will be shown below... -
Page 18: Lacp
2.1.9 LACP Different from the static port trunking, LACP provides another way to dynamically aggregate port to a group (trunk) according to IEEE 802.3ad. Once the protocol is enabled, the ports to be trunked by LACP will be executed automatically after press “ apply “ A default diagram is shown below, Two parameters need to be set per port basis in this webpage: Protocol Enabled –... -
Page 19: Rstp
2.1.10 RSTP The Spanning-Tree Protocol (STP) is IEEE 802.1d standardized method for avoiding loops in switched networks. Enable STP to ensure that only one path at a time is active between any two nodes on the network. The Rapid-Spanning-Tree-Protocol (RSTP) is a more advanced protocol than STP according to IEEE 802.1w standard. - Page 20 Forward Delay -- the number of seconds a port waits before changing from its Spanning-Tree Protocol learning and listening states to the forwarding state. Enter a number 4 through 30. (default is 15) Force Version – normal: use RSTP; compatible: compatible with old STP protocol Port Configuration Aggregations –...
-
Page 21: Igmp
2.1.11 IGMP The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. IGMP can manage the multicast traffic if the members (switches, router or other network devices) of group support IGMP. This switch provides IGMP snooping feature to detect IGMP queries, report packets and manage the IP multicast traffic through the switch. -
Page 23: Ieee802.1
2.1.12 IEEE802.1x A default diagram is shown below, user must contact the manager of RADIUS server, and then get IP, UDP port number ( usually fixed at 1812 ) and secret to operate 802.1X. Admin Mode: Auto: client will be authorized by authentication process Force Authorized: client will be authorized anyway Force Unauthorized: client won’t be authorized anyway Action: means execute command on single port or all ports when click... -
Page 24: Monitoring
2.2 Monitoring 2.2.1. Port Statistics Choose and click command manual, after execution, diagram will shown below, user can clear counter or refresh as will 2.2.2 LACP Status Choose and click command manual, after execution, diagram will shown like below, user can refresh as will... -
Page 25: Rstp Status
2.2.3 RSTP Status Choose and click command manual, after execution, diagram will shown like below, user can refresh as will... -
Page 26: Igmp Status
2.2.4 IGMP Status Choose and click IGMP status at command, after execution, diagram will be shown like below, user can refresh as will. There are IGMP v1, v2,v3 frames will be shown in the network, our switch only support IGMP V2, but it will handle some IGMP V3 frames. -
Page 27: Maintenance
2.3 Maintenance 2.3.1 Warm Reboot Choose and click command manual, diagram will shown like below, user can press Yes or No Warm Reboot Are you sure you want to perform a warm reboot? 2.3.2 Factory Default hoose and click command manual, diagram will shown like below, user can press Yes or No Factory Default Are you sure to reset configurations to factory default? 2.3.3 Firmware Update... -
Page 28: Config File
2.3.4 Config File Choose and click command manual, diagram will be shown, and then direct the location of the file that is to be backup, give a name, then press “ Backup “ Configuration File Backup Backup Choose and click command manual, diagram will be shown, and then direct the location of the file that to be restored, then press “... - Page 29 Once terminal is connected, enter the password, the basic operation are shown, and then when press “ ? “ the commands at top level will be shown as below Key in “ Command “ and then key in “ ? “, second level will be shown , for example...
- Page 30 If user wants to check the IP related information, he may do as below All other function can be operating likewise. Type「up」or 「/」 go back to previous page...
- Page 31 5％～90％（non- condensing） Dimension 252(W)×44(H)×125(L) mm Weight 1.6kg FCC Class A、CE Class A、VCCI Class A Package Contents SWP-0208G, Power cord, Users manual CD-ROM Option Module Mode : MGBIC-SX-P Mode : MGBIC-LX-P 1000BASE-SX (LC Connector) Mini GBIC Module 1000BASE-LX(LC Connector) Mini GBIC Module...
-
Page 32: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
