Infinity Reference 1600a Service Manual page 21

1600a Reference Series
Part Number
MAIN BOARD
1001-1015-10 Common mode choke 5MU 60A φ47 22mm*18mm
1001-4000-10 Inductor
1001-3001-10 HF inductor
1413-0001-00 Phone Jack
1404-0004-00 RCA Jack
1401-0001-03 Fuse holder
1601-253G-00 Fuse
POWER BOARD
0701-2104-02 Resistor
0701-2113-02 Resistor
0701-2153-02 Resistor
0701-2222-02 Resistor
0701-2472-02 Resistor
0701-2432-02 Resistor
0701-2103-02 Resistor
0701-2123-02 Resistor
0701-2102-02 Resistor
0701-2202-02 Resistor
0701-2473-02 Resistor
0701-2623-02 Resistor
06S321046000 E-capacitor
06S321026000 Capacitor
06S321046000 Capacitor
1003-1010-08 Inductor
04PT-4148-01 Diode
03N1-5551-04 Transistor
03P1-5401-04 Transistor
03P1-1023-01 Transistor
03P1-B649-07 Transistor
01TI-L494-09 IC PWM
1501-0509-04 Clubfoot pin
1501-0409-02 Clubfoot pin
LED BOARD
2004-0017-00 LED
2100-0035-05 FFC
2000-0017-00 LED
2004-0014-00 LED
0701-6102-02 Resistor
2102-0153-02 FFC
2102-0154-02 FFC
1502-0504-00 Jack
06S121046000 Capacitor
04PT-4148-01 Diode
SIGNAL BOARD
Resistors
0701-2104-02 Resistor
0701-2103-02 Resistor
0701-2100-02 Resistor
0701-2102-02 Resistor
0701-2222-02 Resistor
0701-2203-02 Resistor
0701-2472-02 Resistor
0701-2431-02 Resistor
Description
40UH 40A core:ETD-49 φ0.1*80*14TS
35UH φ25 φ0.3*20*2
6P4C RJ11 Black
4 Jacks white red golden
3PIN
25A/32V
SMD 100KΩ 1/8W ±5% 0805
SMD 11KΩ 1/8W ±5% 0805
SMD 15KΩ 1/8W ±5% 0805
SMD 2.2KΩ 1/8W ±5% 0805
SMD 4.7KΩ 1/8W ±5% 0805
SMD 4.3KΩ 1/8W ±5% 0805
SMD 10KΩ 1/8W ±5% 0805
SMD 12KΩ 1/8W ±5% 0805
SMD 1KΩ 1/8W ±5% 0805
SMD R0805 2KΩ 1/8W ±5% TR
SMD 47KΩ 1/8W ±5% 0805
SMD 62KΩ 1/8W ±5% 0805
SMD 0.1uF/50V 0805 NPO ±5%
SMD 1000pF/50V 0805 NPO ±5%
SMD 0.1uF/50V 0805 NPO ±5%
SMD 100MH 100MHZ 4A
SMD 1N4148 DO-213AA
SMD MMBT5551LT1 NPN SOT-23
SMD MMBT5401LT1 PNP SOT-23
DIP 2SA1023 TO-92 PNP TR
DIP 2SB649A 1.5A 180V 20W PNP TO-126
SMD TL494C SO-16
DIP PITCH 2.54mm 5PIN Bend 90 degree
DIP PITCH 2.54mm 4PIN Bend 90 degree
φ3 White with blue light
5PIN 2.0 UL1007 28AWG L=100mm 2.0 105℃
DIP Red with red ligth Φ3MM 2P
DIP Φ3.0MM Blue with blue light
SMD 1KΩ 1/2W ±5% 2010
2PIN UL1007 red black 28AWG L=320mm
5mm
2PIN UL1007 red black 28AWG L=40mm 5mm
DIP Pitch 2.0MM 5PIN Bend 90 degree
SMD 0.1uF/50V 0805 X7R ±10%
SMD 1N4148 DO-213AA
SMD 100KΩ 1/8W ±5% 0805
SMD 10KΩ 1/8W ±5% 0805
SMD 10Ω 1/8W ±5% 0805
SMD 1KΩ 1/8W ±5% 0805
SMD 2.2KΩ 1/8W ±5% 0805
SMD R0805 20KΩ 1/8W ±5% TR
SMD 4.7KΩ 1/8W ±5% 0805
SMD 430Ω ±5% 1/8W 0805
20
Qty Reference Designator
L6
1
L4
1
L4
1
JK1
1
J1
1
for F1
1
F1
6
R154
1
R171
1
R175
1
R132
1
R46
1
R102
1
R149 R36 R34
3
R35
1
R155 R156
2
R138
1
R19 R20
2
R12
1
C1
1
C143
1
C79 C81 C82 C84 C117 C132 C80 C151
8
L1 L2
2
10 D18
Q33
1
Q32
1
Q19 Q20
2
Q17
1
U18
1
CN7
1
1
8
1
LED101
1
LED100
1
2
1
1
1
C1 C2
2
D1 D2
2
R64
1
R3 R33 R30 R31
4
R117 R118 R193 R198
4
R55 R58
2
R105 R106
2
R2
1
R40 R41 R42 R43 R44
5
R45
1
