INSTRUCTION MANUAL
Digital Eight Channel Recorder
About this manual
Before installing and using this unit, please read this Manual carefully.
Be sure to keep it handy for later reference.
Date: Aug. 29th 2005
EDR810H/810M/
410H/410M
V 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDR810M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EverFocus EDR810M

Summary of Contents for EverFocus EDR810M

  • Page 1 INSTRUCTION MANUAL Digital Eight Channel Recorder EDR810H/810M/ 410H/410M V 1.0 About this manual Before installing and using this unit, please read this Manual carefully. Be sure to keep it handy for later reference. Date: Aug. 29th 2005...

  • Page 2: Product

    Safety Warning WARNING TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE CAUTION DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 3: Safety Precautions

    Safety Precautions Safety Precautions Refer all work related to the installation of this product to qualified service personnel or system installers. Do not block the ventilation opening or slots on the cover. Do not drop metallic parts through slots.This could permanently damage the appliance.
  • Page 4 Safety Precautions Safety Precautions The lightning flash with an arrowhead symbol, within an Warning: equilateral triangle, is intended to alert the user to the presence Electrostatic-sensitive device. Use proper of uninsulated ” dangerous voltage” within the product’s enclosure CMOS/MOSFET handing precautions to avoid that may be of sufficient magnitude to constitute a risk of electric electrostatic discharge.

  • Page 5: Important Safeguards

    Important Safeguards Important Safeguards Read Instruction---All the safety and operating instructions should be read before the unit is operated. Retain Instructions---The safety and operating instructions should be retained for future reference. Heed Warnings—All warnings on the unit and in the operating instructions should be adhered to. Follow Instructions—All operating and use instructions should be followed.

  • Page 6: Table Of Contents

    LIST ………………………………………………………………………...…….……… 2.2 SYSTEM FLOORPLAN ………………………………………………………..…………….……… 2.3 BASIC CONNECTIONS ………………………………………..…………………….…….……… 2.4 BOOT UP EDR810 …………………………………………………………..……………….……… 2.5 QUICK INSTALLATION GUIDE FOR EDR810M & EDR410M ONLY……….………………… 3. MENU SETUP………………………………………………………………………………………… 3.1 TIME/DATE SETUP MENU …………………………………….……………………………….… 3.2 CAMERA SETUP MENU ……………………………………………………………………….…. 3.3 RECORD SETUP MENU ………………………………………..…………………………….……...
  • Page 7 Table of Contents 5. PLAYING BACK……………………………..……………………………………………..………... 5.1 NORMAL PLAYBACK……………….……………………………………………………………… 5.2 SEARCH PLAYBACK …………………………………………………….………………………… 6. COPY TO A VIDEO FILE ………………………………………………….………………………… CALL ………………………………………………………………………..……….………… ……… 8. SCREEN DISPLAY SETTING …………………………..………………..………………………… 9. SCREEN DISPLAY MODE ………………………………….…………….………………………… 10. REMOTE VIEWER ……………………………………..………………..………………………… APPENDIX A: RS232 specifications …………………………………………….……………………...

  • Page 8: Introduction

    1. PRODUCT INTRODUCTION The Digital Video Recorder is the industry’s first full-featured digital video recorder designed specifically for use in security industry. The Digital Video Recorder incorporates all the benefits of digital video recording, is simple to install, and operates just like a VCR.

  • Page 9: Specifications

    1.2 SPECIFICATIONS Video Format NTSC/EIA or PAL/CCIR Video Input 4/8 camera inputs (BNC), 1Vp-p/75ohm 1 BNC video out (1Vp-p/75ohm) for Main Monitor 1 BNC video out (1Vp-p/75ohm) for CALL Monitor Video Output 4 video out (1Vp-p/75ohm) for Looping (4 Channels only) MPEG4 Video Compression...
  • Page 10 Title 12-characters title generator for each camera Ethernet RJ45 connectors for network communication Compact Flash Slot and USB for archiving Archive and Archive through Wireless transmission (Optional) RS-232 9-pin female connector for local communication for Keyboard connection RS-485 2 mono (MIC) inputs, 2 mono (SPEAKER) outputs Audio Power Rate DC 12V/DC 24V...

