Summary of Contents for Integra DTM-40.4

  • Page 1 Network Stereo Receiver DTM-40.4 Instruction Manual...
  • Page 2: Important Safety Instructions

    Thank you for purchasing an Integra receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new receiver.
  • Page 3: Precautions

    Precautions 1. Recording Copyright—Unless it’s for personal use For U.S. models only, recording copyrighted material is illegal FCC Information for User without the permission of the copyright holder. CAUTION: 2. AC Fuse—The AC fuse inside the unit is not user- The user changes or modifications not expressly serviceable.
  • Page 4: Features

    Features ❑ Clean Design Aluminum Front Panel ❑ Network Capability • Internet Radio • DLNA (Digital Living Network Alliance) ❑ iPod/iPhone Digital Direct Connection via iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.
  • Page 5: Table Of Contents

    Advanced Setup Menu ..........41 Connecting Your Components......14 About AV Connections ........... 14 Zone 2 ..............44 Connecting Integra/Onkyo  Components ..16 Connecting Zone 2 ..........44 Connecting a Recording Component ...... 17 Zone 2 Out Settings ..........45 Connecting the Power Cord ........17 Using Zone 2 ............45...
  • Page 6: Supplied Accessories

    Power cord Remote control sensor DTM-40.4 * In catalogs and on packaging, the letter at the end of the product name indicates the color. Specifications and operation are the same regardless of color.
  • Page 7: Getting To Know The Receiver

    Getting to Know the Receiver Front Panel North American model q r s Oceanian model Master Volume control (19) Phones jack (19) Dimmer button (North American model) (20) Zone 2, Off buttons (45) Input selector (19, 22, 23, 27, 45) Bass control (20) Treble control (20) Balance control (20)
  • Page 8: Rear Panel

    Getting to Know the Receiver —Continued Rear Panel c 4 5 6 For detailed information, see the pages in parentheses.  REMOTE CONTROL jack (16) PHONO IN (MM) and GND terminal (15) UNIVERSAL PORT jack (15) CD IN jacks (15) ETHERNET port (15) TV/TAPE IN/OUT jacks (15, 17) ZONE 2 OUT V jack (44)
  • Page 9: Remote Controller

    Getting to Know the Receiver —Continued Remote Controller For detailed information, see the pages in parentheses.  button (12, 18, 46) Input Selector buttons (18, 19, 22, 23, 38, 39, Control buttons (38, 39) Repeat button (38, 39) List button Arrow []/[]/[]/[] and Enter buttons (12, 23, 38, 39, 40, 45) Setup button (12, 40, 45)
  • Page 10: Connecting The Receiver

    Connecting the Receiver Disconnect the power cord from the electrical outlet before making any connections. Speaker Connection Precautions Connecting the Speaker Cables The receiver allows you to connect two sets of speakers. Strip about 5/8" (15 mm) When two sets of speakers are connected, you can select 5/8"...
  • Page 11: Connecting A Powered Subwoofer

    Connecting the Receiver —Continued Connecting a Powered Subwoofer Connecting a Power Amplifier Using a suitable cable, connect the receiver’s PRE OUT: If you want to use a more powerful power amplifier and SUBWOOFER to the input on your powered subwoofer. use the receiver as a preamp, connect the receiver’s PRE If your subwoofer is unpowered and you’re using an OUT: L, R to the amp’s input, and connect all speakers...
  • Page 12: Configuring The Speaker Impedance

    Connecting the Receiver —Continued Configuring the Speaker Impedance Ω On the receiver, the factory default for speaker impedance is “6 ”. If you need to change the speaker impedance setting, read “Speaker Connection Precautions” on page 10 carefully before performing the procedure below. Note: Be sure to minimize the volume level on the receiver ...
  • Page 13: Connecting Antennas

    Connecting Antennas This section explains how to connect the supplied indoor FM antenna and AM loop antenna. The receiver won’t pick up any radio signals if no antenna is connected, so you must connect the antenna to use the tuner. Insert the plug fully into the jack.
  • Page 14: Connecting Your Components

    Connecting Your Components About AV Connections Connecting AV components Video Receiver Audio Blu-ray Disc/ DVD player TV, projector, etc. Game console • Before making any AV connections, read the manuals supplied with your AV components. • Don’t connect the power cord until you’ve completed and double-checked all AV connections. •...
  • Page 15 Connecting Your Components —Continued No. Jack/Port Connectable components iPod/iPhone, MP3 player, USB flash drive DIGITAL IN OPTICAL 1 (GAME) Game console 2 (CD) TV, CD player COAXIAL 1 (BD/DVD) Blu-ray Disc/DVD player 2 (CBL/SAT) Satellite/cable set-top box, RI dock, etc. UNIVERSAL PORT Universal port option dock (UP-A1 etc.) ETHERNET...
  • Page 16: Connecting Integra/Onkyo  Components

