- Page 1 LE4618FHD EDGE-LIT LED LCD TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN...
- Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Customer Support Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 Authorised Service Centre for repair. In this event, proof of purchase is required to support a warranty claim. After the repair, the product will be available for collection by or return to the purchaser at a fee upon request. TEAC in- home service can be made available at a fee upon request.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safety Precautions Power Supply Installation Use and Maintenance Important Safety Instructions TV Placement Setup Accessories TV Stand/Wall Mounting Assembly Parts & Connections Front View Back View Initial Setup & Input Sources Initial Power On Selecting and Input Source Remote Control Remote Control Buttons and Functions Battery Installation... -
Page 5: Safety Precautions
1. SAFETY PRECAUTIONS 1.1 Power Supply DO NOT plug several devices DO NOT touch the power DO NOT use a damaged Insert the power plug fully into into the same outlet. plug with wet hands. power cord or plug or a the outlet. -
Page 6: Installation
DO NOT place the unit on an unstable DO NOT place containers with DO NOT place the unit where DO NOT use or store flammable surface, such as a sloped table, or any liquids such as vases, drink cans, it is exposed to rain, excessive or combustible materials near stand with a contact area smaller than bottles or small metallic objects... -
Page 7: Use And Maintenance
Although the LED screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LED screen. This is a property of the LED screen and is not a malfunction. Disconnect the power cord from the power source during a objects, such as a screwdriver,... -
Page 9: Tv Stand/Wall Mounting Assembly
Remote Control Batteries User’s Guide M6X12... -
Page 10: Tv Placement Setup
(supplied) Before installing the stand, please ensure that the Stand is in good condition without scratches, broken parts or missing parts. If these problems are found, please contact TEAC. TV set Stand Screws(supplied) 4 x ST4 x 28F How to install the Stand? 1. - Page 11 2. TV PLACEMENT SETUP Fall Prevention To prevent the TV from tilting forward and falling over to cause damage or injury, please secure the TV to your table or wall using screws or eyebolts and strong cord (not provided). An example on fixing the TV to a table is shown below Install a wood screw or eyebolt into the table that is supporting the TV.
-
Page 12: Parts & Connections
2. TV PLACEMENT SETUP Wall Mounting Fasten 4 eyebolts into the four screw holes on the TV’s rear panel according to the diagram. Fasten the wall mounting bracket using screws onto the wall. Connect the eyebolts and the wall bracket securely with strong rope Carefully check that all fastenings are secure before releasing the TV. -
Page 13: Back View
3. PARTS & CONNECTIONS 3.2 Back View SWITCH AC POWER IN HDMI2 PC-IN NOTE: Before making or changing cable connections, please make sure that power to the unit is completely disconnected by switching off the power supply and unplugging the power cable from the wall outlet. -
Page 14: Initial Setup & Input Sources
4. INITIAL SETUP & INPUT SOURCES 4.1 Initial Power On When the TV is turned on the first time out of the box or after a factory settings reset, it will prompt you to run auto channel tuning. Connect the TV to your antenna wall socket using a coaxial TV cable. After making sure all connections are secure, plug in the power cord and turn on AC power. -
Page 15: Remote Control
5. REMOTE CONTROL The remote control uses Infrared signals. Point it at the Infrared sensor at the front of the TV. NOTE: The remote control may not work correctly if it is operated out of range or angle, of if there are objects blocking the signal. 5.1 Remote Control Buttons and Functions (POWER) : Turn the TV on/back to Standby mode. -
Page 16: Battery Installation
5. REMOTE CONTROL DTV/USB INPUT AUDIO MUTE PICTURE SOUND SLEEP ASPECT Buttons for USB operation: (REC): Press to start record the program in DTV mode. : No function. : Stop program. : Previous chapter. : Next chapter. : Play/Pause program. : Fast reverse. -
Page 17: Menu Map
Main menu CHANNEL PICTURE SOUND TIME Submenu OPTION (Channel menu LOCK for example) Hint---you should operate the OSD menu according to the hint. MENU MENU... - Page 18 Tuning Auto...
-
Page 19: On-Screen Display (Osd) Menu
6. ON-SCREEN DISPLAY (OSD) MENU... -
Page 20: Atv/Dtv Mode
INPUT MENU MENU MENU... -
Page 21: Electronic Programme Guide (Epg)
SCH.LIST SCREEN MENU 7.3 Channel Customisation MENU MENU... -
Page 22: Channel List And Favourite List
CH.FAV CH.FAV CH / CH / CH /... -
Page 23: Password Lock For Channels And Programmes
8899 Enable Locks Block Channel MENU MENU 8899 MENU... - Page 24 MENU Watching 3D Broadcasts in 2D This is a non-3D TV, but it can downconvert and display 3D DTV broadcasts in normal 2D. When tuned into a 3D channel, the 3D picture will most likely be displayed in a split-screen format.
- Page 25 MENU...
-
Page 26: Instant Recording
REPEAT MENU REVEAL... -
Page 27: Time Shift (Pause Live Tv)
CANCEL REPEAT MENU MENU CANCEL CANCEL REVEAL HOLD SIZE... -
Page 28: Scheduled Recording/Viewing Reminder
The name and number The current state of the program of the program The process of the program A-B mark The current time... -
Page 29: Using The Recorded File List
Press to exchange Schedule List Recorded List Press to access the Recorded File List. Any recorded TV programmes will be listed if a USB storage device is connected and powered on. Viewing and Playing Recorded Files Press to view the Recorded File List. Press repeatedly to sort the files by Programme, Channel and Time. -
Page 30: Playing Multimedia Files
USB Usage Precautions Never turn the unit off or disconnect a USB Storage Device (Flash Drive) when it is being accessed. Doing so could damage the TV and the connected USB storage device. Do not use a device that has a maximum current consumption of 100 mA or more. Do not use a device that has security functions or other special functions. - Page 31 DTV/USB INPUT Return to device list Preview Up Folder Information CANCEL...
- Page 32 CANCEL CANCEL...
- Page 33 CANCEL Goto Time CANCEL Select a switable character libraly of corront Text file that you view,such as Char Set Western Europe(Windows).
- Page 34 CANCEL NOTE: If playback is stopped, the track position is remembered and playback will resume from there. Char Set Select a switable character libraly of the subtitle of the movie that you view such as Western Europe(Windows). CANCEL Goto Time CANCEL...
-
Page 35: Reference
Please do not use functions not mentioned in this user manual. If a problem occurs with your TV, please refer to the table below. If the problem persists, please turn the TV off and consult the TEAC Customer Service Hotline. -
Page 36: Specifications
10. REFERENCE 10.2 Specifications LED Panel Panel Size Max. Resolution Input Connector VIDEO YPbPr AUDIO (L/R) PC/AUDIO HDMI 3 The HDMI support 1.3, the HDCP support 1.1) Output Connector HEADPHONE COAX 100-240V 50/60Hz Power Source 150W Power Consumption Standby Power Consumption <0.5W TV receive system PAL BG/DK/I SECAM BG/DK L/L'... - Page 37 1920x1080...
- Page 40 TEAC CUSTOMER SUPPORT HOTLINE (TCS) 1300 553 315 Between Monday to Friday – AEST 8:30AM to 6PM...
