- Page 1 Car radio DVD-player with Bluetooth ® and 3“ touch screen display ALD1915H ACAD30B User manual Gebruiksaanwijzing NL 27 Manuel de l’utilisateur FR 54 Manual de instrucciones ES 81 Gebrauchsanleitung DE 108 Οδηγίες χρήσεως EL 136 Brugsanvisning DA 164...
-
Page 2: Table Of Contents
Table of contents Safety ................3 Intended use ..............3 Labels in this manual ............3 General safety instructions ..........3 Preparations for use ........... 4 Unpacking ................4 Package contents ............4 Installation ..............5 ISO Cable Connection .............6 Connecting wires .............7 Connecting random equipment ........8 Remote control..............8 Functions .............. -
Page 3: Safety
ACAD30B Safety Intended use The Car Radio with DVD player and touch screen plays music and video from CD, DVD, USB device, memory card and radio. Read the manual carefully before the first use. Due to the great variety of products with external memory connection (USB, SD/MMC, etc.) and their sometimes quite manufacturer-specific functions we can neither guarantee that all devices will be recognised, nor that all operating options that are... -
Page 4: Preparations For Use
CAUTION Do not block the ventilation holes. This appliance employs a laser system. To prevent direct exposure to the laser beam, do not open the appliance. Visible laser radiation when open and interlock defeated. Preparations for use Unpacking ● Unpack the appliance carefully. ●... -
Page 5: Installation
ACAD30B 2x ISO Wire Cable Operator manual If any item is missing, please contact your reseller. Installation This unit can be installed in any dashboard having an opening as shown in the picture. The dashboard should be 4.75 - 5.56 mm thick in order to be able to support the unit. -
Page 6: Iso Cable Connection
● Secure the rear of the unit to the support strap, using the bolts, nuts, and washers provided. ● Connect the appliance to the electrical circuit. Read the paragraph "ISO Cable Connection". ● Connect the random equipment to the appliance. Read the paragraph "Connecting random equipment". -
Page 7: Connecting Wires
ACAD30B ISO B CONNECTOR Front speaker B3 Right + (Gray) B4 Right - (Gray/Black) B5 Left + (White) B6 Left - (White/Black) Rear speaker B1 Right + (Violet) B2 Right - (Violet/Black) B7 Left + (Green) B8 Left - (Green/Black) Connecting wires Parking GREY/WHITE:... -
Page 8: Connecting Random Equipment
Connecting random equipment Audio connections (output) ● AUDIO OUT: Connect a suitable cable to the L/R channels of the AUDIO OUT connection. ● REAR: Connect a suitable cable to the L/R channels of the REAR connection. ● FRONT: Connect a suitable cable to the L/R channels of the FRONT connection. -
Page 9: Functions
ACAD30B Functions Control panel 10 11 1314 POWER button 11 TRACK SEARCH UP button / MUTE button PRESET STATION 6 FUNCTION button 12 TA button PAUSE button / PRESET 13 A/PS button STATION 1 14 PTY button INTRO button / PRESET 15 Line in jack STATION 2 16 USB slot... -
Page 10: Remote Control
Behind control panel 23 EJECT button 24 RESET button RESET 25 Disc slot 26 Memory card slot Back panel 27 Bluetooth antenna 28 Bluetooth external microphone Remote control 29 POWER button 30 MODE button 31 GOTO button 32 DUAL button 33 SUB-T button 34 SETUP button 35 EQ/ANGLE button... -
Page 11: Operation
ACAD30B 51 * button 52 # button 53 AF button 54 TA button 55 TRACK SEARCH DOWN button 56 TRACK SEARCH UP button 57 RPT/APS button 58 INT button 59 STOP button 60 VOL+ button 61 SEEK+/NEXT button 62 Arrow buttons 63 MENU button 64 PBC/Title button 65 STEP button... -
Page 12: General Functions
● Place the control panel into the case and take it with you when you leave the car. WARNING Do not install or remove the control panel while driving your car. CAUTION ● Do not insert the control panel from the right side. It can damage the control panel. -
Page 13: Radio Functions
ACAD30B ● To access the TREBLE control, press the FUNCTION button (3) once again. To adjust the level, turn the VOLUME dial (3) until the desired level is set. ● To access the BALANCE control, press the FUNCTION button (3) once again. - Page 14 Programming radio stations Per radio band (FM1, FM2, FM3), 6 radio stations can be preset. ● Search for a radio station. ● Press the PRESET STATION button (4-6 & 9-11) for more than 1 second to store the station under the desired preset number. Using the PTY function ●...
