- Page 1 CX-A200 Amplifier Installation & User Guide Cloud Electronics Limited 140 Staniforth Road, Sheffield, S9 3HF England Tel +44 (0)114 244 7051 Fax +44 (0)114 242 5462 e-mail info@cloud.co.uk web site http://www.cloud.co.uk...
-
Page 2: Table Of Contents
CX-A200 I NSTALLATION AND OPERATION MANUAL CX-A200 Amplifier Installation and operation manual Contents Section Page Safety Notes................2 General Description..............2 Installation ..................2 Input Facilities ................3 Output Details................5 100V Line operation ..............5 Bridged Mode Operation ............5 Status Indicators.................5 VCA Modules ................5 Fitting VCA Module ..............6 Remote Level Connections ............6... -
Page 3: Safety Notes
The CX-A200 is supplied with a power cable fitted with a moulded plug. If the plug is cut off the lead for any reason, remember that the discarded plug is a potential hazard and should be disposed of in a responsible manner. -
Page 4: Input Facilities
CX-A200 I NSTALLATION AND OPERATION MANUAL Input Facilities All four inputs are balanced and use 3 pin XLR type connectors. All inputs are wired to the standard convention of pin 1 ground, pin 2 in-phase, pin 3 reverse phase, with the shell of the connector connected to the chassis. - Page 5 CX-A200 I NSTALLATION AND OPERATION MANUAL POWER AMPLIFIER LEVEL CONTROL SOURCE JUMPERS INPUT AMPLFIER INPUT 1 INPUT 2 FROM STEREO SOURCE TWO STEREO PAIRS FROM ONE STEREO SOURCE POWER AMPLIFIER LEVEL CONTROL SOURCE JUMPERS INPUT AMPLFIER INPUT 1 INPUT 2...
-
Page 6: Output Details
100 watt 8 ohm outputs. Status Indicators The front panel of the CX-A200 has an array of LED's which indicate the status of all four channels. The lower green LED illuminates when a signal exceeding 500mW is detected, the yellow 'peak' LED will illuminate when the amplifier output is close to clipping and the top red LED indicates that the protection relay has disconnected the load. -
Page 7: 10 Fitting Vca Module
Plate Connections' for wiring details. Fitting a VCA Module Remove the power cable before commencing. Remove the top panel from the CX-A200 then remove the relevant connector cover from the rear panel of the unit. Locate the 10 pin male header (CON1 for inputs 1 & 2 and CON2 for inputs 3 & 4) then remove the two jumpers from the 10 way header (male connector). -
Page 8: 12 Field Servicing
NSTALLATION AND OPERATION MANUAL Field Servicing The CX-A200 is ruggedly built and uses proven reliable circuitry. It requires no more than the occasional removal of any dust that may have built up inside the unit as a result of the forced cooling. -
Page 9: Safety Considerations
CX-A200 I NSTALLATION AND OPERATION MANUAL This product conforms to the following European Standards EN 50081-1: 1992 EN 50082-1: 1992 EN 60065 : 1994 SAFETY CONSIDERATIONS CAUTION - MAINS FUSE TO REDUCE THE RISK OF FIRE REPLACE THE MAINS FUSE ONLY WITH THE SAME TYPE, WHICH MUST BE A CLASS 3, 240 VOLT, TIME DELAY TYPE, RATED AT 3.15A WHERE THE MAINS INPUT VOLTAGE IS SET TO...
