Pl-L0006; Screw - Infinity Reference 1600a Service Manual

1600a Reference Series
Part Number
SIGNAL BOARD
0701-2681-02 Resistor
0701-2152-02 Resistor
0701-2101-02 Resistor
0701-2303-03 Resistor
0701-2221-02 Resistor
0701-2331-02 Resistor
0701-2473-02 Resistor
Capacitors
06D211076100 E-capacitor
06S321026000 Capacitor
06S321016000 Capacitor
06S321046000 Capacitor
06S132253000 ceramic capacitor
06D344727400 MET Capacitor
06S123326000 Capacitor
06D214764102 E-capacitor
06D211074100 E-capacitor
Semiconductors
0100-C081-08 IC
2601-4N35-00 Optocoupler
01LM-M555-08 IC
0100-74AH-00 IC
0100-2010-00 IC
03P1-5401-04 Transistor
01TC-WH04-00 IC
04ZL-2512-00 Diode
01LM-M311-08 IC
04PT-4148-01 Diode
04WY-51AV101 Zener diode
Miscellaneous
1505-1009-04 Clubfoot pin
MECHANICAL
ZL-A0001A-15 6.5PC Pole
PL-L0007-000 Cliper

PL-L0006-000

Cliper
JY222A18A01X Mica
JY233A22A001 Mica
JY297A22A001 Mica
JY264A22A001 Mica
JY242A22A001 Mica
ZA-H00040100 Snap buttom
LS1AM0250401 Screw
JY217A12A10A ceramic plate
LS1AA0301501 Screw
LS1FJ0200801

Screw

LS5KJ0301007 Screw
LS5KP0300807 Screw
LS1AP0300607 Screw
LS1AM0300607 Screw
KT-200012200 CAP
KT-200021300 CAP
LS1AY0301201 Screw
XG-0017-2601 Bottom plate
Description
SMD 680Ω 1/8W ±5% 0805
SMD 1.5KΩ 1/8W ±5% 0805
SMD 100Ω 1/8W ±5% 0805
SMD 30K 1/8W ±1% 0805
SMD 220Ω ±1/8W 5% 0805
SMD 330Ω 1/8W ±5% 0805
SMD 47KΩ 1/8W ±5% 0805
DIP 100uF/50V ±20% 6.3*11 105℃ Blk 5MM
SMD 1000pF/50V 0805 NPO ±5%
SMD 100pF/50V 0805 NPO ±5%
SMD 0.1uF/50V 0805 NPO ±5%
SMD 2.2uF/16V 1206 X7R ±10%
DIP 472/100V ±5% TR 5MM
SMD 332/50V ±10% X7R 0805
DIP 47uF/25V ±20% 5*11 105℃ Black 5MM TR
DIP 100uF/25V ±20% 6.3*11 105℃ Blk 5MM
TLC081 SOP-8 Op-Amp
4N35 DIP6
SMD LM555 Timer SOP-8
74AHC1G04 Inverter SOT-235
IR2010S High/Low side driver SOL-16
SMD MMBT5401LT1 PNP SOT-23
TC7WH04F Triple Inverter
SMD MUR120 1A 2512
SMD LM311 Comparator SOP-8
SMD 1N4148 DO-213AA
SMD 5.1V DO-213AA 0.5W
DIP PITCH 2.54mm 10PIN Bend 90 degree
φ7.5*φ3.0*6.4mm LASK-5
30*36*0.8mm
30*28*0.8mm
22*18*0.1MM
33*22*0.1mm
97*22*0.1mm
64*22*0.1mm
42*22*0.1mm
φ7.5 M3.5*4
Plating black zinc 2.5*4
17*12*1.0mm white
PA3*15 plating black zinc
KA2*8 plating black zinc
3*10MM Plating nickel
3*8MM Plating nickel
3*6MM Plating nickel
PM3*6 Plating nickel
White PVC for RCA
Red PVC for RCA
PM3*12MM plating zinc
325*182*1.2mm, H1-144 silver painting
21
Qty Reference Designator
R116 R199
2
R56
1
R49 R191 R192
3
R29
1
R113
1
R48
1
R57
1
2 C93 C94
C100
1
C61 C62
2
C57 C59 C60 C63 C75 C77 C91 C92
8
C104 E1
2
C55 C56
2
C64
1
C43
1
C58
1
U8
1
U17
1
U7
1
U16
1
U10
1
Q30
1
U9
1
D8
1
U11
1
D2 D3 D4 D7 D49
5
DZ1
1
CN6
2
2
1
10
1
1
1
1
1
4
4
6
2
2
3
8
6
2
2
2
4
1
