  • Page 1 TS-AAP12 Intel Pentium II, III Series USER S MANUAL Transcend Your Supplier, Your Partner, Your Friend.

  • Page 2: User's Notice

    All information within this document has been carefully checked. However, Transcend Information, Inc. (hereinafter re- ferred to as “Transcend”) carries no responsibility on liability to any error or inaccuracy which might occur in this manual, including the products and soft- ware mentioned in it.
  • Page 3 Table of Contents CHAPTER 1 INTRODUCTION CHAPTER 2 HARDWARE INSTALLATION...
  • Page 4 CHAPTER 3 BIOS SETUP CHAPTER 4 BIOS UPGRADE...
  • Page 5 INTRODUCTION CHAPTER 1 INTRODUCTION 1.1 Package Contents 1.2 Specifications and Features • • • • • CPU • • • • • Chipset • • • • • DRAM Memory • • • • • I/O BUS Slot • • • • • I/O Functions...
  • Page 6 INTRODUCTION ® • Award BIOS • Wake Up Features • PCB Dimensions...

  • Page 7: Hardware Installation

    HARDWARE INSTALLATION CHAPTER 2 HARDWARE INSTALLATION 2.1 Transcend TS-AAP12 Motherboard * T:PS/2 Mouse ATX Power Slot 1 **B:PS/2 Keyboard Connector * T:USB1 **B:USB2 3 DIMM Sockets Freq.-Ratio **B:COMB DIP Switch *T:Parallel Port 693/693A Chipset **B:COMA 2 IDE Connectors AGP Port...
  • Page 8 HARDWARE INSTALLATION 2.2 Layout of Transcend TS-AAP12 Motherboard KB MOUSE POWER-FAN CPU-FAN PS/2 T:Mouse B:Keyboard T:Port 1 B:Port 2 COMB CPU Freq.-Ratio DIP Switch Printer 3/693A hipset COMA Transc cend Wake-on-LAN PCI Slot1 (PCI1) PCI Slot2 (PCI2) SB_Link PCI Slot3 (PCI3)
  • Page 9 HARDWARE INSTALLATION 2.3 CPU Installation •UNIVERSAL RETENTION MODULE (URM) INSTALLION ON MODULE UNIVERASAL RETENTIO LOCK 1. Before installing the UNIVERASAL RETENTION MODULE, pull the supporting EARs 90 outward until you hear a “Click” and both EARs sit upright in the notches of the main body. OPEN 2.
  • Page 10 HARDWARE INSTALLATION •The Intel Processor Type Intel Celeron Intel Celeron Intel Celeron Intel Processor II Intel Processor II Intel Processor II Intel Processor III Intel Processor III Intel Processor III Intel Celeron Intel Celeron Intel Processor II Intel Processor II Intel Processor III Intel Processor III Processor...
  • Page 11 HARDWARE INSTALLATION •The Intel Processor Installion Setp1: Slide the Processor into the URM Assembly and insert it in Slot1,while making sure that the heat sink assembly is facing towards the chipset, as shown in the figure .press down firmly on the cpu until it is fully seated in the Slot1 connector Important : The Slot1 connector is directionally keyed and the processor will not go in unless it is properly...

  • Page 12: 66/100Mhz System Configuration

    2.4 66/100MHz System Configuration 66/100MHz 66MHz 100MHz TS-AAP12 66/100MHz F FSB Configuration Jumper 2.5 CPU Internal Frequency Ratio Setting CPU internal frequency = frequency ratio x system bus frequency * NOTE: Because Intel has locked the frequency ratio for new CPUs, setting SW1 to ad-...
  • Page 13 1 2 3 4 : 400/600MHz 1 2 3 4 : 433/650MHz 1 2 3 4 : 466/700MHz 1 2 3 4 : 500/750MHz 1 2 3 4 : 533/800MHz 1 2 3 4 TS-AAP12 CPU Freq.- -Ratio DIP Switch Setting...