  • Page 11: Front Panel Keypads

    1.3 FRONT PANEL KEYPADS Channel Key: Press FULL+Channel Key (CH1~CH8) to display video image in the full screen format the picture of the corresponding will fill the whole screen of the monitor display. CH1 / REC: Press this key to start instant recording. CH2 / REV.
  • Page 12 MODE: Switch PIP, 4, 7, and 8 displays in Live and Playback modes. ZOOM: Press this key while viewing the full screen image to display a magnified resolution on the monitor. You must be in “Full” screen mode first before zooming. While zooming, all other function keys will be disable until you press “ZOOM”...
  • Page 13 Shuttle and Jog Dial Shuttle: In the Playback mode, turn the Shuttle dial to fast forward/rewind the video. In the Pause mode, turn the Shuttle dial to slow forward/rewind the video. In the Search mode, turn the Shuttle to change pages. Jog Dial: In the Pause mode, turn the Jog dial to forward/rewind the video.

  • Page 14: Back Panel Connectors

    1.4 BACK PANEL CONNECTORS Back panel of 810M Back panel of 810H Back panel of 410M Back panel of 410H POWER Main Power plug: Connect the DC 12~ 24V power source to adapter for AC 100~ 240V.
  • Page 15 AUDIO Audio IN: Audio input for recording, and it can be set to “YES” or “NO” in the RECORD SETUP MENU. Audio OUT: Connect to an audio input of a monitor or other device. MONITOR MAIN MONITOR: This connector is used for the main monitor display, a number of different display modes may be selected for viewing.
  • Page 16 IR receiver on the front panel. Note: The IR receiver extension line (10m) must be purchased separately. Wireless LAN (Reserved) Antenna: Integrated IEEE 802.11b/g wireless LAN capabilities. The antenna port is for wireless network antenna use (For EDR810M option). FAN: Cooling FAN.

  • Page 17: Monitor Display

    1.5 MONITOR DISPLAY The status information of the cameras or machine will show up, and be located at different places on the screen. 1. Channel tag 2. Event sign 3. Select sign 2. Event sign 4. Play status bar 5. Record status bar Channel tag: A channel tag indicates the channel name of the screen.
  • Page 18 Select sign: You can assign a camera to a display by pressing SELECT key in life mode. Dial Jog to move the select sign to the display you would like to change camera, and then press FULL + channel key to relocate the camera. Play status bar: The play status bar appears in play back mode if you enable a status bar on the screen (Check page 12, item 15th, DISPLAY).
  • Page 19 1. Current date: The current date which is set in the TIME/DATE SETUP MENU. 2. Record status: It shows REC and recording hard disk number. “REC”, it shows when machine is recording. “R01”, the recording hard disk number. There is only one hard disk available in this model, so it always shows R01 when recording.

  • Page 20: Installation

    2. INSTALLATION The installations described below should be done by qualified service personnel or system installers. 2.1 PACKING LIST Please check accessories in the packing before the installation. 2.2 SYSTEM FLOORPLAN Please refer to the following diagram for the system connections. Note: Monitor and Camera must be purchased separately.

  • Page 21: Basic Connections

    RJ45 connector Ethernet cable or wireless network (IEEE 802.11b/g). RS232/RS485 Digital Video Recorder is enabled control from the PC or EverFocus keyboard via RS232/RS485. Main/Call Monitor Connect the Main/Call monitor output connector to a Main/Call monitor. The Main/Call monitor displays selected live or recorded cameras in any available format.

  • Page 22: Quick Installation Guide For Edr810M & Edr410M Only

    The EDR810M & EDR410M are the full-featured digital video recorders designed specifically for use in mobile applications. Please refer to the following Quick Installation Guide for installing EDR810M or EDR410M into mobile applications such as buses, cars and police cruisers. The DVR can be mounted horizontally (suspend or support mounted).
  • Page 23 Quick Install Guide : 1. Unpack Everything Make sure you have everything you need before you begin the installation. 2. Equipment Required The following tools may help you to complete the installation: •Drill •Screwdrivers •Wire cutters 3. Choosing the Location Choose a location for installation that: •Provides convenient access for installing or removing the hard drive •Allows air to flow around the fan vents.
  • Page 24 Possible Installation Locations Inside the Automobile Vehicle: TOYOTA CAMRY Glove box (inside or underneath) Trunk (Users are suggested to use “suspend” for mounting option) Passenger seat (underneath) Drive seat ( between seat and wall) Show the wiring on the wiring harness that connects to the electrical system. Vehicle body Car body On/Off switch...
  • Page 25 Trunk Possible Installation Locations Inside the Automobile Vehicle: Glove box (inside or underneath) Drive seat ( between seat and wall) or Passenger seat (underneath) ( Users are suggested to use “support” for mounting option) Show the wiring on the wiring harness that connects to the electrical system. Vehicle body Car body On/Off switch...
  • Page 26 Installing the Camera(s) and Monitor The DVR is typically connected to one camera installed inside the car. Other camera(s) can also be installed in different locations (for example, use the waterproof camera to the outside of vehicle). For installation procedure, refer to the guide that came with the camera(s) you purchased.
  • Page 27 Installing the Hard Drive The following figures are for the 3.5” and 2.5” HDD. Figure shows 3.5“ HDD Figure shows 2.5“ HDD...