    CD player e.g., Tape deck  cable  cable • Connect only Integra/Onkyo components to  jacks. Make sure that each Integra/Onkyo Connecting other manufacturer’s components may component is connected with an analog cause a malfunction. audio cable (connection in the hookup •...
  • Page 17: Connecting A Recording Component

    Connecting Your Components —Continued Connecting a Recording Component See “Recording” for an explanation of recording ( page 22). Composite video Analog Analog cable audio cable audio cable Cassette tape VCR, DVD recorder, etc. deck, CDR, etc. Notes: • Copy-protected Blu-ray discs and DVDs cannot be •...
  • Page 18: Turning On The Receiver

    Turning On the Receiver MOn/Standby VCR/DVR TV/Tape Game Turning On and Standby Changing the Input Display For the [TV/Tape], [VCR/DVR] and [Game] buttons, the Press the [On/Standby] button. input display name can be changed as shown below. Alternatively, press the remote controller’s [] When the input display name has been changed for one button.
  • Page 19: Enjoying Audio Sources

    Enjoying Audio Sources Input Selector Speaker A, B Master Volume Phones Input Volume F/H Muting Muting the Receiver Rotate the receiver’s [Input] selector, or (remote controller only) press the remote controller’s Input Selector You can temporarily mute the output of the receiver. buttons to select the source you want to hear.
  • Page 20: Setting The Display Brightness

    Enjoying Audio Sources —Continued Mode Bass Dimmer Treble Sleep Balance (North American model) Dimmer Setting the Display Brightness Using the Tone and Balance Controls You can adjust the brightness of the display. This section explains the following functions that can be used with any input source.
  • Page 21: Selecting The Listening Mode

    Enjoying Audio Sources —Continued Audio Selecting the Listening Mode Press the remote controller’s [Audio] button repeatedly to select the listening mode. The setting will change as follows each time you press the [Audio] button. Stereo Stereo (M.Opt: ON) Direct Mono When the Stereo indication is shown, pressing the [Audio] button will make the display indicate “Music Optimizer: On”...
  • Page 22: Recording

    Recording Unless you have the full consent of the copyright holder, copyright laws prohibit using your recordings for anything other than personal enjoyment! This section explains how to record the selected input source to a component with recording capability, and how to record audio and video from different sources.
  • Page 23: Listening To The Radio

    Listening to the Radio &/( Tuning F/H Number buttons D.TUN Input Tuning Mode Listening to AM/FM Stations Press the Tuning [] or [] button. You can also use the remote controller’s arrow With the built-in tuner, you can enjoy AM and FM radio []/[] buttons to tune the radio.
  • Page 24: Press The [Setup] Button On The Remote

    Listening to the Radio —Continued Presetting AM/FM Stations Press the [Memory] button again to store the station or channel. Tuning F/H, The station or channel is stored and the preset Preset C/U number stops flashing. Setup Return Repeat this procedure for all of your favorite AM/ FM radio stations.
  • Page 25 Listening to the Radio —Continued Tips: When you’ve finished editing the name and *1 You can also perform this on the remote want to store it, be sure to use the arrow controller by using >10. []/[]/[]/[] button to select “OK” and *2 By pressing [CLR] on the remote controller, you then press [Enter].
  • Page 26: Using Rds (Oceanian Model)

    Listening to the Radio —Continued RDS Program Types (PTY) Using RDS (Oceanian model) RDS only works in areas where RDS broadcasts are Type Display available. When tuned into an RDS station, the RDS None NONE indicator appears. News reports NEWS Current affairs AFFAIRS RDS indicator...
  • Page 27 Listening to the Radio —Continued Displaying Radio Text (RT) Listening to Traffic News (TP) ENTER RT/PTY/TP RT/PTY/TP When tuned to an RDS station that’s broadcasting text You can search for stations that broadcast traffic news. information, the text can be displayed. Press the [RT/PTY/TP] button three times.
  • Page 28: Using The Usb/Network Device

    Using the USB/Network Device Connecting the iPod/iPhone Directly Press [Mode] to switch to Extended Mode to the USB Port A list of your iPod model’s contents appears. To open a folder, use []/[] to select it, and then USB can be used to play music files stored on iPod/ press [Enter].
  • Page 29: Playing The Usb Device