  • Page 14: Memory Configuration

    HARDWARE INSTALLATION 2.6 Memory Configuration IMPORTANT: Memory speed setup is required through “Auto Configuration“ in BIOS Chipset Features Setup. 3.3V Position Unbuffered Position 168Pin SDRAM Module (DIMM1) 168Pin SDRAM Module (DIMM2) 168Pin SDRAM Module (DIMM3) TS-AAP12 168Pin DIMM Sockets...
  • Page 15 TS-AAP12 Key yboard Wake Up 2.8 Primary / Secondary IDE Connectors (Two 40-pin IDE) Note: Orient the red stripe to Pin1 Secondary IDE Connector IDE2 IDE2 IDE2 IDE2 PIN1 IDE1 IDE1 IDE1 IDE1 PIN1 Primary IDE Connector TS-AAP12 IDE E Connectors...
  • Page 16 HARDWARE INSTALLATION 2.9 Floppy Disk Drive Connector (34-pin FDC) Note: Orient the red stripe to Pin1 Floppy Drive Connector PIN1 TS-AAP12 Floppy Disk k Drive Connector 2.10 Fan Power Connectors POWE ER-FAN +12V Rotation CPU-FAN CASE-FAN TS-APP12 Power Co onnectors...
  • Page 17 NOTE:This function requires that the Wake-on-LAN Power Up Control is set to “En- abled” and that your system has an ATX power supply with at least 720mA +5V standby power. +5 Volt Standby Ground TS-AAP12 Wake-on n-LAN Connector 2.12 IrDA-Compliant Infrared Module Connector (5-pin IrDA) IrDA IRTX IRRX TS-AAP12 IrDA Connector...
  • Page 18 HARDWARE INSTALLATION 2.13 Panel Connectors S_LED POWER LED HDD_LED KEY LOCK RESET SPEAKER SOFT_OFF TS-AAP12 Pane e l Connectors Power LED Lead (3-pin KEYLOCK) Keylock Lead (2-pin KEYLOCK) Speaker Lead (4-pin SPEAKER) Suspend Mode LED Lead (2-pin S_LED)
  • Page 19 HARDWARE INSTALLATION Harddisk LED Lead (2-pin HDD_LED) Suspend Switch Lead (2-pin SUS) Reset Switch Lead (2-pin RESET) Software Power-Off Lead (2-pin SOFT_OFF) 2.14 Power Connector (20-pin PWR-CONN) PWR-CONN PSON# : Power Supply on wer Connectors TS-AAP12 Pow...

  • Page 20: External Connectors

    HARDWARE INSTALLATION 2.15 External Connectors 1. PS/2 Mouse . Parallel Port (Printer) 3. USB1 3. USB2 2. PS/2 Keyboard 5. C COMB 5. COMA TS-AAP12 Exte ernal Connectors...

  • Page 21: Sb-Link Connector

    HARDWARE INSTALLATION 2.16 Clear CMOS Jumper (3-pin JP4) CMOS_CLR Default TS-AAP12 Clear CM MOS Jumper 2.17 SB-Link Connector ® PCPCIGNTN DGND PCPCIREQN DGND SEPIRQ TS-AAP12 SB-Link k Connector...

  • Page 22: Bios Setup

    BIOS SETUP CHAPTER 3 BIOS SETUP 3.1 BIOS Setup 3.2 The Main Menu...
  • Page 23 BIOS SETUP • STANDARD CMOS SETUP • BIOS FEATURES SETUP • CHIPSET FEATURES SETUP • POWER MANAGEMENT SETUP • PnP/PCI CONFIGURATION • LOAD BIOS DEFAULTS • LOAD SETUP DEFAULTS • INTEGRATED PERIPHERALS...
  • Page 24 BIOS SETUP • SUPERVISOR / USER PASSWORD • IDE HDD AUTO DETECTION • SAVE & EXIT SETUP • EXIT WITHOUT SAVING 3.3 Standard CMOS Setup • Date (mm:dd:yy) / Time (hh:mm:ss) • Primary Master / Primary Slave / Secondary Master / Secondary Slave...
  • Page 25 BIOS SETUP...
  • Page 26 BIOS SETUP • Drive A / Drive B • Video • Halt On...
  • Page 27 BIOS SETUP 3.4 BIOS Features Setup • Virus Warning NOTE: Many disk diagnostic programs that access the boot sector table can trigger the virus warning message. If you plan to run such a program, we recommend that you first disable the virus warning. •...
  • Page 28 BIOS SETUP • CPU L2 Cache ECC Checking • Quick Power On Self Test • Boot Sequence • Swap Floppy Drive • Boot Up Floppy Seek • Boot Up NumLock Status • Gate A20 Option • Typematic Rate Setting...
  • Page 29 BIOS SETUP • Typematic Rate (Chars / Sec) • Typematic Delay (Msec) • Security Option • PCI/VGA Palette Snoop • OS Select for DRAM > 64MB • HDD S.M.A.R.T capability • Report No FDD For WIN95...
  • Page 30 BIOS SETUP • Video BIOS Shadow 3.5 Chipset Features Setup • Bank 0/1, 2/3, 4/5, DRAM Timing...
  • Page 31 BIOS SETUP • DRAM Clock • Memory Hole • Read Around Write • Concurrent PCI/Host • System BIOS Cacheable • Video RAM Cacheable • AGP Aperture Size (MB)
  • Page 32 BIOS SETUP • AGP-2X Mode • CPU Host/PCI Clock (CPU/PCI) • CPU Warning Temperature • Current CPU Temperature • Current Power FAN Speed • Current CPU FAN Speed • Current CASE FAN Speed • VCORE • VTT...
  • Page 33 BIOS SETUP 3.6 Power Management Setup • ACPI function • Power Management...
  • Page 34 BIOS SETUP • • • • • PM Control by APM • Video Off After • Video Off Method • Modem Use IRQ • Soft-Off by PWR-BTTN • HDD Power Down...
  • Page 35 BIOS SETUP • Doze Mode • Suspend Mode PM events • VGA • LPT & COM • HDD & FDD • DMA/Master • LAN Wake Up...
  • Page 36 BIOS SETUP • Ring Wake Up NOTE: This feature requires the network interface and an ATX power supply with at least 720mA +5 V standby power. • Time Wake Up • Primary INTR 3.7 PnP/PCI Configuration Setup...
  • Page 37 BIOS SETUP • PNP OS Installed • Resource Controlled by • Reset Configuration Data • IRQ-n Assigned to...
  • Page 38 BIOS SETUP • DMA n Assigned to • CPU to PCI Write Buffer • PCI Dynamic Bursting • PCI Master 0 WS Write • PCI Delay Transaction • PCI #2 Access #1 Retry...
  • Page 39 BIOS SETUP • AGP Master 1 WS Write • AGP Master 1 WS Read • PCI IRQ Activated by • Assign IRQ For VGA 3.8 Integrated Peripherals...
  • Page 40 BIOS SETUP • • • • • On Chip IDE Channel 0/1 • • • • • IDE Prefetch Mode • • • • • IDE HDD Block Mode • Primary/Secondary Master/Slave PIO • • • • • Primary/Secondary Master/Slave UDMA •...
  • Page 41 BIOS SETUP • • • • • KBC Input Clock • • • • • Onboard FDC Controller • • • • • Onboard Serial Port 1 • • • • • Onboard Serial Port 2 • • • • • UART Mode Select •...

