Summary of Contents for Planex SF-0424F
-
Page 2: Installation Method
The Switch Quick Installation Guide Step 1 Installation The site where you place the may greatly affect its performance. When Switch installing, take the following into your consideration. 1.1 Installation method Follow the guidelines below to install the Switch. Install the Switch in a fairly cool and dry place. See the Technical Specifications for the acceptable temperature and humidity operating ranges. -
Page 3: Connecting The Switch
The Switch Quick Installation Guide Step 2 Connecting the switch This chapter describes how to connect the Switch to your Fast Ethernet network. 2.1 PC to Switch Figure 2-1 PC to Switch A PC can be connected to the Switch via a two-pair Category 3, 4, or 5 UTP/STP straight-through Cable. - Page 4 The Switch Quick Installation Guide to determine the transmission mode for any new twisted-pair connection: If the attached device does not support auto negotiation or has auto-negotiation disabled, an auto sensing process is initiated to select the speed and set the duplex mode to half-duplex.
-
Page 5: Web-Based Management
The Switch Quick Installation Guide Step 3 Management This chapter describes three management methods of the Switch. Web-based management Console management Telnet management SNMP provides v1/v2 3.1 Web-based management The Switch has a Web GUI interface for switch configuration. The Switch can be configured through the Web browser. -
Page 6: Console Management
The Switch Quick Installation Guide NOTE: The factory-default IP Address : 192.168.2.11 Through the Web Management Utility, you do not need to remember the IP Address; select the device shown in the Monitor List of the Web Management Utility to settle the device on the Web browser. - Page 7 The Switch Quick Installation Guide To start using the Console Management program, first connect an EIA-232 serial cable to a COM port on a PC or notebook computer and to the Console Port on the rear panel of the Switch. Note: do not use a null modem cable. If you are using Microsoft Windows, boot up the computer, go to “Start”...
- Page 8 The Switch Quick Installation Guide Figure 1-4 2. Select the COM port that you are using for this connection and click “OK”. Figure 1-5...
-
Page 9: Telnet Management
The Switch Quick Installation Guide 3. Setup the COM port properties by using the information below and click “OK”. Figure1-6 NOTE: The console port is set at the factory for the following configuration: Baud rate: 9,600 Data width: 8 bits Parity: none Stop bits: 1 Flow Control: None... - Page 10 The Switch Quick Installation Guide management through Telnet, over the Ethernet LAN network or even over internet. If you are using Microsoft Windows, boot up the computer, go to “Start”-“Run”. Enter ” Telnet 192.168.2.11”, Click “ ok”. Figure 1-7 the main page After connected successful please enter”...
- Page 11 The Switch Quick Installation Guide NOTICE: The factory-default User name is “guest”. Pass word is “guest”...
