Baby Jogger Performance Single Assembly Instructions Manual page 6

Canopy
Attaching
1
To attach bracket to frame: Unsnap seat
from frame to reveal mounting location.
Use a phillips head screwdriver to attach
bracket screws to frame.
Using
1
Secure canopy Velcro to stroller frame.
8
2
To attach canopy to bracket: Insert canopy
frame into bracket and attach screws using
a phillips head screwdriver.
2
To use your canopy simply pull forward to
the desired position.
Seat
1 2
Snap seat to the frame. Fasten the two bottom Velcro straps. One is located near the
front of seat and the other is near the footplate.
Stroller is packaged with seat support frame and can be
easily removed or inserted into the seat back if additional
support is desired.
NoTe: Be sure to remove the board from
the back of the seat before washing.
9
