- Page 1 TS-AVE3 USER’S MANUAL ® Intel Socket 370 Celeron ® Pentium III FC-PGA Series Transcend Your Supplier, Your Partner, Your Friend.
- Page 2 This is even if Transcend has been advised of the possibility of such damages arising from any defect or error in this manual or product.
-
Page 3: Table Of Contents
1.3 Package Contents ....................2 1.4 Specifications and Features ...................3 CHAPTER 2 HARDWARE INSTALLATION 2.1 Transcend’s TS-AVE3 Motherboard ............... 5 2.2 Layout of Transcend’s TS-AVE3 Motherboard ..........6 2.3 CPU Installation .................... 7 2.4 66/100/133MHz System Configuration ............10 2.5 Memory Configuration ................... 10 2.6 Primary/Secondary IDE Connectors ............. - Page 4 CHAPTER 3 BIOS SETUP BIOS Setup....................21 The Main Menu ................... 21 Standard CMOS Features................23 Advanced BIOS Features................26 Advanced Chipset Features ................29 Integrated Peripherals ................32 Power Management Setup................. 35 PnP/PCI Configurations ................38 PC Health Status................... 41 3.10 Frequency/Voltage Control ................
-
Page 5: Chapter 1 Introduction
INTRODUCTION CHAPTER 1 INTRODUCTION 1.1 Essential Handling Precautions IMPORTANT. Read this page before unpacking your motherboard! • Power Supply Be careful! Always ensure that the computer is disconnected from the power supply when working on the motherboard and its components. •... -
Page 6: Checklist: Hardware Required For Setup
This motherboard package should contain the following items. Please check them as soon as you unpack. If you find any damaged or missing items, please contact your retailer. - TS-AVE3 motherboard - 1 x CD-ROM - 1 x FDD cable - 1 x Ultra DMA/66 cable - User ’s Manual... -
Page 7: Specifications And Features
• • • • • CPU - Supports Intel Socket 370 Celeron - Supports Intel Pentium III FC-PGA • • • • • Chipset -TS-AVE3: VIA 694X/686A AGPset -TS-AVE3/B: VIA 694X/686B AGPset • • • • • DRAM Memory - Supports Synchronous DRAM... - Page 8 INTRODUCTION • Award BIOS - Support Plug-and-Play, PC98 - Support ACPI, APM, DMI and Green Feature - Easy BIOS Recovery • Wake Up Features - Supports Wake-on-LAN function - Remote Ring Wake Up - Time Wake Up • PCB Dimensions - ATX form factor, 4-layer PCB, 19cm x 30.5cm (8 inch x 12 inch) •...
-
Page 9: Chapter 2 Hardware Installation
HARDWARE INSTALLATION CHAPTER 2 HARDWARE INSTALLATION 2.1 Transcend’s TS-AVE3 Motherboard I/O Port I/O Port Memory General MIDI Port & Audio Jack · · ® Intel Celeron Socket 370 PPGA 3 x 168 -pin DIMM Sockets · (Line-In, Line-Out, MIC-In) ·... -
Page 10: Layout Of Transcend's Ts-Ave3 Motherboard
HARDWARE INSTALLATION 2.2 Layout of Transcend’s TS-AVE3 Motherboard KB MOUSE PS/2 ATX Power Connector T : M o s e B:Keyboard U S B T:Port 1 B:Port 2 C O M B 6 9 4 X Chipset C O M A... -
Page 11: Hardware Installation
HARDWARE INSTALLATION 2.3 CPU (Central Processing Unit) Installation So far you have familiarized yourself with the handling precautions, checked you have all of the necessary hardware for building your system, inspected the motherboard package contents and looked at the layout of the motherboard. This chapter will take you step by step through the process of installing the different hardware devices onto it. -
Page 12: Cpu Installation
HARDWARE INSTALLATION Step 2: Next, according to the CPU type you install, short JP7 and set JP2 to short pin1 & pin2 (for an Intel ® Celeron or Pentium ® III FC-PGA series CPU), or open JP7 and set JP2 to short pin2 &... -
Page 13: 66/100/133Mhz System Configuration
HARDWARE INSTALLATION 2.4 66/100/133MHz System Configuration The jumper (JP4) allows you to set the FSB (Front Side Bus) for 66, 100 or 133MHz configuration. When you set the FSB to 66MHz, you can select a system bus frequency from 66MHz to 95MHz through “CPU Host/PCI Clock”... -
Page 14: Memory Configuration
HARDWARE INSTALLATION 2.5 Memory Configuration This motherboard must be installed with DIMMs (Dual Inline Memory Modules). The DIMMs must be 3.3 Volt synchronous DRAM modules. The VIA Apollo Pro 133A chipset supports PC100, PC133 and Virtual Channel Memory (VCM). It also supports ECC (Error Checking and Correcting) modules. -
Page 15: Primary/Secondary Ide Connectors