  • Page 42: Supervisor Password

    BIOS SETUP • • • • • EPP Mode Select • • • • • OnChip USB 3.9 Supervisor Password...
  • Page 43 BIOS SETUP 3.10 User Password 3.11 IDE HDD Auto Detection...
  • Page 44 BIOS SETUP 3.12 Save & Exit Setup 3.13 Exit Without Saving...
  • Page 45 BIOS SETUP 3.14 Load BIOS Defaults NOTE: This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high performance features. 3.15 Load Setup Defaults...

  • Page 46: Bios Upgrade

    BIOS UPGRADE 4.1 How to Check Your BIOS File Name and Version AAP1A-V10 TRANSCEND MODULAR BIOS : AAP1A-V10 AAP1A - V10 BIOS Version 1.0 (V11 for Ver ( You can upgrade to newer v than this version.) BIOS File Name...

  • Page 47: Bios Update

    BIOS UPDATE 4.3 How to Update Your Motherboard BIOS FORMAT A:/S Format 3.5 Menu 4.2)

  • Page 64: Bios Setup

    BIOS SETUP 3.7 PnP/PCI Configuration Setup • PNP OS Installed...
  • Page 65 BIOS SETUP • Resource Controlled by • Reset Configuration Data • IRQ-n Assigned to • DMA n Assigned to • PCI 1,2,3,4 Use IRQ No. • Used MEM Base Addr...
  • Page 66 BIOS SETUP 3.8 Integrated Peripherals • • • • • IDE HDD Block Mode • IDE Primary/Secondary Master/Slave PIO • • • • • IDE Primary/Secondary Master/Slave Ultra DMA...
  • Page 67 BIOS SETUP • • • • • On Chip IDE Primary / Secondary PCI IDE • • • • • USB Keyboard Support • Init Display First • • • • • POWER ON Function • • • • • KBC Input Clock à...
  • Page 68 BIOS SETUP • • • • • Onboard Serial Port 1 • • • • • Onboard Serial Port • • • • • UART Mode Select • • • • • Onboard Parallel Port • • • • • Parallel Port Mode...
  • Page 69 BIOS SETUP 3.9 Supervisor Password...
  • Page 70 BIOS SETUP 3.10 User Password 3.11 IDE HDD Auto Detection...
  • Page 71 BIOS SETUP 3.12 Save & Exit Setup 3.13 Exit Without Saving...
  • Page 72 BIOS SETUP 3.14 Load BIOS Defaults NOTE: This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high performance features. 3.15 Load Setup Defaults...
  • Page 73 BIOS UPGRADE 4.1 How to Check Your BIOS File Name and Version TRANSCEND MODULAR BIOS : ABX1A-V10 ABX1A - V10 BIOS Version 1.0 (V11 f for Version 1.1) ( You can upgrade to n ewer version if your BIOS version is older than this version.)
  • Page 74 BIOS UPDATE FORMAT A:/S Format 3.5 Menu...
