- Page 1 LE1980HD/LE2280FHD/LE2480FHD LED/LCD TV “ For Optimum picture and sound quality, please use TEAC Audio/Video cables ” TEAC High Performance Audio/Video cables and connectors have been designed to enhance your home entertainment experience. USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au...
- Page 3 Where In-Home service/Pick up* is not available, the purchaser is required to send the product to the nearest TEAC Authorised Service Centre for repair. In this event, a copy of this warranty card and a copy of your receipt of purchase must be enclosed to be a valid warranty. Such equipment or part must be sent freight prepaid to your nearest TEAC Authorised Service Centre.
- Page 4 * P P lease refer to TEAC w ebsite for y y our nearest Authorised TEAC Service Centre. . 10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
- Page 5 Dealer’s Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below: service@teac.com.au www.teac.com.au 1800 656 700...
-
Page 6: Table Of Contents
Contents Contents Safety Precautions Power Supply..............................1 Installation................................. 2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Accessories / Wall Mounting Information ......................6 Names of each part(Front View) / Accessories ....................7 Names of each part(Back View) ........................8 Remote control .............................. -
Page 7: Safety Precautions
Safety Precautions Power Supply Do not touch the power Do not use a damaged Do not plug several devices Insert the power plug fully into plug with wet hands. power cord or plug or a into the same outlet. the outlet. loose outlet. -
Page 8: Installation
Safety Precautions Installation Do not place containers with Do not place the unit where it Do not use or store flammable Do not place the unit on an unstable liquids such as flower vases, soft is exposed to rain, excessive or combustible materials near surface, such as a wobbly stand or drink cans, or medicine bottles or... -
Page 9: Use And Maintenance
Safety Precautions Use and Maintenance Although the LCD screen is made with high-precision technology and 99.99% or more of the pixels are effective, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a structural property of the LCD screen and is not a malfunction. -
Page 10: Important Safety Instructions
Safety Precautions Important Safety Instructions... - Page 11 Safety Precautions Important Safety Instructions The manufacturer will not be held responsible for the damage caused by any substitutions and modification of the product without authorisation from the manufacturer’s or authorised service agent.
-
Page 12: User Guidance Information
User Guidance Information Names of each part Accessories 2 x AAA Battery VGA cable USB extension cable Remote Control User’s Guide Mains adapter Mains cable Wall Mounting Information Stand and wall-mounted (optional) Your LCD TV is able to accommodate wall mounting with the useof a wall mount bracket (not supplied with LCDTV, please contact your local hardware store) and the mounting holes on the back of the unit. -
Page 13: Names Of Each Part(Front View) / Accessories
User Guidance Information Names of each part Front View MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. INPUT: Display the input source menu. POWER: Turn on/standby the TV set. -
Page 14: Names Of Each Part(Back View)
User Guidance Information Names of each part Back View HDMI2 HDMI1 1. POWER: Connect to the mains adaptor. 2. USB: USB jack. 3. HDMI1/2: Connect it to the HDMI of DVD or other equipment. 4. YPbPr: Connect them to the YPbPr video output terminal of DVD. 5. -
Page 15: Remote Control
User Guidance Information Remote Control POWER POWER: Turn the TV on/standby. NICAM/A2 MUTE DTV: Switch to DTV source. ASPECT SLEEP USB: Switch to USB source. TV/RADIO SUBTITLE NICAM/A2: Select different audio languages, subject to availability from broadcaster. TV/RADIO: Press to toggle between TV and Radio. ASPECT: Cycles among screen display modes. - Page 16 User Guidance Information Remote Control POWER NICAM/A2 MUTE TV/RADIO ASPECT SUBTITLE SLEEP Buttons for TELETEXT operating Teletext is an information system broadcast by certain channels which can be consulted for news, weather forecasts, puzzles, etc, and also offers subtitles for viewers with hearing problems or who are not familiar with the transmitted EXIT MENU...
-
Page 17: Basic Operation
Basic Operation Basic Operation Power on/off 1. Connect to the socket with the correct power rating using the supplied power adaptor. 2. -To turn on the TV Press POWER button on the TV or remote control. Input Source -To turn off the TV Press POWER button on the TV or remote control. - Page 18 Basic Operation Basic Operation Basic OSD Menu operation Press MENU button to display the OSD menu as below: Main menu CHANNEL PICTURE SOUND TIME Submenu OPTION (Chanel menu Record Stard LOCK for example) Hint---you should operate the OSD menu according to the hint. button to select the main menu, and press button to enter the submenu.
-
Page 19: Osd Menu
OSD Menu OSD Menu 1. CHANNEL menu Record Stard Description Auto Scan Press OK button to enter the hint menu, and select the Country and Tune Type mode for the TV, then press OK button to start auto tuning. DTV Manual Tuning Press OK button to enter the DTV Manual Tuning menu. - Page 20 OSD Menu OSD Menu Programme Edit Press OK button to enter the Program Edit menu as the following picture. Delete: Select a channel and press RED button, “Delete” will appear on the right of the program edit menu next to the channel you have chosen, then press RED button again, the program will be deleted.