HARDWARE INSTALLATION 2.6 Primary / Secondary IDE Connectors (Two 40-pin IDE) This mainboard supports two 40-pin IDE connectors marked as IDE1 (primary IDE channel) and IDE2 (secondary IDE channel). Each channel supports two IDE devices, making a total of four devices. Connect your Hard Disk (the main one if you are using more than one) to the “Master”... -
Page 16: Floppy Disk Drive Connector
HARDWARE INSTALLATION 2.7 Floppy Disk Drive Connector (34-pin FDC) This connector supports the provided floppy disk drive ribbon cable. After connecting the single end to the board, connect the two plugs on the other end to the floppy drives. Note: Orient the red stripe to Pin1 Floppy Drive Connector F D C... -
Page 17: Wake-On-Lan Connector
HARDWARE INSTALLATION 2.9 Wake-on-LAN Connector (3-pin WOL) This connector connects to LAN cards with a Wake-on-LAN output. The system can be Power up when a wakeup packet or signal is received from the LAN card. NOTE: This function requires that the “LAN Wake Up” function in the POWER MANAGEMENT SETUP is set to “Enabled”... -
Page 18: Panel Connectors
HARDWARE INSTALLATION 2.11 Panel Connectors P O W E R L E D S P E A K E R S _ L E D H D _ L E D S L E E P R E S E T S O F T _ O F F Panel Connectors Power LED Lead (3-pin POWER LED) - Page 19 HARDWARE INSTALLATION Sleep Button Lead (2-pin SLEEP) Pin10 : SLEEP Pin12 : GND Reset Switch Lead (2-pin RESET) This 2-pin connector connects to the case-mounted reset switch for rebooting your computer without turning off your power switch. Pin14 : RESET Pin16 : GND Software Power-Off Lead (2-pin SOFT_OFF) Attach the SOFT_OFF Switch of the panel to this connector.
-
Page 20: Power Connector
HARDWARE INSTALLATION 2.12 Power Connector (20-pin PWR-CONN) Make sure to plug the ATX power supply connector in the right direction. The pin definition is shown below. Make sure that your ATX power supply can support at least 720mA on the standby lead. -
Page 21: Using Jumper Jps To Clear Cmos
HARDWARE INSTALLATION 4. Parallel Port 7. Game/MIDI Port (Printer) 1. PS/2 Mouse 3. USB1 3. USB2 5. COMB COMA 9. Line-in 2. PS/2 Keyboard 8. Line-out 10. MIC-in External Back Panel I/O Ports 2.14 Using Jumper JPS to Clear CMOS To clear the CMOS data, you should turn off your computers power and short pin1 and pin2 of JP5. -
Page 22: Onboard Audio Setting
HARDWARE INSTALLATION 2.15 Onboard Audio Setting (9-Pin JP6) For an external AMR card, the onboard audio CODEC can be enabled or disabled via this jumper. Please disable the onboard audio CODEC, if you want to use an AMR Sound Card. Note : If you want to use a PCI Sound Card with audio controller on it, please disable the “OnChip Sound”... -
Page 23: Internal Audio Connectors
HARDWARE INSTALLATION 2.16 Internal Audio Connectors These connectors allow you to receive stereo audio input from sound sources such as a CD- ROM, TV tuner, or MPEG card. The MODEM connector allows the onboard audio to interface a voice modem card with a matched connector. It also allows the sharing of mono_in (such as a phone) and mono_out (such as a speaker) between the onboard audio and the voice modem card. -
Page 24: Internal Usb Port Connector
HARDWARE INSTALLATION 2.17 Internal USB Port Connector (10-Pin USB3/4) You can use the provided serial port bracket to add a serial port for additional serial devices. Regarding the onboard COMA, please refer to Section 2.13 “External Back Panel I/O Ports” (page 20). -
Page 25: Chapter 3 Bios Setup
BIOS SETUP CHAPTER 3 BIOS SETUP 3.1 BIOS Setup Award BIOS has a built-in Setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM, so it can retain the Setup information when the power is turned off. When the CMOS battery fails, it will cause the data to be lost. If that happens, please set up your configuration parameters again after replacing the battery. -
Page 26: Standard Cmos Features
BIOS SETUP Increase the numeric value or make changes Decrease the numeric value or make changes [F1] General help on setup navigation keys [F5] Load previous values from CMOS [F6] Load the Fail-Safe Defaults from BIOS default table [F7] Load the Optimized Defaults [F10] Save all CMOS changes, and exit The following is a brief summary of each setup category •... - Page 27 BIOS SETUP • Set Supervisor / User Password To change, set, or disable a password • Save & Exit Setup To save settings in nonvolatile CMOS RAM and exit Setup • Exit Without Saving To abandon all changes and exit Setup 3.3 Standard CMOS Features •...