-
Page 15: Cd Functions
ACAD30B ● Long press the button to switch regional mode ON or OFF: • ON: the search for alternative frequencies and the AUTO SEEK function are limited to the stations with the same regional code as the current radio station •... -
Page 16: Dvd/Cd Functions
● To play the first 10 seconds of each track on the disc, press the INT button (58). Press the button again to cancel the function. ● Press the RPT button (57) once to repeat the current track. The display shows the message "RPT ON". - Page 17 ACAD30B ● To view a specific title of a DVD, press the TITLE button (64). Use the arrow buttons to select the title. ● To select the audio language of a DVD, press the AUDIO button (37) repeatedly until the desired language is set. ●...
- Page 18 Using the PROGRAM function ● Press the button to enter the PROGRAM function. ● Press the digit buttons to select a desired track, and use the arrow button down to highlight the next entry. ● To confirm the selection and start the program, move the highlight to "START"...
-
Page 19: Usb Functions
ACAD30B ● Press the PAUSE button (67) to resume the slide show. ● To flip the image vertical or horizontal, press the up/down arrow buttons (62). ● To rotate the image left or right, press the left/right arrow buttons (62). ●... -
Page 20: Bluetooth Functions
● Refer to the instructions under "CD functions" for explanation of the functions available during playback. ● To remove the device, gently pull it out of the slot. Bluetooth functions Pairing Before Bluetooth can be used the appliances must be paired. ●... -
Page 21: Advanced Functions
ACAD30B Search by track number ● Press the A/PS button (57) once. ● Turn the VOLUME dial (3) to select the track number that you are looking for. ● Press the FUNCTION button (3). The selected track will be played. Search by file name ●... -
Page 22: Resetting The Appliance
● Connect AUDIO OUT and VIDEO OUT to the LIN IN of the external AV appliance. ● Press and hold MD (30). ● Select the memory card of USB source. ● Press DUAL (32): (T=TUNER, C=CARD, U=USB, D=DISC). 5.11 Resetting the appliance If any of the buttons on the appliance does not operate or if the error symbol appears on the display, the appliance needs to be reset. -
Page 23: Cleaning And Maintenance
ACAD30B VIDEO SETUP: Settings in VIDEO SETUP mode: ● BRIGHTNESS: to adjust the screen brightness. ● CONTRAST: to adjust the screen contrast. ● HUE: to adjust the screen hue. ● SATURATION: to adjust the screen saturation. ● SHARPNESS: to adjust the screen sharpness. Cleaning and maintenance Cleaning the cabinet Wipe with a soft cloth. -
Page 24: Troubleshooting
● Do not bend or press the disc. Do not expose the disc to direct sunlight or heating sources. ● Clean the disc surface with a soft, dry cleaning cloth. Wipe the disc surface gently, radially, from centre towards the outer edge. ●... -
Page 25: Usb Playback
ACAD30B MP3 playback Trouble Action No sound or incomplete audio If MP3 data is mixed with other files on CD, the appliance may play the non-MP3 files as noise or without sound or it rejects the disc. Check if the played file is in MP3 format or select another file to play. -
Page 26: Disposal Of Used Electrical And Electronic Equipment
For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu...