-
Page 21: Picture Menu
OSD Menu OSD Menu 2. PICTURE menu Description Picture Mode: There are four preset settings to choose from Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Color and sharpness can only be adjusted in User mode option from the Picture Mode Settings. Contrast: Adjust the difference between the brightest and darkest regions of the picture. -
Page 22: Sound Menu
OSD Menu OSD Menu 3. SOUND menu SPDIF MODE Description Sound Mode: There are five preset setting to choose from Standard, Music, Movie, Sports and User. Note: Treble and Bass can only be adjusted in User mode. Treble: Adjust the relative intensity of higher pitched sounds. Bass: Adjust the relative intensity of lower pitched sounds. -
Page 23: Timer Menu
OSD Menu OSD Menu 4. TIME menu Description Clock: Use the buttons to select the position, and buttons to set the time. Note: User can not change time manually during DTV mode because it is directly synchronise with the broadcast signal. Off Time: Press OK button to enter the submenu, you could set the time when the TV set will be turned off automatically, you could also set the frequency. -
Page 24: Option Menu
OSD Menu OSD Menu 5. OPTION menu OSD Duration Blue Screen Country Description OSD Language: Allows you to select menu language. Audio Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second audio language. Subtitle Language 1st/2nd (can be selected in DTV mode): Allows you to select first and second subtitle language. -
Page 25: Lock Menu
OSD Menu OSD Menu 6. LOCK menu Lock Channel Program Guide Description Lock Channel: Turn on/off the Lock Channel function. Note: You are required to enter a password to access this menu. (Default password is 0000). Set Password: You can set your desired password. If the password was changed previously, you must enter the present password. -
Page 26: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select USB source by the buttons, and press OK button to enter the Multimedia menu such as below. Input Source YPBPR HDMI1 HDMI2... - Page 27 Multimedia Operation Multimedia Operation 1. Photo Display photos ZOOM IN ZOOM OUT Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Music: Play/pause selected music.(you can only play or pause the music you have selected). Playlist: Display the playlist on the screen, and you can select the photo by button, and press OK button to select.
-
Page 28: Multimedia Operation
Multimedia Operation Multimedia Operation 3. Movie Play the movie GOTO Time Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Set A-B: Select and play the preferable paragraph of the program by seting A and B at the beginning and end, and there will be a sign on the left screen, press OK button again to cancel. -
Page 29: Multimedia Operation
Multimedia Operation Supporting Format MOVIE The max bit rate is 6Mbps The max resolution is 720*576P (AVI) Supported mono color 16color 256color 16bit 24bit; 32bit The max resolution is PHOTO 3000*3000 the min resolution is 100*100 Sample rate 8K-48K Bit rate 32K-320K MUSIC Special Note 1 It can only support USB memory device and will not support multimedia device such as mobile... -
Page 30: Recording Operation
Recording Operation Recording Operation DVR settings Press the MENU button, and select CHANNEL menu. Recorded Mode DVR File System 1). DVR File System DVR File System Check DVR File System Setup the PVR File system before you start recording. Select Disk: Select the device for the Record files. Note: Unit will always use the first partition (C:) as a default recording partition. -
Page 31: Recording Operation
Recording Operation Recording Operation 2) Record Start When you finish the settings above, you could start recording by select Record Start in the menu and press OK button in DTV mode. (You can also start recording by pressing the button on the remote control) Record buttons Recording: Press to enter the recording mode. - Page 32 Recording Operation Recording Operation 3). Schedule List You can view Schedule List by pressing the Timer List button on the remote control. Note: a. Unit will only record one program at a time. If you try to do a schedule record with conflicting time, it will not register on to the schedule list.
-
Page 33: Maintenance And Service
Maintenance and Service Trouble shooting Do not use other functions that are not mentioned in this user’s manual. In case a problem occurs with your LCD TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Action Problem Is the power plugged in? Insert the power plug. -
Page 34: Specifications
Maintenance and Service Specifications LCD Panel Panel Size 18.5” 21.6” 23.6” 1366 x 768 1920 x 1080 1920 x 1080 Max. Resolution LE1980HD LE2280FHD LE2480FHD VIDEO Input Connector YPbPr AUDIO (L/R) PC/AUDIO HDMI Output Connector HEADPHONE COAX DC12V 5A DC12V 5A... - Page 35 Maintenance and Service Specifications Supporting Format MOVIE The max bit rate is 6Mbps The max resolution is 720*576P (AVI) Supported mono color 16color 256color 16bit 24bit; 32bit The max resolution is PHOTO 3000*3000 the min resolution is 100*100 Sample rate 8K-48K Bit rate 32K-320K MUSIC...
- Page 36 TEAC CUSTOMER CARE CENTRE (TCCC) Free call: 1800 656 700 Between Monday to Friday – EST 9AM to 5PM...