- Page 28 BIOS SETUP • IDE HDD Auto-Detection : Detect the HDD on this channel. If the detection is successful, it fills the remaining fields on this menu. • IDE Primary/Secondary Master/Slave : We recommend that you select “AUTO” for all drives. The BIOS can automatically detect the specifications during POST (Power On Self Test) while the system boots.
- Page 29 BIOS SETUP • Drive A / Drive B Select the correct types of diskette drive(s) installed in the computer. - None : No diskette drive installed - 360K, 5.25 in. : 5-1/4 inch standard drive; 360 kilobyte capacity - 1.2M, 5.25 in. : 5-1/4 inch high-density drive; 1.2 megabyte capacity - 720K, 3.5 in.
- Page 30 BIOS SETUP 3.4 Advanced BIOS Features The “Advanced BIOS Features” option allows you to improve your system performance and sets up system features according to your preference. • Virus Warning When this function is enabled, you will receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive.
-
Page 31: Cpu L2 Cache Ecc Checking
BIOS SETUP • CPU Internal Cache / External Cache Cache memory is additional memory that is much faster than conventional DRAM (system memory). CPUs from 486-type and up contain internal cache memory. Most, but not all, modern PCs have additional (external) cache memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory for even faster accessed by the CPU. -
Page 32: Swap Floppy Drive
BIOS SETUP • First / Second / Third Boot Device; Boot Other Device The original IBM PCs loaded the DOS operating system from drive A (floppy disk). Therefore, IBM PC-compatible systems are designed to search for an operating system first on drive A, and then on drive C (hard disk). -
Page 33: Security Option
BIOS SETUP • Typematic Rate (Chars/Sec) When the Typematic Rate setting is enabled, you can select a typematic rate (the rate at which characters repeat) to “6”, “8”, “10”, “12”, “15”, “20”, “24” or “30” characters per second. • Typematic Delay (Msec) When the Typematic Delay setting is enabled, you can select a typematic delay (the delay before key strokes begin to repeat) of “250”, “500”, “750”... - Page 34 BIOS SETUP 3.5 Advanced Chipset Features This option will change the values of the chipset registers and the system setting will alter. Do not change any values if you are unfamiliar with the chipset. • Bank 0/1, 2/3, 4/5, DRAM Timing The DRAM timing of Bank 0/1, 2/3, 4/5 is determined by the Memory modules which are plugged on the motherboard.
-
Page 35: System Bios Cacheable
BIOS SETUP • Memory Hole At 15M-16M Enabling this feature reserves memory address space (between 15 and 16MB) to ISA expansion cards that specifically require this setting. This makes between 15 and 16MB of memory unavailable to the system. Expansion cards can only access memory up to 16MB. The default setting is “Disabled”. -
Page 36: Pci Dynamic Bursting
BIOS SETUP • • • • • On Chip Sound Select “Auto” to enable the OnChip Audio Controller, which lets you use OnBoard CODEC or Add-On CODEC on the AMR card (depend on the JP setting). If you use an Add-On Audio Card with an Audio Controller built-in, please set this field to “Disabled”. - Page 37 BIOS SETUP • Memory Parity / ECC Check When parity DRAM modules are installed, select “Enabled” to correct 1 bit memory errors in the memory. Otherwise, select “Disabled”.
-
Page 38: Integrated Peripherals
BIOS SETUP 3.6 Integrated Peripherals Choose this option and the following display appears. • • • • • On-Chip IDE Channel O/Channel 1 The chipset contains a PCI IDE interface which supports two IDE channels. Select “Enabled” to activate the first and/or second IDE interface. Select “Disabled” to deactivate this interface, if you install a primary and/or secondary add-in IDE interface. -
Page 39: Init Display First
BIOS SETUP • • • • • Primary/Secondary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Mode 0 through 4 provide successively increased performance. - Page 40 BIOS SETUP • • • • • Onboard FDD Controller You can use this function to enable or disable the onboard FDD controller. • • • • • Onboard Serial Port 1 / Port 2 Select an address and the corresponding interrupt for each of the first and second serial ports.