  • Page 28: Menu

    3. MENU SETUP To set up the machine before using is necessary, especially first time to use. Press the MENU key to enter the MAIN MENU. Press the MENU key to quit current setting, and go back to last setting. MENU Dial the Jog clockwise or counterclockwise to change subentry values.
  • Page 29 In the TIME/DATE SETUP MENU, we define : (1) TIME FORMAT: There are two time formats that are 12 HOUR and 24 HOUR to be selected. (2) TIME: Current time Hour: 00 ~ 23 (1 ~ 12 if TIME FORMAT is 12 HOUR) Minute : 00 ~ 59 Second: 00 ~ 59 (3) DATE FORMAT:...
  • Page 30 (7) END TIME: To set the end time of daylight saving time. To set the end month of daylight saving time: Dial the jog to set the end month. To set the end week of daylight saving time: Dial the jog to set the end week. 1 ST 2 ND 3 RD...

  • Page 31: Camera Setup Menu

    3.2 CAMERA SETUP MENU In the CAMERA SETUP MENU, we define : (1) TITLE: The title setting allows you to assign a title to each camera input. Titling with 12 characters is supported in each channel. The available alphanumeric characters are: 0,1,2,3,4,5,6,7,8,9, A,B,C,D,E,F,G,H,I,J,K,L,M,N,O,P,Q,R,S,T,U,V,W,X,Y,Z, ( ) .
  • Page 32 (5) REC QUALITY: Select an image quality for recording. Normal record image quality and event record image quality can be set individually. There are six different qualities available. A higher image quality needs more HDD space. The theory space needed per second lists below: : 4.0 Mega Bits/sec SUPERIOR : 3.5 Mega Bits/sec...
  • Page 33 (8) SUMMARY : Dial Jog to change items in the SUMMERY table. All camera’s statuses are shown in the SUMMARY table. The table is for checking camera overall statuses only, not for setting. Note: The SUMMARY table also exists in ALARM, MOTION and VLOSS SETUP MENU. All of these SUMMARY tables are also for checking particular overall statuses, not for setting.

  • Page 34: Record Setup Menu

    3.3 RECORD SETUP MENU In the RECORD SETUP MENU, we define : (1) RECORD AUDIO: YES: Audio will be recorded when machine is recording. NO: Audio will not be recorded when machine is recording. (2) TIME STEMP: ON: The time stamp will show on the video and picture when recording. OFF: The time stamp will not show on the video and picture when recording.
  • Page 35 (6) RECORD MODE: REWRITE: Continue recording. Disk will be overwritten if it is full. STOP: Stop recording when disk is full.

  • Page 36: Alarm Setup Menu

    3.4 ALARM SETUP MENU In the ALARM SETUP MENU, we define : (1) ALARM: ENABLE: Enable alarm detection. DISABLE: Disable alarm detection. (2) ALARM TYPE: N. O. : Normal Open alarm. N. C. : Normal Close alarm. (3) ACTIVE CAMERA: Active camera setting, from camera 01~08.
  • Page 37 (5) DURATION: Buzzer noise and event record duration of an alarm, from 1 sec to 99 seconds. The default value is 5 seconds. (6) ALARM OUTPUT: The setting of alarms which are NONE and 1, where 1 means the alarm is enabled. (7) ALARM EMAIL: Select “YES”...

  • Page 38: Motion Setup Menu

    3.5 MOTION SETUP MENU In the MOTION SETUP MENU, we define : (1) MOTION: ENABLE: Enable motion detection. DISABLE: Disable motion detection. Note: Motion only works in live and playback modes. It is invalid when you are setting menus. (2) SENSITIVITY: The sensitivity allows users to adjust to a suitable motion detection sensitivity.
  • Page 39 (6) EMAIL/NETWORK: YES: Send an email / Enable alarm network when an alarm occurs. NO: Do not send an email / Disable alarm network when an alarm occurs. The email address can be set in the NETWORK SETUP MENU. (7) BUZZER: Motion buzzer. ENABLE: To enable a motion buzzer.
  • Page 40 (11) EDIT MULTIPLE MOTION AREA Enter a desired channel, and press SELECT to edit a motion area. In the motion edit mode: The default motion area of each camera is entire screen which displays in light green. Press COPY to start to set an area. Then press SEARCH to end and enable the area, or press PAUSE to end and disable the area.

