1600A Exploded View - Infinity Reference 1600a Service Manual

1600a Reference Series
Item# Part Number
1 SG-0016-2601
2 GD-600011400
3 LSIFM0300011
4 SR-1300-0117
5
6 MK-0004-2601
7 LS5KP0300807
8 LS5KJ0301007
9 XN-10500-012
10 LSIAP0300607
11 LSIAM0300607
12 XG-0017-2601
13 PL-L0007-000
14 PL-L0006-000
15 LSIAY0301201
16 ZL-10037A-15
17 HG-0005-2601
18 1601-253E-00
19 LSIAA0200501
20 LS1AM0250401
21 CP-B00011400
22
Description
Top cover
Light panel
Screw
Main heat sink
Main PCB
Front panel
Screw for F/RP
Screw for terminal, RCA jacks
Knob
Screw
Screw
Bottom plate
Transistor spring clip (2)
Transistor spring clip (1)
Screw
Space Pole
Rear panel
Fuse 25A ATC
Screw
Screw
LED lens
LED PCB
6
Qty
1
1
5
1
1
1
8
3
3
6
2
1
1
10
4
4
1
3
1
4
1
1
