Summary of Contents for CDA ci860
- Page 1 8 + 6kg, 1400 Spin Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service.
-
Page 4: Safety Warnings
Safety Warnings • If the plug or cord is damaged, do not connect the appliance to the mains power supply. If the cord is damaged it should be replaced by the manufacturer or appointed service agent in order to avoid a hazard. - Page 5 Warnings To avoid the risk of fire, electric shocks, injury or damage when using your washer dryer, please take the following precautions: • Please read all the instructions before using the washer dryer. • Do not wash items that have previously been cleaned, washed, soaked or treated with petrol, solvents for dry cleaning, other inflammable substances or explosives, as they produce fumes that could catch fire or explode.
- Page 6 Recommendations • Residues of detergent or softener left in the detergent drawer for long periods will dry and stick to the detergent drawer. To prevent this put the detergent and softener into the detergent drawer just before washing. • It is recommended that the pre-wash programme should only be used for very dirty clothes.
-
Page 7: Before First Use
Before First Use When your washer dryer has been correctly installed, we recommend that you pre-clean the machine. This is to check that the installation, the connections and the drainage are all correct, and to thoroughly clean the inside of the washer dryer before any wash programmes are run. - Page 8 • Fasten all zips and buttons. • Turn garments, such as knitted fabrics, inside out. • Before placing the clothes in the drum, make sure all the pockets are empty. Any small objects may block the drain pump. • We recommend loading the washer dryer to its full capacity for best water and energy efficiency.
-
Page 9: Detergents And Additives
Detergents and Additives Your washer dryer’s detergent dispenser has three compartments, marked with symbols. For prewash detergent For main wash detergent fig. 1 For fabric conditioner, starch or other additives. Add the required amount of detergent and fabric softener into the specific sections of the detergent dispenser before starting the wash programme. - Page 10 Liquid Detergent • Liquid detergent may be used in your washer dryer by using the liquid detergent adaptor. • Any programs that don’t include pre-wash may be run with liquid detergent. • Plug the liquid detergent adaptor into the second compartment of the detergent drawer and add the fig.
- Page 11 Eco Note The use of more detergent than necessary will not improve your washing results, and will have a negative effect on the preservation of the environment. We therefore recommend you follow the detergent manufacturer’s instructions. Loading the Washer Dryer - Open the door.
-
Page 12: Control Panel
Control Panel fig. 2 A Programme selector knob B Temperature button C Spin speed button D Stain level button E Options button (prewash, extra rinses or anti-allergy) F Dry level button G Delay button H Start button... -
Page 13: Starting A Wash Programme
Starting a Wash Programme • Turn the “Programme selector” knob to the required programme. • Select the required adjustments and additional functions using the buttons “B” to “G” in fig 2. as detailed below. • Press the “Start” button. When a wash programme is in progress, the programme can be paused by pressing the “Start”... - Page 14 the programme listing on pages 20 & 21. You can change the spin speed, if required, by pressing the “Spin speed” button a number of times. If you miss the speed you want you can come back round to it again by pressing a few more times.
- Page 15 display. Note: If the prewash symbol does not display on the screen it is because the prewash function is not available for the programme selected. Note: Prewash is not available for selection at the same time as extra rinses or the anti-allergy option. Extra rinses This function adds up to 3 extra rinse cycles to the programme, which is ideal for large loads and garments belonging to people...
- Page 16 Anti-allergy function Press the “Options” button again to activate the anti-allergy function. The display will show . In this setting the machine rinses the washing in hot water: Note that the energy consumption of the machine increases when this function is used. When the “Options”...
- Page 17 To set drying level You can change the drying level, if required, by pressing the “Dry Level” button a number of times. If you miss the level you want you can come back round to it again by pressing a few more times. Level 1 ( showing on the display) is recommended for washing that is to be ironed.
- Page 18 Note: If you choose to set a defined drying time this will automatically be at the default drying level for the programme selected. Refer to the drying programme list on page 22 for details of drying options available for each programme. Delay timer A delay of up to 23 hours can be set before the start time for the programme, in half hour increments to allow the wash programme to...
- Page 19 Cancelling a programme If you need to cancel a programme after it has started running: • Switch the “Programme selector” knob to the “0” position: The machine will stop its washing operation. • To discharge any water in the machine turn the “Programme selector”...
-
Page 20: Programme Listing
Programme Listing The table below shows the extra functions and temperatures available for each wash programme. Wash Temperature Options Index Programme Cold Whites B ** Cotton Eco Eco 20°C Synthetics Wool Duvet Refresh Rinse Spin 15 * Rapid 15 min Daily 60 min 2 / 4 30 /... - Page 21 Note: The actual water temperature may differ from the declared cycle temperature. ** Programme for wash and energy consumption assessment in accordance with standard EN60456. Index Laundry Type Cottons & linens 1400 Medium Low, High 1, 2, 3, A (Maximum 4kg for towels) B ** Cottons &...