  • Page 41: Vloss Setup Menu

    3.6 VLOSS SETUP MENU In the VLOSS (Video Loss) SETUP MENU, we define : (1) VLOSS: ENABLE: Enable video loss detection. DISABLE: Disable video loss detection. (2) DURATION: Buzzer noise and event record duration of an alarm, from 1 sec to 99 seconds. The default value is 5 seconds.
  • Page 42 (6) ALARM NETWORK: YES: Enable alarm network. NO: Disable alarm network. (7) SUMMARY: All video loss’s statuses are shown in SUMMARY tables. These tables are for checking video loss overall statuses, but not for setting.

  • Page 43: Network Setup Menu

    3.7 NETWORK SETUP MENU There are 4 subentries that are CONFIG, ALARM, EMAIL and PASSWORD in the NETWORK SETUP MENU. Each of them has to be set up completely before the network functions. 3.7.1 CONFIG Please Note: Since every Network Configuration is different, please contact your Network Administrator or ISP for how to assign those IP addresses and port numbers.
  • Page 44 (8) HTTP PORT: The default port number is 80. User can change it to different port number for HTTP/WEB communication between DVR and client PC. (9) CONTROL PORT: The default port number is 1600. User can change it to different port number for Controlling comment between DVR and client PC.
  • Page 45 (4) SERVER 1 : assign the IP address of Alarm server 1. (5) SERVER 2 : assign the IP address of Alarm server 2. (6) SERVER 3 : assign the IP address of Alarm server 3. 3.7.3 EMAIL In the ALARM of the NETWORK SETUP MENU, we define : (1) SMTP SERVER: assign the SMTP (e-mail) server’s IP address.
  • Page 46 3.7.4 PASSWORD In the PASSWORD of the NETWORK SETUP MENU, we define : (1) NAME: assign the login name for remote accessing. (2) PASSWORD: assign the password for remote accessing. (3) LEVEL: assign the accessing Right/Priority of that login user. “PLAY” allows users to playback the video and to see live images.

  • Page 47: Schedule Setup Menu

    3.8 SCHEDULE SETUP MENU In the SCHEDULE SETUP MENU, we define : (1) DAY: MON (Monday), TUE (Tuesday), WED (Wednesday), THU (Thursday), FRI (Friday), SAT (Saturday), SUN (Sunday). WDAY: Weekday, from Monday to Friday. WEND: Weekend, Saturday and Sunday. DLY: Daily. (2) START: The start time of a scheduled record time zone.
  • Page 48 3.9 DISK SETUP MENU In the DISK SETUP MENU, we define : (1) DISK INFORMATIONS: Select disks, there are 5 disks in each table. However, only one disk in available in this model. (2) DISK VIDEO DELETE: The disk you want to delete. Press SELECT to start delete.
  • Page 49 DATA BIT: Select data bit : 7 or 8. The default setting from the factory is 8. Note: RS 485 pin definition is shown in APPENDIX B. (3) RS 232 / RS 485 ID: Select ID from 001 to 255. (4) PTZ PROTOCOL: Select PTZ protocol from EVERFOCUS, PELCO-D and PELCO-P,...
  • Page 50 3.11 WARNING SETUP MENU In Warning Setup Menu, you will be able to do warning setting when the following situations occur: 3.11.1 FAN FAULT In FAN FAULT, we define: BUZZER: Fan buzzer. ENABLE: To enable a buzzer when the fan does not work. DISABLE: To disable fan buzzer.
  • Page 51 3.11.2 HDD TEMP. In HDD TEMP., we define: BUZZER: HDD TEMPERATURE buzzer. ENABLE: To enable a buzzer when HDD’s temperature is over 70 ° C. DISABLE: To disable HDD TEMP. buzzer. ALARM OUTPUT: The setting of alarms which are NONE and 1, where 1 means the alarm is enabled. ALARM DURATION: PERMANENT NETWORK ALARM: YES: To enable network alarm.
  • Page 52 3.11.3 NO HDD In NO HDD, we define: BUZZER: NO HDD buzzer. ENABLE: To enable a buzzer when no HDD has been found. DISABLE: To disable NO HDD buzzer. ALARM OUTPUT: The setting of alarms which are NONE and 1, where 1 means the alarm is enabled. ALARM DURATION: Buzzer noise and event record duration of an alarm, from 1 sec to 99 seconds.
  • Page 53 3.11.4 HDD FULL In HDD FULL, we define: BUZZER: HDD FULL buzzer. ENABLE: To enable a buzzer when HDD is full. DISABLE: To disable HDD FULL buzzer. ALARM OUTPUT: The setting of alarms which are NONE and 1, where 1 means the alarm is enabled. ALARM DURATION: Buzzer noise and event record duration of an alarm, from 1 sec to 99 seconds.