    Using the USB/Network Device —Continued Tip: Playing the USB Device You can also use the receiver’s [Menu], [/], [] or [] buttons as follows. This section explains how to play music files from a USB device (e.g., USB flash drives and MP3 players). [Menu]: Hold down to move to the top menu.
  • Page 30: Listening To The Internet Radio

    • If you’re using DHCP, your router may not always (email address and password) on the http://integra.vtuner.com/ portal. To verify your MAC allocate the same IP address to the receiver, so if Address, please see “Network Setup” ( page 42).
  • Page 31: Playing Music Files On A Server

    Using the USB/Network Device —Continued Registering Presets Playing Music Files on a Server You can add the currently playing song or station to “My You need to connect the receiver to your home Favorites”. You can preset up to 40 Internet radio network, see “Network/USB Features”...
  • Page 32: Remote Playback

    Using the USB/Network Device —Continued Tip: Remote Playback You can also use the receiver’s [Menu], [/], [] or [] buttons as follows. You need to connect the receiver to your home [Menu]: Hold down to move to the top menu. network, see “Network/USB Features”...
  • Page 33 Using the USB/Network Device —Continued Using Remote Playback Start Windows Media Player 12. To enable remote playback, you must first configure Windows Media Player 12. Press [NET] button. The “NET” appears in the display. If it flashes, verify the network connection. Use []/[] to select “DLNA”, and press [Enter].
  • Page 34: Network/Usb Features

    Network/USB Features Please consult your ISP or computer dealer if you’re Connecting to the Network unsure. The following diagram shows how you can connect the Notes: receiver to your home network. In this example, it’s • To receive Internet radio with the receiver, your connected to a LAN port on a router, which has a 4-port broadband Internet connection must be working and 100 Base-TX switch built-in.
  • Page 35: Usb Device Requirements

    Network/USB Features —Continued ■ WMA (.wma or .WMA) Minimum system requirements for Windows WMA stands for Windows Media Audio and is an audio Media Player 11 on Windows XP compression technology developed by Microsoft Operating system Corporation. Audio can be encoded in WMA format by ®...
  • Page 36: Ipod/Iphone Playback Via Onkyo Dock

    iPod/iPhone Playback via Onkyo Dock Using the Onkyo Dock • The Auto Power On function will not work if you set your iPod/iPhone in the UP-A1 Dock while it is playing. Dock is sold separately. Models sold are different • When Zone 2 is turned on, you can’t use Auto Power depending on the region.
  • Page 37: Controlling Your Ipod/Iphone

    iPod/iPhone Playback via Onkyo Dock —Continued RI Dock With the RI Dock, you can easily play the music stored Operating Notes on your Apple iPod/iPhone through the receiver and • Use the receiver’s volume control to adjust the enjoy great sound. You can even use the receiver’s playback volume.
  • Page 38 iPod/iPhone Playback via Onkyo Dock —Continued If a UP-A1 is connected to UNIVERSAL PORT in  Extended mode ( page 8), the [Play List] buttons Press the appropriate Input Selector first. are used as the page jump buttons. With the page modes, you can quickly locate your favorite songs even when your song lists, artist lists, and so on are very long.
  • Page 39: Controlling Other Components

    Controlling Other Components You can use the receiver’s remote controller to control  your other AV components. : Available buttons Components Use the Remote Mode buttons to select the zone of the component you want to control (Main or Zone 2). Then press the Input Selector button of the component you want to control.
  • Page 40: Advanced Setup

    Advanced Setup Changing the Advanced Setup Turn on the power. Settings Press the [Setup] button on the remote Here’s how to change the Advanced Setup settings. controller. The setup menu appears in the display. Example: Intelli volume setting procedure Intelli Volume Use the arrow []/[] buttons to select “2.
  • Page 41: Advanced Setup Menu

    Advanced Setup —Continued 3.4.5. 12V Trigger A/B/C Setup Advanced Setup Menu Delay 1. Digital Audio Input 0sec, 1sec, 2sec, 3sec When “0sec” is selected, the trigger signal is output as If you connect a component to a digital audio input, you soon as the input source is changed.
  • Page 42: Hardware Setup