- Page 22 Drying Programme Listing Index Programme Laundry Type Whites Cottons & linens 2, 3 30, 60, 120 (Maximum 4kg for towels) B ** Cotton Eco Cottons & linens 2, 3 30, 60, 120 (Maximum 4kg for towels) Eco 20°C Cottons & linens 30, 60, 120 (Maximum 2kg for towels) Synthetics...
-
Page 23: Care And Maintenance
Care and Maintenance Before beginning any care or maintenance you should always disconnect the appliance from the electricity supply, and also turn off the water supply. If a programme has been run recently, wait for the water in the appliance to cool down to prevent risk of scalding. Water inlet filters There are filters on the tap side of the water inlet hose and at the end of the... -
Page 24: Pump Filter
Pump Filter The pump filter system prevents ingress of lint or foreign objects into the drain pump, reducing the risk of damage. The pump filter should be cleaned regularly, every two to three months at least. To avoid injury, do not carry out this operation when the wash water is at a temperature over 30ºC To clean the filter: •... -
Page 25: Detergent Drawer
• Refit the filter by turning it clockwise. • Replace the filter cover. Please note - failure to replace the filter cover properly will cause water to leak from the machine. Detergent Drawer Detergents may cause residue build up in the detergent drawer and the drawer housing over time. -
Page 26: Limescale Removal
Cleaning the Washer Dryer Exterior The exterior of the washer Dryer should be cleaned with warm soapy water or a gentle cleaning agent. Do not use abrasive cleaning products or solvents. It should then be dried thoroughly with a soft cloth. Please note - wipe any detergent spills immediately to minimise the risk of damage to the washer dryer exterior. -
Page 27: Practical Information
Practical Information Alcoholic beverages: The stain should first be washed with cold water, then wiped with glycerine and water and be rinsed with water mixed with vinegar. Shoe Polish: The stain should be slightly scratched without ruining the cloth, rubbed with detergent and rinsed. In case it is not eliminated, it should be rubbed with 1 part of pure alcohol (96 degrees) mixed in 2 parts of water and then washed with lukewarm water. - Page 28 Practical Information Blood stain: Soak the item in cold water for 30 minutes. If the stain still does not disappear, soak in a mixture of water and ammonia (3 table-spoons of ammonia in 4 litres of water) for 30 minutes. Cream, ice-cream and milk: Soak the item in cold water and rub the stained area with detergent.
- Page 29 Shut the door properly so that you hear the properly. click then press the “Start” button. If the error persists, unplug the machine, close the water tap and contact CDA Customer Care. Water cut off or low Make sure the tap is turned on and water E02 or water pressure.
-
Page 30: Troubleshooting
• Unplug the machine. • Close the water tap. • Contact CDA Customer Care. Fault Probable cause Methods of elimination The machine will not It is unplugged. - Page 31 Fault Probable cause Methods of elimination The machine is not The drain hose is obstructed or Check the drain hose. draining water. bent. The pump filter is obstructed. Clean the pump filter. The machine is Not all transit bolts have been Remove all the transit bolts.
-
Page 32: Installation
Installation All four transit bolts, located at the rear of the appliance, must be removed prior to using the appliance to prevent damage. Cover the bolt holes with the plastic plugs supplied. Do not throw the transit bolts away. fig. 7 If you need to move the washer dryer after installation you should first replace the transit bolts and spacers. - Page 33 Levelling To reduce the noise from the washer dryer and to prevent unnecessary movement and vibration during use, ensure the washer dryer is level, using the adjustable feet. First, fix and level the rear feet. When they are properly fixed, secure the plastic locknut tightly against the underside of the washer dryer.
-
Page 34: Connecting To The Mains Water Supply
Connecting to the Mains Water Supply • Fit the seal included in the hose packing at the end of the water inlet hose on the tap side. • Connect the water inlet hose to a ¾” BSP water tap. Then securely tighten the connecting nut by hand. -
Page 35: Electrical Information
The drain hose must be securely fastened to the outlet to prevent any risk of the drain hose becoming detached and causing flooding. Once the appliance is connected to the water supply and the drain connection, ensure that the water inlet and drain hoses are not folded, twisted, crushed or elongated by stretching when moving the appliance into position. -
Page 36: Technical Specifications
How to connect an alternative plug If the fitted plug is not suitable for your socket outlet, then it should be cut off and disposed of safely to prevent the risk of electric shock. A suitable alternative plug of at least 13 Amp rating to BS 1363 should be used. - Page 37 International Washing Symbols Washing Do not wash in a Lukewarm iron Medium hot iron temperature washing machine Hot iron Do not iron Do not tumble Hang to dry Drip dry Dry flat Do not bleach Handy to bleach All of these are dry cleaning symbols. The letters are to instruct the cleaner what type of solvent to be used.
- Page 38 NOTES...
- Page 39 NOTES...
- Page 40 Please contact our Customer Care Department for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