  • Page 54: System Setup Menu

    3.12 SYSTEM SETUP MENU In the SYSTEM SETUP MENU, we define : (1) SYSTEM VERSION: Current system firmware version. (2) SYSTEM VIDEO FORMAT: NTSC or PAL System can detect the input signal type automatically from camera 1 while system is booting up. Users do not need to set it up. Note: The signal type is detected by the camera 1, so camera 1 input has to be connected.
  • Page 55 (6) LANGUAGE: System language can be set in different languages. Note: The available language depends on the different areas and countries. (7) QUICK PLAY: Set up the start play time of the normal play mode. TIME: Quick play time, from 00:00 to 59:59. The default value is 10 minutes. ON: Enable quick play.
  • Page 56 Note: After upgrading system software, please do the following actions before recording: Load System Default in System Setup Menu. Delete disk in Disk Setup Menu. User Level and Right V. 1.0 LEVEL LEVEL-3 LEVEL-2 LEVEL-1 NONE ACCESS RIGHT ADMINISTRATOR OPERATOR GENERAL ---- DISPLAY...

  • Page 57: Record Setup Menu

    4. RECORDING 4.1 INSTANT RECORDING Press the Record key to start to record immediately. When REC is pressed, the pictures being monitored will be recorded in the HDD. •The recording rate, recording quality and recording speed can be set in the CAMERA SETUP MENU.
  • Page 58 4.2 SCHEDULE RECORDING Set up the DAY, START time, END time and then enable the SET in the SCHEDULE SETUP MENU. Please refer to SCHEDULE SETUP MENU, to see setting procedure and more details. 4.3 EVENT RECORDING We define two event types which are ALARM and MOTION events can be recorded. After the event recording is enabled, the EDR810/410 will start an event recording when an event occurs.
  • Page 59 2. After enable an event, you need to set a time zone in the SCHEDULE SETUP MENU. An event recording has to be included in a scheduled time zone. You can refer to SCHEDULE SETUP MENU to set up a time zone which you would like to record when an event occurs. 3.

  • Page 60: Playing Back

    5. PLAYING BACK 5.1 NORMAL PLAYBACK (1) Playback Press the PLAY key to start playing back the stored image/audio. The video start time depends on the immediate play setting in the SYSTEM SETUP MENU. PLAY Press the REV. PLAY key to start reverse playing back the stored image/audio from the last segment.

  • Page 61: Playback

    (4) Slow Forward/Reverse Playback During playback mode, press PAUSE key to freeze the playing back picture. PAUSE Turn the Shuttle dial clockwise, to start slow forward playback. The speed will show on the status bar of the bottom screen. >> 1/2, 1/4, 1/8, 1/16, 1/32, and press ENTER at the same time to fasten the play speed.

  • Page 62: Search Playback

    5.2 SEARCH PLAYBACK Press the SEARCH key to enter the SEARCH MENU. SEARCH In the SEARCH MENU, Dial the Jog clockwise or counterclockwise to change subentry values. Press the ENTER key to go next subentry in search menu setting, and press the DISPLAY key to go last subentry in search menu setting.
  • Page 63 (2) EVENT Search Playback You can change different event search methods if you select “BY EVENT” instead of “BY TIME / DATE”. 7 events which are ALARM, MOTION, VLOSS, A/M, A/V, M/V and A/M/V can be selected. The indications of events show as below. EVENT Indication ALARM...