- Page 41 BIOS SETUP • • • • • Onboard Parallel Mode This field allows you to set the operation mode of the parallel port. - Normal: Allows normal-speed operation, but in one direction only. - EPP: Allows bidirectional parallel port operation at maximum speed. - ECP: Allows DMA and bidirectional operation.
- Page 42 BIOS SETUP 3.7 Power Management Setup The Power Management Setup allows you to configure your system to minimize energy consumption, according to your own style of computer use. • ACPI Function This item allows you to enable/disable the Advanced Configuration and Power Interface (ACPI).
- Page 43 BIOS SETUP This category allows you to select the type (or degree) of power saving and is directly related to the following modes. 1. Suspend Mode 2. HDD Power Down 3. Doze Mode There are three selections for Power Management. Two of them have fixed mode settings. 1.
-
Page 44: Video Off Method
BIOS SETUP • • • • • ACPI Suspend Type Select the ACPI Suspend Type : “S1 (POS)” or “S3 (STR)”. If your expansion cards do not support the STR function, you must leave this field on “S1 (POS)” setting. STR (Suspend-to-RAM) is an energy-saving feature. It takes only a few seconds to wake up the system and return H to its previous situation. - Page 45 BIOS SETUP • State After Power Failure State After Power Failure -On : After a power failure, the system will automatically reboot as soon as power is restored. -Off : After a power failure, the system will not reboot when power is restored. The system needs to be turned on again manually.
-
Page 46: Irqs Activity Monitoring
BIOS SETUP • MODEM Ring WakeUp Select “Enabled” to Power On your system when the external modem receives a call. NOTE:This function requires an external modem which supports the Ring Wake-Up function. • RTC Alarm WakeUp Select “Enabled” if you want to Power On your system at a certain time on the same day every month or at a certain time every day. - Page 47 BIOS SETUP 3.8 PnP/PCI Configurations • PnP OS Installed This field allows you to use a Plug-and-Play (PnP) operating system to configure the PCI bus slots instead of using the BIOS. Thus interrupts may be re-assigned by the OS when “Yes”...
- Page 48 BIOS SETUP • IRQ Resources • IRQ-n Assigned to When the resources are controlled manually, assign each system interrupt to one of the following, depending on which type of device is using the interrupt. - PCI/ISA PnP devices, whether designed for PCI or ISA bus architecture, compliant with the Plug and Play standard.
- Page 49 BIOS SETUP • DAM-n Assigned to Just as the IRQ Resource Assignment, you can assign DMA Resources manually. • PCI / VGA Palette Snoop Some VGA cards, such as graphics accelerators or MPEG video cards, might not show colors properly. Select “Enabled” to correct this problem. If you don’t have such problems, leave this field at “Disabled”.
-
Page 50: Current Cpu Temperature
BIOS SETUP • Current CPU Temperature This field displays the current CPU temperature. • Current System TEMP This field displays the current system temperature. • Current CPU / Case Fan Speed These fields display the fan speeds of the CPU, Power and Case. •... - Page 51 BIOS SETUP 3.11 Load Fail-Safe Defaults This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. NOTE: These default settings are non-optimal and disable all high performance features. 3.12 Load Optimized Defaults This option allows you to load the default values to the system configuration fields. These default values are the optimized configuration settings for the system.
-
Page 52: Supervisor Password
BIOS SETUP 3.13 Supervisor Password This option allows you to set a password to prevent others from changing the BIOS setting of your system. The password prevents any unauthorized use of your computer. If you set a password, the system prompts for the correct password before you boot or access “Setup”. To set a password: 1. -
Page 53: User Password
BIOS SETUP Forget the password? If you forget the password, you can clear it by erasing the CMOS Real Time Clock (RTC) RAM with jumper 5 (JP5: CMOS_CLR. Please refer to page 22). To erase the RTC RAM: 1. Unplug your computer. 2. -
Page 54: Save & Exit Setup
BIOS SETUP 3.15 Save & Exit Setup Save the setting and exit the BIOS utility. 3.16 Exit Without Saving Abort the current change and exit the BIOS utility. -
Page 55: Chapter 4 Bios Upgrade
BIOS.) 4.2 Download Correct BIOS File from Our Web Site Please enter Transcend web site : http://www.transcendusa.com/ Choose BIOS upgrade environment. The BIOS file name consists of 5 characters. Check the exact BIOS to download. Your BIOS file name must absolutely match the one shown on our web site. -
Page 56: How To Upgrade Your Motherboard Bios
BIOS UPGRADE 4.3 How to Upgrade Your Motherboard BIOS Please follow these 5 steps listed below to update your BIOS. Step 1: Make a record of your original or existing BIOS Setup parameters. -Press [Del] during the power On self Test to enter BIOS Setup Program when you start your system.
