Infinity Reference 1600a Service Manual page 20

1600a Reference Series
Part Number
MAIN BOARD
06S322206000 Capacitor
06S321006000 Capacitor
06D342227400 MET capacitor
06D374717400 Tan capacitor
06D241546000 MET capacitor
06D324747700 metallized Capacitor
06D1C4747701 Metalfilm resistor
06D321047200 Terylene capacitor
06D341537400 MET capacitor
06D22102C000 MET capacitor
06D342247400 MET capacitor
06D341839400 MET capacitor
06D343339400 MET capacitor
06D341039000 MET capacitor
06D2C3357700 Metalfilm resistor
06D2C335C700 Metalfilm resistor
06D212264102 E-capacitor
06D211074100 E-capacitor
06D212264103 E-capacitor
06D214764102 E-capacitor
06D214775101 E-capacitor
06D212285101 E-capacitor
06S121244000 Capacitor
06D212256301 E-capacitor
06D21478H001 E-capacitor
06D212266010 E-capacitor
06D214766001 E-capacitor
Semiconductors
04GS-R104-00 High speed diode
04ZL-4004-03 Diode
04WY-51AV101 Zener diode
04PT-4148-01 Diode
04ZL-2512-00 Diode
04ZL-6A10-00 Diode
03T1-Z48N-02 MOS FET
03N1-5551-04 Transistor
03N1-2222-04 Transistor
03D1-38N2-02 MOS FET
01FA-7912-04 Regulator
01JR-4560-08 IC
2601-0202-00 Optocoupler
2202-1620-05 Rectifier
2202-1602-05 Rectifier
01FA-7812-04 Regulator
Miscellaneous
1400-0001-16 RJ45 Jack
3000-INIT-03 HF transformer
1380-0209-00 Temperature switch
1500-0400-01 Terminal
1500-0300-01 Terminal
2901-224C-00 Relay
1004-3000-10 HF bead
1502-0504-00 Jack
Description
SMD 22pF/50V 0805 NPO ±5%
SMD 10pF/50V 0805 NPO ±5%
(BOX)222/100V ±5% Yellow TR
470pF/100V ±5% 5.5mm TR
0.15UF/50V ±20% TR 5mm
474J/100V 5*11MM ±5% Brown TR 5MM
474/100V ±10% Brown TR 7.5mm
104/100V ±5% Green TR 5MM
153/100V ±5% 5MM TR
102/250V TR 5mm ±20%
224/100V ±5% TR 5MM
183/63V ±5% Yellow 5MM
333/63V ±5% TR 5MM
103/63V ±5% TR 5mm
3.3UF/100V ±20% 105℃Brown 20.5mm
3.3UF/250V ±20% 105℃Brown 27mm
22uF/25V ±20% 5*11 105℃ Black 5MM TR
100uF/25V ±20% 6.3*11 105℃ Black 5MM TR
220uF/25V ±20% 8*12 105℃ Black 5MM TR
47uF/25V ±20% 5*11 105℃ Black 5MM TR
470UF/35V ±20% Ф8*20MM 105℃ Black
2200UF/35V Φ16*26MM ±20% 105℃ 7.5MM
SMD 0.12UF/25V 0805 X7R ±10%
2.2UF/50V ±20% 5*11 105℃ Orange 5mm TR
4700UF/80V ±20% 105℃ 35*30mm 10.5mm
22uF/50V ±20% 5*11 105℃ TR 5.0MM
47uF/50V ±20% 6.3*11 105℃ TR 5MM
FR104 1A 400V 52MM TR
IN4004 DO-41 TR
SMD 5.1V DO-213AA 0.5W
SMD 1N4148 DO-213AA
SMD MUR120 1A 2512
6A10 1000V
IRFZ48N TO-220
SMD MMBT5551LT1 NPN SOT-23
SMD BT2222 NPN SOT-23
IRFB 38N20D TO-220
KA7912 TO-220 FAIRCHILD
DIP NJM4560D Dual Op-amp DIP-8
LCR-0202
MUR1620CTA KAD 16A/200V TO-220
UF1602CT AKA 16/200V TO-220
KA7812E TO-220 FAIRCHILD
16PIN RJ45 2*10P16C
φ47 4:19:8:6 L1=L2=φ1.0*8*4TS
S1=S2=φ0.8*6*19TS S3=S4=φ1.0*1*8TS
S5=S6=φ1.0*1*6TS
80℃±5℃ TO-220 PIN 2PCS
Golden crosshead screw
Golden crosshead screw
DC12V 30A
30UH φ12 φ5 11.5mm
Pitch 2.0MM 5PIN Bend 90degree
19
Qty Reference Designator
C45 C33 C32
3
C12 C13 C14
3
C25 CX1 C97 C23 C24
5
C124
1
C46
1
C135 C152
2
C98 C99
2
C122 C65 C119 C85 C86 C139 C140
7
C53
1
C144
1
C103 C102
2
C52
1
C47
1
C54 C125 C126
3
C105
1
C96
1
C136
1
C129 C131 C130 C42
4
C88 C87
2
C50 C49 C35
3
C134 C133 C127
3
C112 C111 C110 C109
4
C123
1
C41
1
C145 C146 C147 C148
4
C3 C4 C7 C8 C10 C31
6
C39
1
10 D29 D28 D27 D26 D25 D24 D23 D22 D21
D16
1
DZ3 DZ2
2
D43 D51 D44 D46 D45 D48 D47 D6 D1 D14
16
D13 D12 D11 D10 D9 D42
D35 D34
2
D17
1
Q28 Q27 Q26 Q25 Q24 Q23 Q22 Q21
8
Q38 Q40 Q1 Q4 Q39 Q37 Q36 Q8 Q7 Q6
14
Q5 Q2 Q3 Q34
Q29
1
Q14 Q13 Q12 Q11 Q10 Q9
6
U14
1
U6 U5 U4 U3 U2 U1
6
LCR1
1
D33 D32
2
D31 D30
2
U13 U15
2
RJ1
1
1 L8
SW2
1
1
1
RL1
1
L12 L11
2
CN1
1