  • Page 64: Copy To A Video File

    6. COPY TO A VIDEO FILE Insert a Compact Flash card into the Compact Flash slot on the front panel, or insert a USB pocket driver into USB slot on the back panel to copy. USB SLOT: CF CARD SLOT: Digital Video Recorder allows users to select the camera for copying image to movie file.
  • Page 65 In the COPY MENU, we define: DISK NO: Disk number. It is fixed as “01” in this series. CH NO: Camera channel number. You can select the video of camera you would like to copy. START DATE & TIME: The start time of video you want to copy. END DATE &...

  • Page 66: Call

    7. CALL Press the CALL key and the CALL MENU will pop up as below. In the SYSTEM SETTING MENU, we define : (1) SEQ: Sequence display on the call monitor. Press SEQ to switch “ON” or “OFF” of the sequence status.
  • Page 67 (b) SEQ is ON: When QUAD DISPLAY is “NO”, the call monitor displays a sequence full screen of each channel. When QUAD DISPLAY is “YES” (enabled), the call monitor displays a sequence quad screen.

  • Page 68: Screen Display Setting

    8. SCREEN DISPLAY SETTING In a full screen display, press SELECT key to pop up the display adjustment window as below: In the screen display setting menu, we define: (1) CAMERA: The display setting of the current camera. (2) BRIGHTNESS: The bright percentage of the current camera; from 0% to 100%. (3) CONTRAST: The contrast percentage of the current camera;...

  • Page 69: Screen Display

    9. SCREEN DISPLAY MODE Press MODE to switch 4, 7, 8, and PIP (picture in picture) displays for Live and Playback mode.

  • Page 70: Remote Viewer

    10. REMOTE VIEWER Basic Operations and Login Display: Go to the Internet Explorer, key in the network IP address, for example, http://220.228.98.9 (must be the same IP address as the one assigned to the unit from the Network Setting Menu. please contact your ISP or MIS for the IP assignment) The LOGIN dialog will be shown on the screen.

  • Page 71: Main Screen

    Main Screen 3 4 5 6 The above diagram is the main screen display. The icons on the lower corner of the screen are mainly for control and configuration, those on the right corner are for status indication. If any icon is grayed, it means that the specific function is not accessible in the current mode. The followings are a brief description for each of the icons.
  • Page 72 7. The system allows up to 3 ways to playback video, by EVENT LIST, Time and PTZ Control. (Playback by EVENT LIST, click “Update” button to show list) (Playback by Time) (Playback by PTZ Control)
  • Page 73 Search from EVENT LIST: Select Event Type from Alarm, Motion and Vloss. Press Update button to refresh the event list. III. All events of the selected type will be displaying along with Date/Time, event type (represents by a capital letter), camera number (represents by a number), e.g.
  • Page 74 8. Events to be searched: Alarm, Motion and Vloss. 9. All available events are shown in the list. Select the desired event and it will be highlighted. 10. Click on “Play” to playback selected video event. 11. Press “Update” to refresh the event list. 12.
  • Page 75 APPENDIX APPENDIX A : RS232 specifications This Digital Video Recorder can be controlled by a computer or a terminal via a RS232 standard D-SUB 9-pin RS-232 connector. D-SUB 9-pin connector The pin assignment of the 9-pin D-SUB connector Digital Video Recorder HOST PIN # NAME...
  • Page 76 APPENDIX APPENDIX B : RS-485 (RJ45) specifications There are two RS-485 (RJ-45) connectors of one port on the back panel of the DVR. Please refer to the following pin assignment for application. 1 2 3 4 5 6 7 8 PIN # NAME...
  • Page 77 APPENDIX APPENDIX C : Alarm I/O Assignment Alarm I/O pin assignment The alarm connector, Figure 1, is used to provide one sensor alarm input for each camera input. For easy operation, an alarm extension board, Figure 2, is provided to connect to the alarm connector. Each alarm input requires two wires, one wire connects to the desired alarm input pin, the second wire connects to the ground.The alarm signal assignment is shown at the following.
  • Page 78 APPENDIX APPENDIX D : Troubleshooting If the above error message pops up when you connect to EDR1680 for viewing from internet, you should change Internet Option of IE to enable ActiveX controls. Select Tools -> Internet Options… Please refer to the above steps for changing Security Options to Low.
  • Page 79 Albert-Einstein-Strasse 1 D-46446 Emmerich, Germany TEL: 49-2822-9394-0 www.everfocus.de Ihr EverFocus Produkt wurde entwickelt und Your EverFocus product is designed and hergestellt mit qualitativ hochwertigen Materialien manufactured with high quality materials and und Komponenten, die recycelt und wieder components which can be recycled and reused.
