Baby Jogger City Single Assembly Instructions Manual

Baby Jogger City Single Assembly Instructions Manual

City single amazing 360° turns make for extreme maneuverability
Hide thumbs Also See for City Single:

Advertisement

Quick Links

Download this manual See also: Manual
City Single
Amazing
360° Turns
Make For
Extreme Maneuverability
Assembly
Instructions
Seat
Reclines
To
23°
Important, Keep for
Future Reference

Advertisement

loading
Need help?

Need help?

Do you have a question about the City Single and is the answer not in the manual?

Questions and answers

Related Manuals for Baby Jogger City Single

Summary of Contents for Baby Jogger City Single

  • Page 1 Assembly Instructions Seat Reclines 23° City Single Amazing 360° Turns Important, Keep for Make For Extreme Maneuverability Future Reference...
  • Page 2 • The passenger should remain seated (no standing in the jogger). • Watch out for cars – never assume that a driver can see you and your child. • Never use Roller Blades while using a Baby Jogger Jogger. • Total weight load recommended for this Jogger is 75 lbs.
  • Page 3 Frame Unpack Jogger from box Unfold adjustable Push footplate of Jogger and set wheels aside. handle while away from handle by pushing both pushing axle of Jogger buttons on the sides up and out. of Jogger handle. The Jogger frame will click into place. Flip Jogger to upright position.

  • Page 4: Front Wheel

    Front Wheel To install front wheel, lay jogger back so handle is resting on floor. Lock front wheels to prevent the forks from swiveling. Insert the front wheel into the forktips by aligning the axle flats with the forktip flats. Tighten by turning the wheel lever and holding the opposite side.

  • Page 5: Rear Wheels

    Rear Wheels • To install, gently slide the wheel’s rear axle into the hole in the axle end until you hear it click into place. • To remove, simply push in the spring lock while pulling out the wheel.

  • Page 6: Safety Harness

    Safety Harness Adjusting safety harness: Loosen the shoulder straps from their plastic guides. Slide the end of each strap through pair of seat loops closest to your child’s shoulder. WARNING: Avoid serious injury from falling or sliding out. Always use safety harness!
  • Page 7 Slide the end of the shoulder strap back into plastic guide.Please note: If you feel the straps are too tight, you may adjust their length by sliding the plastic guides toward the top of the seat. Lock both sides of the strap mechanism into the center buckle. To adjust the center strap, move its plastic guide up or down.
  • Page 8 Brake Rear Wheel Parking Brake • Simply push brake pedal down to engage brake and lift up to release.

  • Page 9: Reclining Seat

    Reclining Seat Simply adjust seat Pull on strap when you Rear flap serves as sun straps to desired want to return the seat canopy when seat is in degree of recline. to its upright position. reclined position. Simply secure it to Velcro on seat.
  • Page 10 Seat Snap seat to frame. Attach bottom part of seat to footplate with the Velcro. Wrap bottom straps around Snap safety strap to frame. frame, thread strap through D-ring and secure.
  • Page 11 NOTE: Some Joggers are shipped with the Canopy, Seat and Basket pre-assembled. Assembly instructions are given if any pre-assemble items are removed for cleaning or replacement. Thread folding strap through openings in seat. Attach folding strap to folding trigger and secure the triangle shaped ALWAYS BE SURE...
  • Page 12 Basket Velcro front basket straps around frame tube. Wrap rear basket straps around upright and snap back to itself. Note: The rear of basket has the mesh material and the front doesn’t.
  • Page 13 Canopy Using a phillips head screwdriver, screw brackets to Jogger frame. Snap canopy strap to frame. Velcro canopy straps to back of sun canopy.
  • Page 14 • Make sure safety wrist strap is secured properly around your wrist whenever your baby is in the jogger. The Baby Jogger is lightweight and ready to roll – with or without you – and the safety wrist strap helps you gain control over your jogger.
  • Page 15 Jogger Care Washing • You can machine wash your jogger’s seat in cold water with a mild detergent. To minimize shrinkage, simply reattach the seat to the frame to dry. (Please do not put the seat in the dryer!) • Be sure to remove the frame from the back of the seat before washing. •...
  • Page 16 Thank You! We wish you many happy journeys with your new Baby Jogger! Your jogger is a great product, and we are proud to manufacture it. If you have any questions or comments, please give us a call at. 1.800.241.1848 Baby Jogger is a Division of Dynamic Brands 8575 Magellan Parkway, Suite 1000 •...