    Advanced Setup —Continued 6. Hardware Setup 7. Zone2 Setup Speaker Impedance Zone2 Out See “Configuring the Speaker Impedance” on page 12. If you have connected your Zone 2 speakers to an amp with no volume control, set the Zone 2 Out setting to AM/FM Frequency Setup (North American model) Variable so that you can set the zone’s volume, balance, For AM/FM tuning to work properly, you must specify...
  • Page 43 Enable (Default setting) • Perform the firmware update only when such an Disable announcement is posted on the Integra web site. Visit Note: the Integra web site for the latest information. If you select “Disable”, you must configure the “IP •...
  • Page 44: Zone 2

    Zone 2 In addition to your main listening room, you can also enjoy playback in a second room referred to as Zone 2. In addition, you can select a different source for each room. Zone 2 Video Output Connecting Zone 2 This receiver features a composite video output for This setup allows 2-channel playback (with the speaker connection to a TV in Zone 2, so you can enjoy both...
  • Page 45: Zone 2 Out Settings

    Zone 2 —Continued Zone 2 Out Settings Using Zone 2 This section explains how to turn Zone 2 on and off, how to select an input source for Zone 2, and how to adjust the volume for Zone 2. &/(/#/5 Controlling Zone 2 from the receiver Enter Setup...
  • Page 46 Zone 2 —Continued Controlling Zone 2 with the Remote Adjusting the Volume of Zone 2 Controller Press the receiver’s [Zone 2] button, and then use the [Master Volume] control, or remote controller’s [Zone2] To control Zone 2, you must press the remote button, and then use the Volume []/[] buttons.
  • Page 47: Using The 12V Triggers

    Zone 2 —Continued Using the 12V Triggers The 12V triggers A, B, and C can be used to turn on 12V trigger-capable components automatically when they are selected as the input source. The triggers can be set so that they activate when a connected component is selected as the input source for the main room, Zone 2 or any combination of rooms.
  • Page 48: Connecting Components Not Reached By The Remote Controller Signals (Ir In/Out)

    Connecting Components Not Reached by the Remote Controller Signals (IR IN/OUT) Making Sensor Connections In order to use the remote controller to control the receiver from a remote location, you will need to When you place the IR receiver in the main room, connect prepare a multiroom kit (sold separately) such as one the cable from the connecting block to the IR IN terminal.
  • Page 49: Firmware Update

    Do not use [] on the remote controller. data, or for any other reason whatsoever. Once turned off, the receiver will automatically turn on again. See the Integra web site for latest information. Congratulations! You now have the latest firmware installed on your Integra receiver.
  • Page 50: Updating The Firmware Via Usb

    USB device, remove it first. receiver will not be able to access the network. Consult your Internet Download the firmware file from the Integra Service Provider (ISP). web site. The file name is as follows: • If your modem does not function as ONKRCV****_************.zip...
  • Page 51 Turn off the receiver using [On/Standby] on the front panel. The Americas Integra Division of Onkyo U.S.A. Corporation Do not use [] on the remote controller. 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Once turned off, the receiver will automatically Tel: 800-225-1946, 201-818-9200 turn on again.
  • Page 52: Troubleshooting

    Troubleshooting If you have any trouble using the receiver, look for a audio performance; do not bundle audio cables solution in this section. together with power cords or speaker cables. • An audio cable may be picking up interference. Try If you can’t resolve the issue yourself, try resetting repositioning your cables.
  • Page 53: Up-A1 Dock For Ipod/Iphone

     page 17). a different input source. If playback is not paused, the • If it is an Integra/Onkyo component, make sure that the Direct Change function may select your iPod/iPhone cable and analog audio cable are connected as the input source by mistake during the transition properly.
  • Page 54: Usb Device Playback

    Troubleshooting —Continued Can’t connect to the receiver from a Web The receiver contains a microcomputer for signal browser processing and control functions. In very rare • If you’re using DHCP, your router may not always situations, severe interference, noise from an external allocate the same IP address to the receiver, so if you source, or static electricity may cause it to lockup.
  • Page 55: Specifications

    Specifications Amplifier Section General Rated Output Power (North American) Power Supply (North American) 80 watts minimum continuous power AC 120 V, 60 Hz per channel, 8 Ω loads, 2 channels (Oceanian) driven from 20 Hz to 20 kHz with a AC 220–240 V, 50/60 Hz maximum total harmonic distortion of 0.08 % (FTC)
  • Page 56 Integra Division of 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4208-213 http://www.integra.eu Integra Division of 1301, 555 Tower, No.555 West NanJin Road, Jin an, Shanghai, China 200041, Tel: 86-21-52131366 Fax: 86-21-52130396 http://www.integra.com.cn...
