Schumacher Electric SpeedCharge SC-7500A Quick Steps

BATTERY CHARGING
For SpeedCharge
Battery Charger with Engine Start and Tester
For Safety Warning Instructions, refer to Owner's Manual
Note: A marine (boat) battery installed in a boat must be
removed and charged on shore.

Steps To Take Before Using Your Battery Charger

See pages 3 & 4 of the Owner's Manual for all cautionary warnings.
1. Make sure to use a grounded 120V AC electrical outlet.
2. Keep hands, hair, clothing and jewelry clear of fan blades, belts, pulley and
other engine parts.
3. Keep the power cord and output cords away from the hood, door and/or moving
engine parts.
4. Wear safety glasses.
5. Charge battery in a well-ventilated area.
1. If necessary, clean the battery terminals as well as possible. Wear rubber
gloves and safety glasses to avoid contact with battery acid.
2. For batteries with removable vent caps, see page 4 of Owner's Manual for
details.
1. Attach RED clamp to positive (+) battery terminal. Refer
to picture. (Negative Ground System)
2. Attach BLACK clamp to negative (-) ground on an
unpainted frame part or engine block of vehicle.
3. Then, plug charger into a 120V AC electrical outlet.
Simply reverse the steps to disconnect.
1. Press the BATTERy TyPE button to select your battery type: 12V STANDARD;
or 12V AGM, OR 12V GEL CELL.
2. Read the voltage on the digital display or press the DIGITAL DISPLAy button
to set the tester to BATTERy % to determine the charge left in your battery.
Note: If the BATTERy SIZE button has been pressed and the CHARGING
LED is on, the SC-7500A is no longer in Test Mode. To change from Charge
Mode back to Test Mode, press the BATTERy SIZE button until all three charge
rate LEDs are off. See page 10 of the Owner's Manual for details.
QUICK STEPS
SAFETY FIRST!

Getting Your Battery Ready

Connecting Your Battery Charger

Testing Your Battery

Model SC-7500A
™
OvER
00-99-000658/1107
